CONDITION POSSIBLE CAUSES CORRECTION WIPERS INOPERATIVE IN HIGH POSITION 1. Faulty high speed circuit. 1. Test and repair the open high speed 2. Faulty multi-function switch. 2. Test and replace the multi-function 3. Faulty wiper high speed brush. 3. Test and replace the wiper motor as WIPERS DO NOT PARK AFTER OPERATING 1. Faulty motor feed circuit. 1. Test and repair the open fused ignition 2. Faulty park switch output circuit. 2. Test and repair the open or shorted cir- 3. Faulty wiper relay. 3. Test and replace the wiper relay as re- 4. Faulty park switch. 4. Test and replace the wiper motor as WASHERS INOPERATIVE 1. Faulty washer pump ground cir- 1. Test and repair the open ground circuit 2. Faulty washer pump feed circuit. 2. Test and repair the open circuit be- 3. Faulty washer pump motor. 3. Test and replace the washer pump as 4. Faulty muli-function switch. 4. Test and replace the multi-function AUTOMATIC WIPER SYSTEM CONDITION POSSIBLE CAUSES CORRECTION WIPERS INOPERATIVE IN ALL SWITCH POSITIONS 1. Faulty or missing fuse. 1. Test and replace the fuse as required. 2. Faulty wiper motor ground circuit. 2. Test and repair the open ground circuit 3. Faulty wiper motor. 3. Test and replace the wiper motor as 4. Faulty multi-function switch feed 4. Test and repair the open fused ignition 5. Faulty multi-function switch. 5. Test and replace the multi-function 6. Faulty rain sensor control module 6. Test and repair the open ground circuit 7. Faulty rain sensor control module 7. Test and repair the open fused ignition 8. Faulty rain sensor control mod- 8. Test and replace the rain sensor control VA WIPERS/WASHERS 8R - 7 |
