Peugeot 306 C Dag (2001 year). Manual

YOUR 306 CABRIOLET IN DETAIL

Button

Function

Ejection of the CD.

RDS

RDS function on/off.
Press for more than 2 seconds: regional station following on/off.

Traffic information priority on/off.
Press for more than 2 seconds: PTY function on/off.

Volume increase.

Volume decrease.

AUDIO

Selects bass, treble, loudness and fader.

Automatic search of higher frequency.
Selection of next CD track.

Automatic search of lower frequency.
Selection of previous CD track.

MAN

Manual/automatic operation of buttons G and H.

Source selection, radio. Selection of wavebands FM1, FM2, FM3, AM.

Press for more than 2 seconds: automatic storing of stations (autostore).

Source selection, CD.

Press for more than 2 seconds: shuffle.

Source selection: CD player.

Press for more than 2 seconds: shuffle.

ON/VOL

Radio on/off. Volume adjustment.

1 to 6

Selection of the stored station.
Press for more than 2 seconds: storing a station.
Selection of a CD disc.

▲

▼

YOUR 306 CABRIOLET IN DETAIL

GENERAL FUNCTIONS

On / off

With the ignition key in the ACCESSORIES or IGNITION position, press the "ON/VOL" button to switch the set
on or off.
The set can operate for 30 minutes without switching the ignition on.

ANTI-THEFT SYSTEM

The first time you use the set following disconnection of the set or the battery, you must enter the confidential code
which was given to you on handover of your vehicle.

Entering the code

Switch the set on.
The display shows “CODE” then the set changes over to code request mode and "- - - -" is displayed.
Enter your four-digit code number using buttons "1" to "6".
For example: if your code is 5345 press buttons "5", "3", "4" and "5" in turn.
When the fourth number has been entered correctly, the radio starts automatically.

Error in entering the code

If an error is made when entering one of the first three digits, do not continue the operation and switch off the radio
to prevent blocking it.
Each incorrect code entry will result in the set being blocked for a period of from 5 seconds to 30 minutes, after
the 7th incorrect entry.
To unblock the set, leave it switched on during the waiting period. When "- - - -" is displayed, you can enter the code again.
If the set is switched off during the waiting period, this waiting period will restart when the set is switched on
again.
After incorrectly inputting the code 14 times, the radio will be permanently locked and will display the message

ADJUSTING THE SOUND

Adjusting the volume

Turn the "ON/VOL" button M to increase or decrease the volume of the set.
In the event of the radio overheating, the volume level decreases.

Note

If you have a car-phone fitted with a “mute” signal output connected to the set, the set will automatically change
to “mute” when the car-phone is used.

YOUR 306 CABRIOLET IN DETAIL

AUDIO SETTINGS

Press the “AUDIO“ button once to select (BASS), then again for treble (TREB), loudness (LOUD), fader (FAD)
and balance (BAL).
Exit from audio mode is automatic after a few seconds, without pressing any button or by pressing the “AUDIO”
button after adjusting the balance.
Note: the bass and treble settings are specific to each source. It is possible to set the radio, CD, or CD multi-changer
differently.

Bass setting

When “BASS” is displayed, press the “D” or “E” buttons to vary the setting.
- “BASS -9” for a minimum bass setting,
- “BASS 0” for a normal position,
- “BASS +9” for a maximum bass setting.

Treble setting

When “TREB” is displayed, press the “D” or “E” buttons to vary the setting.
- “TREB -9” for a minimum treble setting,
- “TREB 0” for a normal position,
- “TREB +9” for a maximum treble setting.

Adjusting the loudness

This function automatically emphasises bass and treble tones when the volume is low.
Press the “D” or “E” buttons to switch this function on or off.

Setting the front/rear sound distribution (Fader)

When “FAD” is displayed, press the “D” or “E” buttons to vary the setting.
The “D” button increases the volume at the front.
The “E” button increases the volume at the rear.
This function may be switched off by simultaneously pressing buttons “M” and “F”.

Setting the right/left sound distribution (Balance)

When “BAL” is displayed, press the “D” or “E” buttons to vary the setting.
The “D” button increases the volume on the right-hand side.
The “E” button increases the volume on the left-hand side.

YOUR 306 CABRIOLET IN DETAIL

RADIO

Notes on radio reception

Your car radio receiver is subject to phenomena which do not affect domestic sets. Both amplitude modulation
(MW/LW) and frequency modulation (FM) reception are subject to various forms of interference which are not a
reflection on the quality of your set, but are due to the nature of the signals and the way in which they are
transmitted.
On MW/LW, interference may be noticed when passing underneath high voltage power lines or bridges or in
tunnels.
On FM, interference may be the result of distance from the transmitter, reflection of the signal by obstacles (moun-
tains, hills, buildings etc), or of being in a shadow area (an area which is not covered by a transmitter).

