Mercedes-Benz ML320. Service manual - part 701





MODELS 163.113 #A as of 289565, 163.113 #X as of 754620, 163.154 /174 #A as of 289565,
163.128/157/175


Fig. 159: Identifying Footwell Flap Actuator Motor Components





Remove/install





1

Remove cover below
instrument panel (left)



AR68.10-P-
1500GH


2.1 Remove electronic
transmission control
(ETC) control module



Only on models fitted with
automatic transmission.

AR27.19-P-
1719GH


3

Disconnect interior and
taillamp wiring harness
connector, cockpit(X18)from
bracket(1)





4

Remove screws (2)





5

Move bracket (1) downwards
and put to one side





6

Disconnect connector (3)





7

Remove screws (4) on defroster
vent flap actuator motor
(M2/15) from heater housing





8

M2/15 Remove footwell flap

 Installation: Adjust footwell

flap actuator motor (M2/15) to the





2001 Mercedes-Benz ML320

1998-2005 HVAC Climate Control - 163 Chassis



me



REMOVE/INSTALL REAR SHUTOFF FLAP ACTUATOR MOTOR - AR83.30-P-2008GH

MODEL 163.113 /154 /174 #A as of 289565, 163.113 #X as of 754620, 163.128/157/175

Fig. 160: Identifying Rear Shutoff Flap Actuator Motor Components

actuator motor

0 position using STAR
DIAGNOSIS.

9

Install in the reverse order









Remove/install





1

Remove cover below
instrument panel (left)



AR68.10-P-
1500GH


2.1 Remove electronic
transmission control
(ETC) control module



Only on models fitted with
automatic transmission.

AR27.19-P-
1719GH


3

Disconnect interior and taillamp
wiring harness connector,
cockpit(X18)from bracket(1)





4

Remove screws (2)





5

Move bracket (1) downwards
and put to one side





6

Disconnect plug (3)





Remove screws (4) on rear



2001 Mercedes-Benz ML320

1998-2005 HVAC Climate Control - 163 Chassis



me



REMOVE/INSTALL FRESH AIR/RECIRCULATED AIR STEPPER MOTOR - AR83.30-P-2010GH

MODEL 163.113 /128 /136 /154 /157 /172 /174 /175 with CODE (580) Air conditioning or Tempmatic for
USA


Shown on model 163 up to VIN A289564, X754619

Fig. 161: Identifying Fresh Air/Recirculated Air Stepper Motor Components (Shown On Model 163 Up
To VIN A289564, X754619)


7

shutoff flap actuator motor
(M2/12) from heater housing





8

Remove rear shutoff flap
actuator motor (M2/12)

 Installation: Adjust rear

shutoff flap actuator motor
(M2/12)to 0 position using STAR
DIAGNOSIS.



9

Install in the reverse order









Remove/install





1

Remove instrument panel



AR68.10-P-
1000GH


2

Remove front passenger airbag unit



AR91.60-P-
0680GH


Disconnect connector (4) from recirculated



2001 Mercedes-Benz ML320

1998-2005 HVAC Climate Control - 163 Chassis



me



REMOVING AND INSTALLING BLENDING AIR INCREMENT ADJUSTMENT MOTOR - AR83.30-P-2020GH

MODEL 163.113 /128 /136 /154 /157 /172 /174 /175 with CODE (580) Air conditioning or Tempmatic for
USA


Shown on model 163 up to VIN A289564, X754619

Fig. 162: Identifying Blending Air Increment Adjustment Motor Components (Shown On Model 163 Up
To VIN A289564, X754619)


3

air flap actuator motor (M39)





4

Unscrew screws (3) from recirculated air
flap actuator motor (M39)

 3 screws are fitted as of

VIN A289565 X754620.



5

Detach recirculated air flap actuator motor
(M39)from AC housing (1)





6

Install in the reverse order









Remove/install





1

Remove instrument panel



AR68.10-P-
1000GH


2

Disconnect connector (4) from blend air
flap actuator (M16/8)





3

Unscrew screws (3) from blend air flap

screws are fitted as of VIN
A289565 X754620.





2001 Mercedes-Benz ML320

1998-2005 HVAC Climate Control - 163 Chassis
