Dacia Pick-Up 1304/1305/1307. Service manual - part 146

89

ELECTRICAL DIAGRAMS

89 - 23

ENGINE WIRING

X75

03

  A.C. COMPRESSOR CLUTCH

(for A.C. provided vehicles)

Position Sectioning

Destination

1

 0,75

  38R

CONTROL +

 A.C. COMPRESSOR CLUTCH

NO

       171

38R

X

WIRE FUNCTIOS IN CONNECTORS AND COUPLINGS

89

ELECTRICAL DIAGRAMS

89 - 24

VALVE POTENTIOMETER

Position Sectioning

Destination

1

0,5

NF

POTENTIOMETER MASS

2

0,75

3LS

SIGNAL + POTENTIOMETER 1

3
4

0,75

3LW

SIGNAL + POTENTIOMETER 2

5

0,75

3AQ

SUPPLY + VALVE POTENTIOMETER

ENGINE WIRING

X75

03

DIAGNOSIS  PLUG

Position Sectioning

Destination

1

 0,75

HK

LINE  K DIAGNOSIS SIGNA

L

2

0,5

ML

MASS

WIRE FUNCTIOS IN CONNECTORS AND COUPLINGS

89

ELECTRICAL DIAGRAMS

89 - 25

ENGINE WIRING

X75

03

IDLE MOTION  REGULATOR

Position Sectioning

Destination

1

   1,0

3BU

CONTROL 1 IDLE MOTION REGULATOR

2

1,0

3BV

CONTROL 2 IDLE MOTION REGULATOR

3

0,75

3AY

IDLE MOTION SWITCH M

ASS SIGNAL

4

0,75



ML

M AS S

FUEL PUMP CONTROL RELAY

Position Sectioning

Destination

2

 1,0

  3NR

+ INJECTOR  > FUEL PUMP RELAY

4

0,75

AP29

+AFTER PROTECTED

CONTACT

6

0,75

3AC

CONTROL - FUEL PUMP RELAY

8

2,5

B

+ BATTERY

NO

  2

 X



OR



AP29

  8

 3AC

3NR

  4

6

B



G

R

CS6P

       236

WIRE FUNCTIOS IN CONNECTORS AND COUPLINGS

89

ELECTRICAL DIAGRAMS

89 - 26

MAIN RELAY

Position Sectioning

Destination

2

 1,0

3BR

+ AFTER  CONTACT > MAIN RELAY

4

0,75

AP29

+ AFTER PROTECTED CONT

ACT

6

1,0

B

+ BATTERY

8

0,75

ML



MASS

ENGINE WIRING

X75

03

NO

  2

 N



OR



AP29

 ML

3BR

  4

  6



  B



 G

  R

CS6P

       238

  8

INJECTION WATER TEMPERATURE SENSOR

Destination

1

0,75

  3C

SIGNAL  +

WATER TEMPERATURE SENSOR

2

0,5

NF

MASS WATER TEMPERATURE SENSOR

Sectioning

Position

WIRE FUNCTIOS IN CONNECTORS AND COUPLINGS