Selecting the radio

Press the "J" button.

Selecting a waveband

By short presses on the “J” button, you can select the FM1, FM2, FM3 and AM wavebands.

Automatic station search

Briefly press button “G” or “H” to search for the station immediately above or below. By continuing to press the button
in the direction selected, you will obtain continuous scrolling of the frequency.
The scrolling stops on the first station found immediately after you release the button.
If TA, traffic information programme, is selected, only stations broadcasting this type of programme are selected.
Searching for a station occurs first in “LO” sensitivity (selection of the most powerful transmitters) during
scanning of the waveband, then in “DX” sensitivity (selection of the weakest and most distant transmitters).
To scan the waveband in “DX” sensitivity, press twice on button “G” or “H”.

Manual station search

Press the “MAN” button.
Briefly press button “G” or “H” respectively to increase or reduce the frequency displayed.
By continuing to press the button in the direction selected, you will obtain continuous scrolling of the frequency.
Scrolling stops as soon as you release the button.
Pressing the “MAN” button again returns you to automatic station search.

YOUR 306 CABRIOLET IN DETAIL

Manual storing in memory of stations

Select the station required.
Press for more than two seconds one of the buttons “1” to “6”.
The sound stops then becomes audible again, confirming that the station has been stored in memory.

Automatic storing in memory of FM stations (autostore)

Press the “TUNER” button for more than two seconds, to automatically store the 6 stations with the strongest
signal in FM. These stations are stored in the FM3 waveband.
- If it is not possible to find 6 stations, the remaining memories are empty.

Recall of stations stored in memory

For each waveband, briefly pressing the buttons “1” to “6” recalls the corresponding stored station.

RDS FUNCTION

Using the RDS (Radio Data System) function on FM

RDS allows you to continue to listen to the same station, whatever frequency it is using for the region you are going
through.
Switch the function on or off by briefly pressing the “RDS” button.

RDS station following

The display indicates the name of the station selected. The radio is continually searching for the station which has
the best reception and which is transmitting the same programme.

YOUR 306 CABRIOLET IN DETAIL

Traffic information programme

Press the “TA” button to switch the function on or off.
Any traffic information flash will be broadcast as a priority, whether you are using the radio, CD, CD multi-
changer.
If you wish to interrupt a message, press the “TA” button; this switches off the function.
Note : the volume of the traffic information announcements is independent of the volume of normal radio
listening. You can adjust it using the volume button. The setting will be stored and will be used when the
next messages are broadcast.
While traffic information is being broadcast, the display will alternately show “TRAFFIC” and the name of the
station.
When the station selected cannot broadcast traffic information, the display shows “NO TA”.

Regional following mode (REG)

When they are part of a network, certain stations broadcast regional programmes in the various areas they serve.
With regional following mode you can keep listening to the same programme.
To do this press the “RDS” button for more than two seconds to switch this function on or off.

PTY function

This allows you to listen to stations broadcasting a specific type of programme (news, culture, sport, rock etc.).
With FM selected, press the “TA” button for two seconds to switch this function on or off.
To find a PTY programme:
- switch on the PTY function,
- briefly press button “G” or “H” to scroll down the list of the various types of programmes offered,
- when the programme of your choice is displayed, keep button “G” or “H” pressed for more than two seconds

to carry out an automatic search (after an automatic search the PTY function is switched off).

In PTY mode the different types of programmes can be stored in memory. To do this, press down the preselection
buttons “1” to “6” for more than two seconds. Recalling the type of programme stored in the memory is by a brief
press on the corresponding button.

YOUR 306 CABRIOLET IN DETAIL

EON system

This connects stations which are part of the same network. It enables broadcasting of traffic information or a PTY
programme from a station which is part of the same network as the station to which you are listening.
This service is available when you have selected the TA traffic information programme or the PTY function.

COMPACT DISC

Selecting the CD as source

After inserting a disc, with the printed surface upwards, the player starts automatically.
If a disc is already inserted, press the "K" button.

Ejecting a disc

Press button “A” to eject the disc from the player.

Selecting a track

Press button “G” to select the next track.
Press button “H” to return to the start of the current track or to select the previous track.

Accelerated play

Press the “MAN” button.
Keep button “G” or “H” pressed for forwards or backwards accelerated play.
Accelerated play stops as soon as you release the button.
Buttons “G” and “H” resume the “track selection” function when the “MAN” button is pressed again.

Shuffle (RDM)

When the CD is selected, keep the “K” button pressed for two seconds. The tracks will be played in random
sequence. Pressing the “K” button again for two seconds returns you to normal play.

YOUR 306 CABRIOLET IN DETAIL

EON system

COMPACT DISC

Selecting the CD as source

After inserting a disc, with the printed surface upwards, the player starts automatically.
If a disc is already inserted, press the "K" button.

