7C–16 CLUTCH 8. Apply molybdenum disulfide type grease to the areas shown in illustration. 201RW012 9. Install the release bearing in the proper direction. NOTE: Ensure release bearing is properly positioned 201RW020 10. Install driven plate assembly. Use the pilot aligner 5-85253-001-0 (J-24547) to install the driven plate 201RW027 11. Install pressure plate assembly and tighten the bolts holding the pressure plate assembly in the order Torque: 18 N·m (1.8 kg·m/13 lb ft) 201RS017 12. Remove the aligner. NOTE: Do not strike the aligner with a hammer to remove 13. Install transmission assembly. |
