4A2A–24 DIFFERENTIAL (REAR 220mm) Thickness of thrust washers available: 0.80 mm, 0.90 mm, 1.00 mm 1.10 mm, 1.20 mm, 425RS050 5. Install lock pin. After lock pin installation, stake the cage to secure the lock pin. 425RS051 Legend (1) Staked Portion 6. Clean the ring gear threaded holes to remove the locking agent. When installing the ring gear, apply 7. Tighten the bolts in diagonal sequence as illustrated. Torque: 108 N·m (11.0kg·m/80 lb ft) NOTE: Discard used bolts and install new ones. 415RW036 |
