(4) Open up bleeder, then have a helper press down the brake pedal. Once the pedal is down close the bleeder. Repeat bleeding until fluid stream is STANDARD PROCEDURE - PRESSURE BLEED- Use approved brake fluid (Refer to LUBRICATION & MAINTENANCE/FLUID TYPES - DESCRIP- TION). Use fresh, clean fluid from a sealed container Follow the manufacturers instructions carefully when using pressure equipment. Do not exceed the Fill the bleeder tank with recommended fluid and purge air from the tank lines before bleeding. Do not pressure bleed without a proper master cyl- inder adapter. The wrong adapter can lead to leak- HYDRAULIC / MECHANICAL SPECIFICATIONS SPECIFICATIONS - TORQUE CHART TORQUE SPECIFICATIONS DESCRIPTION N·m Ft. Lbs. In. Lbs. Brake Lines 14 — 124 Master Cylinder To Brake Booster Nut 28 — 248 Brake Caliper Adapter Rear M12 X 1.5 Bolt 90 66 — Brake Caliper Adapter Rear M14 X 1.5 Bolt 170 125 — Brake Caliper Adapter Front 170 125 — Disc Brake Rotor Locking Bolt Front or Rear 23 — 204 Wear Indicator To Caliper Bolt Front or Rear 10 — 89 Pedal Bracket to Firewall 23 — 204 Fig. 1 Bleed Hose Setup 1 - BLEED HOSE VA BRAKES - BASE 5 - 5 |
