VEHICLE THEFT SECURITY TABLE OF CONTENTS page page VEHICLE THEFT SECURITY . . . . . . . . . . . . . . . . . . . . . . . . . . 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 DIAGNOSIS AND TESTING - VEHICLE THEFT . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 INTRUSION SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 . . . . . . . . . . . . . . . . . . . . . . . . . . 2 SECURITY SYSTEM MODULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 . . . . . . . . . . . . . . . . . . . . . . . . . . 2 SENTRY KEY REMOTE ENTRY MODULE . . . . . . . . . . . . . . . . . . . . . . . . . . 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 . . . . . . . . . . . . . . . . . . . . . . . . . . 4 SIREN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 . . . . . . . . . . . . . . . . . . . . . . . . . . 4 TRANSPONDER KEY . . . . . . . . . . . . . . . . . . . . . . . . . . 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 VEHICLE THEFT SECURITY DESCRIPTION A vehicle theft alarm with a battery powered siren is available as an option and includes interior moni- The alarm will sound when any of the following occur: • A door is opened • A door is unlocked from inside the vehicle • The hood is opened • The vehicle is raised at the front or rear • The trailer wire harness is disconnected • Movements inside the vehicle • The central locking is unlocked by a key at any other door than the driver’s door The alarm is functional about 30 seconds after the vehicle is locked using the RKE transmitter or the OPERATION The anti-theft alarm is activated/deactivated by locking/unlocking the vehicle with the remote trans- The interior monitoring system included in the anti-theft alarm is based on ultrasonics and triggers an alarm if an object intrudes the interior of the To switch off the interior monitoring system and / or the anti-tow away protection, a switch with LED The anti-theft alarm control unit includes a gradi- ent indicator as anti-tow away protection. The gradi- DIAGNOSIS AND TESTING - VEHICLE THEFT Any diagnosis of the Vehicle Theft Security system should begin with the use of a diagnos- INTRUSION SENSOR REMOVAL (1) Disconnect and isolate the battery negative cable. (2) Insert the tip of a small flat-bladed screwdriver into the notch on one edge of the dome lamp/intru- VA VEHICLE THEFT SECURITY 8Q - 1 |
