HOOD DLK-319 < REMOVAL AND INSTALLATION > [WITHOUT INTELLIGENT KEY SYSTEM] C D E F G H I J L M A B DLK N O P Be careful not to bend the cable too much, keep the radius 100mm (3.94 in) or more. 2. Make sure the cable is not offset from the grommet, and push the grommet into the lower dash panel hole securely. 3. Apply sealant around the grommet at * mark. 4. Install the cable securely to the lock. . 6. Install the front grille. Refer to EXT-20, "Removal and Installation" . Hood Lock Control Inspection INFOID:0000000007355652 CAUTION: If the hood lock cable is bent or deformed, replace it. 1. Remove the front grille. Refer to EXT-20, "Removal and Installation" 2. Make sure the secondary latch is properly engaged with the sec- ondary striker with hood's own weight by dropping it from approx. 200 mm (7.87 in) height. 3. While operating the hood opener, carefully make sure the front end of the hood is raised by approx. 20 mm (0.79 in). Also make sure the hood opener returns to the original position. 4. Check the hood lock lubrication condition. If necessary, apply “body grease” to the points shown. 5. Install the front grille. Refer to EXT-20, "Removal and Installation" . LIIA1698E LIIA1699E PIIA1086E PIIA0176E August 2012 2012 Pathfinder 2012 Pathfinder |
