8F–18 BODY STRUCTURE Installation To install, follow the removal steps in reverse order noting 1. Reroute the control cable to its original position, and check and see if the lock assembly and control lever 2. Tighten the hood lock assembly fixing bolts to the specified torque. Torque : 10 N • m (1.0kg·m/87 lb in) Radiator Grille And Front End Lower Panel Parts Location 603RY00002 Legend (1) Front End Lower Panel (3) Radiator Grille Removal 1. Open the hood. D Refer to Headlight Wiper Arm & Blade in |
