Dacia Pick-Up 1304/1305/1307. Service manual - part 123

SEALING WINDOWS AND SCREENS

- Side glass rubber gasket ( D 1304 King - cab )

- Separating wall glass rubber gasket

- Windshield rubber gasket

ISMO UNTING

Remove the glass together with the rubber gasket, by pushing it from the interior of the

vehicle.

Clean the rubber gasket if it will be reused or replace it with a new one.

EMO UNTING

Place the rubber gasket around the glass on all its contour, where previously has been

introduced a cotton rope (4) with the diameter of 3-4 mm leaving some 20 cm of free rope
at each end (3) but no more than 10 cm between ends.

GLASSES SEALING GASKETS

66 - 1

For glasses dismounting/remounting please see s/chapter 54.

SEALING WINDOWS AND SCREENS

ISMO UNTING

Dismount the arm rest at the upper part.
Dismount the window regulator handle and the inner opening mechanism.
Dismount the panel by removing it from clips and take out the inner wiper.

EMOUNTING

Perform the dismounting operations in the reverse order.

66 - 2

INNER WIPERS

SEALING WINDOWS AND SCREENS

ISMO UNTING

Lower the window to the minimum position
The dismounting of the outside wiper is performed by removing it from the fixing clips.

EMO UNTING

Perform the dismounting operations in the reverse order.

66 - 3

OUTSIDE WIPERS

INTERNAL BODY TRIM

71 - 1

FLOOR CARPETS

1. molded carpet
2. under bench carpet ( Dacia Double Cab)
3. platform carpet ( bed mat)

MOLDED CARPET

DISMOUNTING

Dismount:

- the front seats
- the front safety belts locks
- the gearbox lever ornament
- the front/rear doors thresholds.

Dismount by hand the molded carpet.

REMOUNTING

Perform the dismounting operations in the reverse order.

UNDER BENCH CARPETS ( DACIA DOUBLE CAB )

DISMOUNTING

Dismount :

- the rear bench
- the rear safety belts locks that are attached on the intermediary floor.

Dismount by hand the carpet under the bench.

REMOUNTING

Perform in the reverse order the dismounting operations.
