Mercedes-Benz ML320. Service manual - part 598





Fig. 609: Identifying Blade Holder with Clamping Pliers (220 589 01 99 50)

Fig. 610: Identifying MQS Blade (220 589 01 99 60)

Secondary release on version with secondary retainer (Siemens ELO)

1. Using a suitable tool, grasp the secondary retainer (1) and push it in the direction shown by the arrow into

the pre-locking position (first detent) (1a).

Shown on 2-pin Siemens ELO coupling

Fig. 611: Locating Secondary Retainer (Shown On 2-Pin Siemens ELO Coupling)



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



Secondary release on version with retaining clamp (Siemens ELO)

1. Using a suitable tool, pry up the side clips of the retaining clamp (1).

2. Move retaining bracket (1) upward.

3. Detach the retaining bracket (1).

Shown on a 10-pin Siemens ELO coupling

Fig. 612: Locating Retaining Clamp & Bracket (Shown On A 10-Pin Siemens ELO Coupling)

Unpin female contacts from the coupling (Siemens ELO)

1. Position the blade holder with clamping pliers

 and MQS blade

 at the side of the spring shackle for

the female connector (2).

2. Press the spring tab of the female contact downward and push the female contact (2) out of the chamber

of the female contact housing (1). Tug the corresponding cable at the same time to assist the unpinning
procedure.

Shown on a 10-pin Siemens ELO coupling

Fig. 613: Unpin Female Contacts From Coupling (Siemens ELO)

REMOVE CONTACTS FROM SIEMENS ELO PLUG - AR00.19-P-0120-24A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



Fig. 614: Identifying Wiring Harness Repair Kit, Supplement For Passenger Cars (220 589 04 99 00)

Fig. 615: Identifying Wiring Harness Repair Kit, Basic (000 589 13 99 00)