Ejecting a disc

Press button “A” to eject the disc from the player.

Selecting a track

Press button “G” to select the next track.
Press button “H” to return to the start of the current track or to select the previous track.

Accelerated play

Shuffle (RDM)

When the CD is selected, keep the “K” button pressed for two seconds. The tracks will be played in random
sequence. Pressing the “K” button again for two seconds returns you to normal play.

YOUR 306 CABRIOLET IN DETAIL

CD MULTI-CHANGER

Selecting the CD multi-changer

Press the “L” button.

Selecting a disc

Press a button from “1” to “6” to select the corresponding disc.

Selecting a track

Press button “G” to select the next track.
Press button “H” to return to the start of the current track or to select the previous track.

Accelerated play

Shuffle (RDM)

When the CD multi-changer is selected, keep the “L” button pressed for two seconds. The tracks will be played in
random sequence. Pressing the “L” button again for two seconds returns you to normal play.

YOUR 306 CABRIOLET IN DETAIL

CD PLAYER (available as an accessory)

To insert a disc into the player:

– open sliding panel A,
– press button B to eject the cartridge C,
– open one of the six compartments of the cartridge by pulling tab D,
– insert the disc with the printed face upwards and close the

compartment,

– insert the cartridge into the player,
– close the sliding panel A.

YOUR 306 CABRIOLET IN DETAIL

YOUR 306 CABRIOLET IN DETAIL

Ventilation

1 - Windscreen demisting or de-icing vents.

2 - Front windows demisting or de-icing vents.

3 - Side vents.

4 - Central vents.

5 - Air outlet to front footwells.

6 - Air outlet to rear footwells.

Advice on use

- Position the air flow control at a sufficient level to ensure correct renewal of air inside the vehicle.
- Select the most suitable air distribution for your requirements and the climatic conditions.
- Select a suitable temperature setting and only modify it gradually for your comfort.

YOUR 306 CABRIOLET IN DETAIL

To quickly de-ice or demist the windscreen and the side windows, set the
heating and air flow controls to maximum.
To obtain even air distribution, ensure that the external air intake vent and the ven-
tilation vents are not blocked and that the air can move freely under the front seats.

2 Adjusting the temperature
Turn the knob 2 to the blue zone
(outside temperature) or to the red
zone (hot).
3 Adjusting the air flow
Turn the knob 3 to the required flow
position.

This position prevents the
entry of outside air. It must
only be used for a short time
to prevent the entry of
unpleasant odours or dust.

1 Adjusting the air distribution
To direct hot or cold air, turn knob 1 to the desired position.

Windscreen and side
windows.

Windscreen, side windows
and footwells.

Footwells only.

Side and central vents.

HEATING

1 Switching on

Press the switch 1, the operating light will come on.

2 Adjusting the temperature

Turn the knob 2 to the blue zone (cold) or to the red zone (hot).

3 Adjusting the air distribution

To direct the hot or cold air, turn the knob 3 to the desired position.

4 Adjusting the air flow
Turn the knob 4 to obtain the desired
flow.

Entry of outside air
This is the normal operating
position.

Recirculation of interior air
This position prevents the
entry of outside air.
Used at the same time as the

air conditioning, this will improve air
conditioning performance.
Used on its own, it prevents the entry
of outside air (dust, unpleasant
odours) but there is a risk of misting of
the windows.
Avoid continuous operation in interior
air recirculation mode.

Important precautions:
Operate the air conditioning system
for 5 to 10 minutes once or twice a
month to keep it in good working
order.
It is advisable to change the air con-
ditioning system fluid every two years.
If the system is not producing cold air,
stop using it and contact a
PEUGEOT dealer.

Windscreen and side
windows.

Windscreen, side windows
and footwells.

Footwells only.

Side and central vents.

YOUR 306 CABRIOLET IN DETAIL

AIR CONDITIONING

YOUR 306 CABRIOLET IN DETAIL

SEATS

1 - Forward-backwards adjustment

Lift the lever and slide the seat forwards
or backwards.

2 - Adjusting the driver’s seat height

Pull the telescopic handle forwards and
pivot it up or down.

3 - Adjusting the backrest angle

Lift the handle to obtain the best angle.

4 - Lumbar adjustment*

Turn the knob.

5 - Access to the rear seats

Lift the handle, tilt the seat-back and
slide the seat forwards. When it slides
back, the seat will return to its original
position.

6 - Head-rest

Height adjustment: slide the head-rest.
Adjustment is correct when the top of the
head-rest is level with the top of the
head.
The angle of the head-rest can also be
adjusted*.
To remove the head-rest press the tab.

* According to specification.

Peugeot 306 C Dag (2001 year). Manual - part 4
