Mercedes-Benz ML320. Service manual - part 457

Engine 113 in model 129, 202, 208, 210
Engine 113 (except 113.965/981) in model 163

24.1

Remove oil
reservoir on
power steering
pump (11)

Model 163

Removal: Extract oil from reservoir. Remove circlip.
Installation: Replace sealing ring. Check that circlip is

correctly seated.

Power steering -
checking and
correcting oil
level

AP46.00-P-
4611BB

Hand pump

Fig. 95

24.2

Detach power
steering pump
(11) with oil
reservoir.

Do not disconnect lines.

*BA46.30-P-
1005-01A

*BA46.30-P-
1010-01A

*BA46.30-P-
1010-01C

25.1

Detach guide
pulley at timing
case cover

Model 230.474

*BA13.25-P-
1008-01D

25.2

Take off guide
pulley (15) at
coolant pump

Except model 230.474

Take plastic cover off guide pulley.

*BA20.10-P-
1001-01C

*BA20.10-P-
1001-01M

26.1

Remove
compressor

Engine 112.960 in model 170.466
Engine 113.992 in model 230.474

AR09.50-P-
4705SVK

Remove air pump
(20)

Engine 112 (except 112.960) in model 170
Engine 112 in 163, 202, 208, 210
Engines 113 in 163, 202, 208, 210

AR14.30-P-
7251A

Engine 112.922 in model 220.063

AR14.30-P-
7251AA

Engine 112.923 in model 129.059
Engine 112.943 in model 129.064
Engine 112.944 in model 220.065 /165
Engine 112.972 in model 220.067 /167
Engine 112.975 in model 220.087 /187
Engine 113.941 in models 220.070/170
Engine 113.948 in model 220.083 /183
Engine 113.960 in model 220.075/175
Engine 113.960 in model 215.375
Engine 113.961 in model 129.068
Engine 113.963 in models 230.475
Engine 113.966 in model 220.084 /184

2001 Mercedes-Benz ML320

1998-2005 ENGINE Complete engine - 163 Chassis

Engine 113.992 in model 230.474

AR14.30-P-
7251RVK

Separate electrical
line from coolant
temperature
sensor

Unscrew bolts
(21) of cylinder
head to timing
case cover on
right and left

*BA01.40-P-
1002-01C

Remove screws
of the timing case
cover

Installation: Apply sealant to marked bolts, observing

the bolt diagram for the timing case cover: ?

*BR00.45-Z-
1015-01A

Bolt diagram for timing case cover engine 112, 113

AR01.40-P-
8000-01B

Bolt diagram for timing case cover engine 113.992,

AR01.40-P-
8000-01RVK

*BA01.40-P-
1001-01C

*BA01.40-P-
1002-01C

Take off timing
case cover

Installation: The bolt threads for the coolant pump,

the belt tensioning device, and the power steering pump
are not cut into a new timing case cover. For this reason,
use new self-tapping bolts in combination with a new
timing case cover for attaching the coolant pump, the belt
tensioning device and the power steering pump. Pay
attention to tightening torque with non-pre-tapped threads.

*BA13.25-P-
1001-01D

*BA13.25-P-
1001-01M

*BA13.25-P-
1005-01D

*BA13.25-P-
1006-01D

*BA13.25-P-
1007-01D

*BA20.10-P-
1001-01C

*BA20.10-P-
1001-01M

*BA20.10-P-
1002-01C

*BA20.10-P-

2001 Mercedes-Benz ML320

1998-2005 ENGINE Complete engine - 163 Chassis

1002-01M

*BA20.10-P-
1003-01C

*BA20.10-P-
1003-01M

*BA20.10-P-
1004-01C

*BA20.10-P-
1004-01M

*BA46.30-P-
1010-01A

*BA46.30-P-
1010-01C

Clean sealing surfaces, apply sealant only to specified
surfaces in form of bead with height and width of 2.0 mm
± 0.5 mm. The sealant must be applied within 10 minutes!
The silicone bead must not be spread!

*BR00.45-Z-
1013-01A

Notes on
application of
sealant to timing
case cover

AH01.40-P-
1000-01B

Installation: If sealing compound enters the oil ducts,

this is carried by the oil flow and will clog the oil supply
bores.



Do not damage cylinder head gasket.



Replace seals on timing case (19).



Replace front crankshaft radial sealing ring: ?

Engine 112 in model 129
Engine 113 in model 129
Engine 113 in model 163, 202, 208, 210

AR03.20-P-
3000B

Engine 112 in models 170, 202, 208, 210, 220
Engine 113 in model 215, 220
Engine 113.981 in model 163.174
Engine 113.963 in models 230.475
Engine 113.992 in model 230.474

AR03.20-P-
3000BA

Install in the
reverse order

Risk of accident
caused by vehicle
starting off by
itself when engine
is running. Risk
of injury caused
by contusions and
burns during
starting procedure

Secure vehicle to prevent it from moving by itself.
Wear closed and snug-fitting work clothes.
Do not grasp hot or rotating parts.

AS00.00-Z-
0005-01A

2001 Mercedes-Benz ML320

1998-2005 ENGINE Complete engine - 163 Chassis

Crankcase, timing case cover, end cover

or when working
near the running
engine

Run engine and
inspect for leaks

Inspect cooling
system for leaks

First warm up engine to operating temperature.

Engine 112 (except 112.947 /960)
Engine 113 (except 113.992 /963)

AR20.00-P-
1010HA

Engine 112 in Model 170

AR20.00-P-
1010P

Perform basic
programming

Model 215, 220
All except model 215, 220: Code radio and normalize
power window.
Vehicles with stationary heater: adjust time display on
stationary heater.

AR00.19-P-
0200M

36.1

Read out fault
memory and erase

All except models 215, 220, 230

Stored faults which can result from cables being

disconnected or from simulation during removal and
installation or test work, have to be processed and erased
in the fault memories after completing the work: ?
Diagnosis Manual Volume 2 Index 0:
Connecting and using test equipment.

36.2

Read out fault
memory with
STAR
DIAGNOSIS and
erase if necessary.

Model 220, 230

Connect STAR
DIAGNOSIS and
read out fault
memory

AD00.00-P-
2000-04A

STAR DIAGNOSIS diagnosis system

Stored faults which can result from removal and

installation or test work, have to be processed and erased
in the fault memories after completing the work.

*WH58.30-Z-
1048-13A

Number

Designation

Engine 112
except 112.951/
976

Engine 112.951/
976

Engine 113.987/
988/990/
991/993

BA01.40-P-
1001-01C

Timing case
cover to
crankcase

Nm 20

BA01.40-P-

Bolt, cylinder

Nm 20

2001 Mercedes-Benz ML320

1998-2005 ENGINE Complete engine - 163 Chassis
