Mercedes-Benz Sprinter / Dodge Sprinter. Service manual - part 399
(6) Remove engine mounts and raise engine.(7) Disconnect the oil level sensor.(8) Remove the transmission cooler lines from the
oil pan bolts and carefully position the lines aside
(9) Remove the oil pan bolts.(10) Remove oil pan and gasket (Fig. 57).
Fig. 56 ENGINE SUPPORT FIXTURE
VA
ENGINE
9 - 59
