Opel GT (2012 year). Instruction - part 3





38

Seats, interior

Adjust  driver seat height

Press  and hold switch  up  or down until
desired position is rea ched.

Seat position

Ad just driver’s  seat such  that, with the
driver sitting upright, the steering  wheel is

held in the area of its upper spokes with the
driver’s arm s slightly bent.
Push passenger’s seat as fa r back a s
possible.

Head restra ints

The  head restraints  are an integ ra l part of
the  seat back rest  and are designed  to

provide protec tion in the  event of a rear
impa ct, thereby reducing the risk of nec k

and should er injuries.

9

 Warning

Failure to observe these  descriptions
could lead to injuries  which  could  be

fatal. Vehicle passengers should  be
inform ed  according ly before starting-off.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

39

Seats, interior

Folding seat b ackrests

Lift  release lev er on outboard side of
back rest  and fold seat b ackrest forwards.
To move upright, lift release lever, move
seat b ackrest bac kwards and audibly

enga ge.

Three-stage restraint system

Comprising:

z Three-point seat belts,
z Belt tensioners,
z Airbag systems for driver and passeng er.
The three  stag es are a ctivated  in  sequence

depending on the seriousness of the
accident:
z The  automa tic  seat belt locking devices

prevent the  belt strap from being  pulled

out and thus  ensure that the v ehicle
occupants are retained in their seats.

z The  seat belts are pulled  down at the

belt buckles.  This mak es the b elts  fit

snugly, the  oc cup ants are decelerated
together with the v ehicle,  and the  body

is subjected to less stress.

z The airbag  systems a re also triggered in

the ev ent of serious accidents and form a
safety cushion for the occupants.

Depending on the severity of the
accident, the  airbags inflate

in two stages.

9

 Warning

The airbag systems are supplementary
to the three-point  seat belts and  belt

tensioners,  and  the sea t  belts must
therefore  always be worn. Disregarding

these instructions  may  lead to injuries or
endanger life. Vehicle passengers should

be informed accordingly.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

40

Seats, interior

Three-point seat  belts

The v ehicle  is equipped with three-point
seat b elts  with autom atic retractors and

locking devices,  allowing  freed om  of body
movement although the spring tensioned

belts are always  a snug  fit.
For  information on correct sea ting

position –  see  pages 38, 42, 46.
The b elts are lock ed during rap id vehicle

acceleration or deceleration.

In the event of an  accident,  persons not
wearing sea t  belts enda ng er their fellow

oc cup ants and  themselves.
Control indica tor k for  passeng er’s seat

belt –  see  page 43.
Control indica tor X  for  d riv er’s  seat  b elt  –

see p ages 43, 57.
Sea t belts are only desig ned for use by one

person  at a time. They are  not suitable for
persons younger  tha n  12 years of age or

sma ller than 150 cm.

Belt forc e limiters
Belt force limiters on the seats reduce the

stress on the body due to controlled release
of the  belt during a  collision. This m eans

that the  oc cup ants m ov e forward under
control.

Inspection of belts

Plea se check  all parts of the b elt system
occasionally for dama ge a nd  correct

operation. H ave da maged parts replaced .
After an accid ent, hav e belts and dep loyed

belt tensioners  replaced by a workshop.
Do not perform  any altera tions on the

belts,  their anchorages, the automatic
retrac tors or the  belt buck les.
Mak e sure that b elts  are  not da maged or
trapped by sharp-edged objec ts.

9

 Warning

Always wear your sea t  belt,  and that
means  also in urban traffic. It  can save

your life!
Also, pregnant wom en must always wea r

a seat belt  – see page 43.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

41

Seats, interior

Belt tensioners

The seat belts are fitted w ith b elt
tensioners. The sea t  belts are pulled d ow n

at the buckles in the  event of frontal
impac ts ab ov e a  certain sev erity.  This

tightens the belts.

Actua tion of belt tensioners
Indicated by continuous illumination of

control indicator v in  the instrum ent pa nel.
The b elt tensioners must  be replaced

after activation. Consult a  workshop.
Further information – see pa ge 43.

Control ind icator  v for  belt tensioners

The opera tion of the  belt tensioners is
monitored electronically together with sea t

oc cup anc y recog nition and the airbag
systems and is ind icated by control

indica tor v.
When the ignition is switched on, the

control indicator flashes  for  approx.
5 seconds.  If it does not flash, does not go

out a fter 5 seconds or illuminates while
driving, there is  a fault in the

belt tensioners, seat  oc cup anc y
recognition or the airbag systems  –

see a lso pag es 45, 48. The systems may
fa il  to  deploy in the event of an accident.
Deploym ent of the belt tensioners  is
indica ted b y continuous illum ination of v.

