Opel Frontera UBS. Service manual - part 1823





10A–8 CRUISE CONTROL SYSTEM

Removal

1. Disconnect the battery ground cable.
2. Remove the cruise actuator Assembly (4).

D

Disconnect the connector (3).

D

Remove the cable end (1) from the cam link (cruise
control side).

D

Loosen two fixing nuts (2).

D

Remove three actuator fixing screws.

825RW049

Installation

To install, follow the removal steps in the reverse order,
noting the following point.

1. Take care not to bend the cable excessively.

Mode Switch

Removal and Installation

Refer to the Mode Switch removal and installation steps
in Automatic Transmission section.
