Remove female contact

AR00.19-P-0120-02A



220 545 40 28

4-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02A



220 545 46 28

5-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02B



220 545 51 28

6-pin SLK coupling, -, -



Remove female contact

AR00.19-P-0120-02A



220 545 52 28

6-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



220 545 53 28

2-pin SLK coupling, -, -



Remove female contact

AR00.19-P-0120-02A



220 545 53 28

2-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



220 545 55 28

2-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02A



220 545 57 28

4-pin JPT plug, -, -



Remove contact pin

AR00.19-P-0120-08A



220 545 58 28

4-pin JPT plug, Z, water
blue



Remove contact pin

AR00.19-P-0120-08A



220 545 65 28

10-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



220 545 66 28

10-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



220 545 67 28

10-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A

220 545 68 28

2+8-pin SLK, LSK
coupling, B, white





Remove SLK female
contact

AR00.19-
P-0120-
02A



Remove LSK female
contact

AR00.19-
P-0120-
12A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me





220 545 69 28

6-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02A



220 545 71 28

2 x 3-pin SLK coupling,
A, black



Remove female contact

AR00.19-P-0120-02A



220 545 74 28

10-pin Siemens ELO
coupling, A, yellow



Remove female contact

AR00.19-P-0120-23A



220 545 75 28

10-pin Siemens ELO
plug, A, yellow



Remove contact pin

AR00.19-P-0120-24A



220 545 81 28

2 x 2-pin SLK plug, A,
black



Remove contact pin

AR00.19-P-0120-01A



220 545 82 28

2 x 2-pin SLK plug, B,
white



Remove contact pin

AR00.19-P-0120-01A



220 545 84 28

2 x 5-pin SLK coupling,
A, black



Remove female contact

AR00.19-P-0120-02A



220 545 85 28

2-pin Siemens ELO
coupling, A, yellow



Remove female contact

AR00.19-P-0120-23A



220 545 86 28

2-pin Siemens ELO plug,
A, yellow



Remove contact pin

AR00.19-P-0120-24A



220 545 90 28

3-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



220 545 92 28

14-pin SLK plug, A,
black



Remove contact pin

AR00.19-P-0120-01A



220 545 94 28

9-pin JPT coupling, A,
black



Remove female contact

AR00.19-P-0120-07A



220 545 95 28

9-pin JPT coupling, B,
white



Remove female contact

AR00.19-P-0120-07A

220 545 96 28

4-pin MT -3, JPT
coupling, A, black





Remove MT -3 female
contact

AR00.19-
P-0120-
06A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONTACT PART NUMBERS - GF00.19-P-8100CE

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 230

SENSOR LAMINATED CONTACT, CONNECTOR FAMILY - GF00.19-P-8101A

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Sensor spade-type contact, Design 97 contact family



Remove JPT female
contact

AR00.19-
P-0120-
07A



220 545 99 28

14-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02A



Part number

Designation, Coding,
Color





230 540 00 81

2-pin MQS coupling, C,
black



Remove female contact

AR00.19-P-0120-04A

230 545 01 28

47-pin MQS, MCP
coupling, A, black





Remove MQS female
contact

AR00.19-
P-0120-
04B

Remove MCP female
contact

AR00.19-P-0120-09A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



Fig. 51: Identifying 2-Pin Slk Coupling