The  system’s integrated self-diagnostics

allows faults to b e q uick ly rem edied.
Consult a workshop .

9

 Warning

Have the c ause of  the fault rem edied by
a workshop .

-------------------------------------------------------------------------------------------------------------------------------------------------------------

42

Seats, interior

Im portant
z Acc essories and  other objects not

specifically app rov ed for your v ehicle
type must not be a ffixed or placed within

the action zone of the belt  tensioners
(near the retractor) as this could result in

injury if the belt tensioners are triggered .

z Do not m ake any modifications to the

com ponents  of the belt  tensioners, a s
this will render the vehic le unroadw orthy.

z The belt tensioner and airbag system

control electronics c an  be  found in the

centre c onsole area. In  ord er to av oid
malfunctions, do not store magnetic

ob jects in this area.

z We  recommend that you have the seats

rem oved  by a  workshop  in the ev ent of

actuation of the belt tensioners.

z The  belt tensioners are  for single  use

only, w hich is indicated by continuous
illumination of control indicator v. Hav e

deployed  belt  tensioners replaced  by a
workshop .

z Applicable safety directives must alwa ys

be observed when  disposing of the

vehicle.  For this  reason, disposal should
be done  by an a uthorised recycling

compa ny.

Using the belts

Fitting  the belt
Pull the belt out from  the retractor  and

guide it across the body, making c ertain
that it is not twisted.
Insert the  latch plate  into the buckle.
The seat back rest  must  not be tilted  back

too far  (the rec om mended m aximum  tilting
angle is approx. 25

o

).

Mak e sure that the lap belt is not  twisted
and that it  fits snugly across the body.

Tension the belt frequently while driving by
tugging the  diagonal part of the  belt.

9

 Warning

Inc orrect handling  (e.g. removal  or fitting
of b elts or belt  buc kles) can deploy the

belt tensioners with risk  of  injury.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

43

Seats, interior

Thick layers of  clothing p revent  the belt

from fitting  snugly. The belt must  not  rest
against hard or fragile  objects in the

pockets of your clothing (e.g. b allpoint
pen, keys, spectacles), since this c ould

cause injury. No objects such as handbags,
mobile phones etc. must  be p resent

between  the belt and your body.

Dr iver’s sea t belt w arning device X

Control indica tor X  illuminates in the
instrument panel for  approx.  20 seconds

when the ig nition is sw itched on, or until
driver’s seat  belt is fastened . Flashes for a

further 60 seconds if seat belt rem ains
unfastened .
When  the vehicle is being  driven, if the
driver’s seat  belt remains  unfastened, the

control indicator will illum inate for a pprox.
20 seconds and flash for  a further

60 seconds or until  the belt is  fa stened.
Ap ply seat  belt –  see  page 42.

Control indica tor g oes out  immed iately.
Control indica tor X  for  d riv er’s  seat  b elt  -

see p age  57.

Passeng er’s seat b elt warning  device k

Control indicator k illuminates in the
centre console after a pprox. 20 seconds

when the ignition is switched on, if
passenger’s  seat belt is unfastened  and the

seat occupancy recognition system detects
that the  passenger’s seat is occupied.

Sta ys  illum inated for a further 20 seconds
then flashes for  approx. 60 seconds  if seat

belt rem ains unfastened.
When the  vehicle is  being d riv en, if the

passenger’s  seat is  occupied a nd  the belt
remains unfastened, the control indicator

will illuminate  for a pprox. 20 seconds and
then flash for a further 60  second s or until

the belt is fastened .
Apply seat belt – see pa ge 42.

Control indicator goes out imm ediately.
Seat occupancy recognition - see page 48.

9

 Warning

On pregnant  women in pa rticular,  the
la p belt  must b e positioned as low a s

possible a cross the pelvis so  as  not to
put too m uch  pressure on  the abd om en.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

44

Seats, interior

Removing the belt

To rem ov e the belt, depress  the red
pushbutton on the buck le; the belt  will

retract autom atic ally.

Child restraint systems

3

A wa rning stick er on the sun v isors reminds
that  the use of rea rward facing child

restra int systems p oses a risk of fatal injury.

When using a  child restraint system, always
observe the instructions on installation and

use.
The country in w hich you are trav elling

ma y not perm it the use of child restraint
systems on certain  seats. Always comply

with the  loc al or national  regulations.

