9A–14 SEAT BELT SYSTEM Third Seat Belt Buckle and Lock Assembly Third Seat Belt Buckle and Lock Removal 1. Disconnect the battery ground cable. Installation To install, follow the removal steps in the reverse order, 1. Tighten the lock assembly fixing bolts to the specified torque. Torque: 39 N·m (4.0 kg·m/29 lb ft) 2. Tighten the buckle assembly fixing bolt to the specified torque. Torque: 39 N·m (4.0 kg·m/29 lb ft) 1 4 3 2 755RW042 Legend (1) Third Seat Belt Buckle Assembly (2) Third Seat Lock Assembly (3) Third Seat (4) Seat Lock Cover |
