![]() 8F–14 BODY STRUCTURE 4. Remove cowl cover brackets. D Disconnect two screws each side. 5. Remove cowl cover. D Disconnect three screws. 6. Remove cowl cover seals. 7. Remove front window lower molding. Installation To install, follow the removal steps in reverse order. Engine Hood Removal 1. Open the hood. 880RS001 4. Remove hood hinge bolts (3). D Before removing the hinges from the engine hood 610RS003 5. Remove engine hood. Installation To install, follow the removal steps in the reverse order 1. Tighten the engine hood fixing bolts to the specified torque. Torque: 13 N • m (1.3kg·m/113 lb in) 2. Adjust the engine hood mounting gap with reference to Body Dimension in this section. 3. Check and see if the engine hood lock operates normally. |