Note

z Children und er 12 years or und er 150 cm

tall should only trav el in an ap prop ria te

child  sa fety sea t.

z When  transporting children, use  a child

restra int system  that is  suitable for  the
child 's weight.

z The covers  of the child restraint system

can be wiped clea n.

z Do not stick anything on the child

restra int systems and do not cover them

with  any other m aterials.

z Only a llow  children to enter a nd  exit the

vehicle at the side  fa cing  away from the
tra ffic.

z A child restraint system which has been

subjected to  stress in an accident must

be replaced.

9

 Warning

Vehicle with front passenger airbag:
Rear-fa cing  child seats must  not  be

fitted, danger of fata l injury.
Sp ecifically a pproved  forwa rd -fa cing

child restraints  can be fitted on the  front
passenger’s seat, provided  that the latter

is moved as far bac k as it will go.
Opel has app rov ed c hild  restra int

systems from  the ’DUO’ and ’KID’ ranges.

9 Warning

N ever carry c hild  restra int system s on

your lap, risk  of fatal injury.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

45

Seats, interior

Permissible options for fitting a child

safety seat

Opel Full Size airbag system

The airb ag system is identified by the w ord
AIRBAG on the steering wheel and  above

the glove compartment.
The airbag  system comprises:
z an airbag  with inflator in the steering

wheel and a  second one  in the

instrument panel,

z control  electronics with impac t  sensors,
z control indicator for airbag systems v in

instrument panel,

z seat occ upa ncy rec og nition.

The airbag system is triggered:
z depending on the sev erity of the

accident,

z depending on  the type of im pact, within

the range shown in the  illustration.

Exception: The seat oc cup anc y recognition
system  deactiv ates the a irba g on the

passenger’s side if the p assenger’s seat is
unoccupied  – see page 48.
Examples  of  events triggering the airba g

system:
z Impact  against a  non-yielding obstacle:

the a irb ags are triggered at a low vehicle
speed .

z Impact aga inst a yielding obsta cle (such

as  a nother  vehicle):  the  a irb ags  a re  only

trig gered at a  higher vehicle speed.

Weight and

ag e class

On front

pa ssenger

seat

1)

1)

En sure seat is  in  its rearmost po sition.

Group 0:
up to  10 kg

or approx. 10 m onths
Group 0+:

up to  13 kg
or approx. 2 years

X

Group I:
9 to 18 kg

or approx. 8 m onths to
2 years

L

Group II:
15 to 25 kg

or approx. 3 to 7 years
Group III:

22 to 36 kg
or approx. 6 to 12 years

L

X

= No child restraint of any  class

allowed in this seating position

L

= Suitable only for specifically

approved child restraints. Opel  has

approved child restraint systems
from the ’DUO’ and  ’KID’ ranges.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

46

Seats, interior

When triggered,  the airbags inflate in

milliseconds to form  a safety cushion for
the d riv er and  passenger. The forwa rd

movement  of the seat occupants is
check ed, thereb y sub stantially reducing

the risk of injury to the  upp er body and
head .
No im pairment of view will occur,  because
the a irb ags  inflate and deflate so quickly

that it is often not ev en noticed  in  an
accident.

The airbag system will not be triggered in

the event of:
z the ignition  being switched  off,
z minor frontal collisions,
z accidents in which the vehicle overturns,
z collisions involving  a sid e or rear impac t

where it would not be of benefit to the

occupants.

9

 Warning

The airb ag system prov ides optimum
protection when  the seat  and  backrest

are correctly  adjusted.
Adjust  the driver's sea t  according to the

occupant's height such that, with the
driver sitting upright, the steering wheel is

held  in  the area of its  up per spokes w ith
the driver's arms slig htly bent.
The  passenger’s seat should  be a s far
back  as possible, with the  backrest

upright – see pa ges 7, 37, 38.
Do not place the head, b od y, hands or

feet on the c ov er of the airbag systems.
Do not place any objects  in  the area in

which the airb ags inflate. Im portant
inform ation –  see page 49.

9

 Warning

The three-point  seat belt  must b e
correctly fitted (see  page  42).

-------------------------------------------------------------------------------------------------------------------------------------------------------------

47

Seats, interior

In add ition,  the airbag  system  will not be
triggered for the passenger in versions with

seat occupancy recognition if:
z the passenger’s sea t  is unoccupied .
Seat occupancy recognition – see page 48.

