MANUAL GEARBOX 21 21 - 38 Engage the velocity steps III - IV fork in the position required for the coupling of velocity step IV and keep it in this position until complete mounting of the gearbox. REMOUNTING OF THE REVERSE DRIVING PINION Place the attachment spring and ball of the shaft in the left side half crankcase. NOTE: The spring is black painted to be different from locking spring of forks shafts. Introduce the reverse driving pinion shaft - the reverse driving pinion, with the hub directed towards the front of the gearbox; - the friction washer, with the bronze side towards the pinion. Introduce the guiding wedge in its seat and completely introduce the shaft. Mount the safety ring. REPAIR |
