soiling.

13 The ground terminal of the welder must not be attached to the transmission. The welding current can
cause arcing at the bearing points inside the transmission. The structural changes that this causes lead to
premature failure of the equipment.

CHASSIS NUMBER BREAKDOWN - AH00.00-P-2000-01GH

Model 163

 Valid for all ECE vehicles without code 986 except NAFTA.

Fig. 1: Identifying Chassis Number (Valid For All ECE Vehicle Without Code 986 Except NAFTA)

 Valid for all NAFTA vehicles and ECE vehicles with code 986



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



Fig. 2: Identifying Chassis Number (Valid For All NAFTA And ECE Vehicles With Code 986)

LAYOUT OF VEHICLE DATA CARD - AH00.00-P-3000-01B

Models 123, 124, 126, 129, 140, 163, 168, 170, 201, 202, 208, 210, 215, 220 as of 01.01.78

Front of vehicle data card



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



Fig. 3: Layout Of Vehicle Data Card - Front Of Vehicle Data Card

Back of vehicle data card

Fig. 4: Layout Of Vehicle Data Card - Back Of Vehicle Data Card

 The vehicle data card with all the essential data is required to be able to find the correct replacement parts for

a particular vehicle.

This requires data that cannot be accommodated on the vehicle (e.g. on the model plate) any more.

The vehicle data card format DIN A5 (approx. 21.0 x 14.5 cm) was introduced in January 1978 as a standard for
all manufacturing plants. Only the vehicle data card that is glued into the service booklet has a size of approx.
10.0 x 19.5 cm. The back of this card remains empty. As of 01.09.2005, the vehicle data card is no longer glued
into the service booklet.

Field contents

Comments

Chassis number

The chassis or vehicle identification number is the
identification number of every vehicle. It also
provides information on the version and the
manufacturing plant of this vehicle. The preceding
letter combination WDB is the World Manufacturer
Code and means "Westdeutschland Daimler-
Benz" ("Western Germany Daimler-Benz"). It has no
meaning as far as replacement parts are concerned.



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



KEY TO BODY PLATE - AH00.00-P-4000-01A

Model 100, 107, 108, 109, 111, 112, 113, 114, 115, 116, 123, 124, 126, 129, 140, 163, 168, 170, 201, 202, 208,
210

Engine number

The engine number is the identification number for
every engine. It also provides information on the
version of this engine.

Sales Designation

Is used for several model series. 240 D is used for
instance for models 115, 123. Is used to determine a
microfiche of the replacement part literature only in
combination with the model (= the first 3 digits of
the chassis number).

Transmission number

The complete transmission number is specified on
the data card. It is the identification number or every
transmission.

Groups and SA (optional equipment) numbers (as
of 1983, not on vehicle data card in maintenance
booklet)

The special equipment numbers are arranged based
on ascending groups. Special equipment numbers are
listed several times, if they pertain to several groups.
e.g.: special equipment number 56 149/2 can appear
in groups 67, 72, 73, 74.

Lamps

It is essential to state the manufacturer for
determining headlamp parts, as different
manufacturer's parts are not completely
interchangeable.

SA (optional equipment) code number

The 3-digit codes for special equipments are written
in ascending order in lines. The slash that was used
earlier is omitted. Thus, 410 corresponds to 41/0, 466
corresponds to 46/6 etc. The meaning of the special
equipment code can be found in the "Code list of
special versions - Passenger cars".

Equipment

Code for color and material dependent interior trim.

Paintwork

Color code for the original paintwork, single-
colored. In the event of multicolor painting,
additional codes are listed in fields 32-35.

Lock system number (not on all vehicle data cards) The lock system numbers of master and secondary

keys are identical.
Differentiating characteristic H=master key,
N=secondary key. The lock system number has to be
specified when ordering spare keys or locks for
certain vehicles in order to sustain a consistent
closing system.