Control ind icator  v for  airbag  systems

The opera tion of the  airbag systems is
monitored electronica lly together  with

seat occupancy  recognition a nd  the
belt tensioners and is indicated  by  control

indica tor v.
When the ignition is switched on, the

control indicator flashes for approx.
5 seconds.  If it does not flash, does not go

out a fter 5 seconds or illuminates while
driving, there is  a fault in the airba g

systems, the seat occupancy recognition or
the belt tensioners –  see also pages 41, 48.

The system s may fail to d eploy in the event
of an accident.
Deploym ent of the airba gs  is indicated by
continuous illumination of v.

The  system’s integrated self-diagnostics

allows faults to b e q uick ly rem edied.
Consult a workshop .

9

 Warning

Seat  belts must always be worn. The
airb ag system  serves to supplement the

three-point seat belts.
If you do not w ear your seat belt, you risk

being seriously injured, or even  thrown
from the vehic le, in the ev ent of an

accident.
If an accident occurs, the belt helps to

maintain  the correct  seat position that
is required for the  airbag system

to prov ide you with effectiv e protection.

9

 Warning

Have the c ause of  the fault rem edied by
a workshop .

-------------------------------------------------------------------------------------------------------------------------------------------------------------

48

Seats, interior

Seat oc cupancy recognition
The seat occupancy recognition system

deactivates the passenger’s airbag  if  the
passenger’s sea t is not occupied.
Control indicators  W and V for seat
occupancy  recognition a re located on the

centre console. Both control  indica tors
illuminate for app rox. 5 seconds after the

ignition is switched on, then either W or V
illuminates continuously.
If both control indicators illuminate
continuously, or neither  illum inates  after

the ignition is sw itc hed on, there is a fault in
the seat occupancy recognition system.

The airbag and b elt tensioner systems m ay
fail to deploy in the event of an accident or

may deploy unnecessarily. H ave  cause of
fault remedied immediately by  a

workshop.
Belt  tensioners - see pa ge 41,

Airbag system s -  see p age  45.

Control indica tor W illuminates

continuously as soon as the system ha s
detected that the passenger’s sea t is not

oc cup ied.  The airbag  for the passenger’s
seat is dea ctiv ated.
Pa y attention to the  control indicators  for
seat occupancy recognition.

9

 Warning

If the pa ssenger’s  seat is not  occupied,
control indicator W m ust illuminate

continuously in the centre console after
the ignition  is switched  on.
If control indicator W does not illum inate
while driving,  the airbag  systems have

not been dea ctivated on the passenger’s
side and m ay deploy unnec essarily in the

event of an accident.
In this case, check  that  the seat bac krest

is not pushing  down onto  the seat
cushion. Recline back rest if necessary.  If

control indicator W d oes not illuminate
after adjusting backrest, ha ve cause of

fault remedied by a workshop.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

49

Seats, interior

Control indicator V illuminates

continuously as soon as the  system has
detected that the p assenger’s  seat is

occupied  and the  passenger is correctly
seated. When a  passeng er occupies the

passenger’s sea t, the a irb ag for the
passenger’s sea t  is  activated  and may

infla te in the event of an accident.
Pay attention to the control indica tors for

seat occupancy recognition.

Importa nt
z Accessories a nd  other objects must not

be  affixed or stored  in  the area  in which
the airbags inflate, since they  could

cause injury if the a irb ags a re deployed.

z Do not  place  any objec ts between the

airbag systems and  the vehicle
occupants;  risk of injury.

z The airbag  systems  and belt tensioner

control electronics  can be found in the

centre console area. In order to av oid
malfunctions, do not store mag netic

objects in this a rea.

z Do not stick anything on the steering

wheel or instrument pa nel, or cov er
either of these area s w ith other

materials.

z Use only a  dry cloth or Interior/

Upholstery Cleaner to clea n the  steering
wheel and instrument panel. Do not use

any agg ressive cleaning  agents.

9

 Warning

If the passenger’s seat is occupied,
control ind ic ator V must  illuminate

continuously in the c entre console after
the  ig nition is sw itc hed on.
If control indicator V does not illuminate
while  driving, the  airbag systems have

not been activa ted on the  passeng er’s
side; risk of fa ta l injury.
In this case,  turn off the ignition, ensure
the  passenger’s seat ba ckrest is in  an

upright position and the passenger is
sitting  upright in the seat. Resta rt  the

vehicle.  If the control indicator  does not
illuminate w hile driving, hav e ca use  of

fault rem edied by  a workshop .
If control indicator v for  airbag systems

and b elt tensioners illum inates  in  the
instrument panel and W is illuminated in

the centre c onsole while the pa ssenger’s
seat is occupied, consult  a workshop

immediately.

9

 Warning

Never ca rry child restraint systems or
other objects on your lap; risk  of  fa ta l

injury.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

50

Seats, interior

z The airbag system s are triggered

depending  on  the severity of the

accident and  the type of impa ct.

z Each airbag c an b e triggered only once,

which is indicated by continuous
illumination of control ind icator v. Once

trigg ered , an airbag  must  be replaced
without delay.  Consult a  work shop.

z The speeds, directions of movement and

deformation properties of the vehicles,

and  the properties of the obstacle
concerned, d eterm ine the severity of the

accident and  trig gering of the  airb ags.
The degree of damag e to your v ehicle

and  the resulting repa ir  costs alone a re
not indicative that the  criteria for

trigg ering of the airba gs  were met.

z Do  not m odify airbag  system

com ponents, since this would  render the
vehicle unroadworthy.

z Applicable safety directives must alwa ys

be observed when  disposing of the

vehicle.  For this  reason, disposal should
be done  by an a uthorised recycling

compa ny.

z Persons weighing  less than 35  kg should

only travel in a vehicle suitable for fitting
a c hild restraint system. The use of child

restraint systems in your vehic le is not
rec om mended.

z Do not place any heavy  objects on the

passenger’s seat when the seat is

unoccupied, otherwise the airbag for the
passenger’s seat may be  trig gered

unnecessarily in the event of  an
accident.

z To prevent m alfunctions in the seat

occupancy recognition system, do not

use protective cov ers or seat cushions on
the passenger’s seat.

Notes on loading the vehicle

z Secure heav y objects in the luggage

compartment. If objec ts are to be
stack ed, the hea vier objects should be

placed  at  the  bottom. Unsecured  objects
in  the luggage compa rtm ent would be

thrown forward w ith g reat force  in  the
event of heavy braking,  for  exam ple.

z If heav y loads slip when the vehicle is

braked heavily or driven a round a bend ,

the handling of the v ehicle  may  cha nge.

z The warning triangle  3 and first-aid kit

(cushion) 3 should alwa ys be freely
accessible.

9

 Warning

If hand led im prop erly, the airbag
system s c an  be triggered  in a n explosive

manner; risk of injury!

-------------------------------------------------------------------------------------------------------------------------------------------------------------

51

Seats, interior

z No objects should  be p laced  on  the

instrum ent panel. They are reflected in

the glass, obstruct the driver’s v iew a nd
will  be  thrown throug h  the vehic le in the

event of heavy braking, for exam ple.

z Objects must not be stored  in the airba g

inflation a rea, because they could cause
injury if the airbag system  is  deployed.

z Loads m ust not obstruct the  operation of

the pedals, hand brake and g ear shift

lever, or hinder the freed om  of
movem ent of the d riv er. Do not pla ce

any unsecured objects  in  the interior.

z Do not drive with luggage compartment

op en when transporting bulky objects,
for exam ple,  to  avoid causing  damag e

to the vehic le.

Stowage compartments

Glove comp artm ent
To  op en, pull handle.
The glove compartment can be locked
using the ig nition key.

Console box between sea ts

To open, press button  in  centre of console
box, rotate it  left or right and pull cover

down.
To close,  push cover up until it latches in

position a nd press the button.

9

 Warning

Failure to observe these descriptions can

lead to injuries which may be fatal.
Vehicle passengers should  be informed

according ly.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

52

Seats, interior

Net p oc kets

Loc ated  on the panel  behind both seats.
Lift  backrest release  lever and fold seat

forward to access the net pock ets.

Backrest poc kets

Located on the rear side  of the backrests
on b oth seats.
Lift back rest release lever a nd  fold  seat
forward  to  access the b ackrest pockets.

Seat cushion  pockets

Located on the front of the seat cushion on
both seats.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

53

Seats, interior

Ashtrays

To be used only for ash and not for
combustible rubbish.

To open: pull lid upwards.
To emp ty: pull ashtray out of the recess by
gripping the  lid and pulling upwards.
To install:  seat the  bottom  edges of the
ashtray in the recess and push  the ashtray

fully in.

First-aid kit

+ 3

warning triangle

¨ 3



Your first-aid k it  and warning triangle c an
be a ccommodated in the lugga ge

compartment.

Power outlets

Cigarette lig hter )
Press in cigarette lighter.
Pops up  autom atically once the element is
hea ted.  Pull out lighter.
The  cigarette lighter socket  can also  be
used a s a n  accessory soc ket.

9

 Warning

Failure to observe these descriptions can
lead to injuries which may be fatal.

Vehicle passengers should  be informed
according ly.

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     1      2      3      4      ..
