Mercedes-Benz ML320. Service manual - part 389





Fig. 22: Identifying Camshaft Hall Sensor - Shown On Engine 112 In Model 220

 Position sensor

TEST ROTORLESS HIGH VOLTAGE DISTRIBUTION - AR15.10-P-3000WA

ENGINE 112.923 /943, 113.961 in MODEL 129

ME-SFI fuel injection and ignition system with engine diagnostic tester Datascope D 980

Fig. item etc.

Work instructions







Camshaft Hall sensor to
cylinder head



*BA15.10-P-1002-03A

B6/1

Camshaft Hall sensor

 Replace O-ring.



Number

Designation

Engines
112.910/911/
912/913/914/
915/916/917/
920/921/922/
923/940/941/
942/943/944/
945/946/947/
949/951/953/
954/955/960/
961/970/972/
973/975/976

Engines
113.940/941/
942/943/944/
948/960/961/
962/963/964/
965/966/967/
968/969/971/
980/981/982/
984/986/992/
993/995

Engine
113.987/
988/990/
991

BA15.10-P-
1002-03A

Camshaft Hall
sensor to
cylinder head

Nm 8

8

8



2001 Mercedes-Benz ML320

1998-2005 ENGINE Electrical System - Engine - 163 Chassis



me



ENGINE 112.942, 113.942/965/981 in MODEL 163

ME-SFI fuel injection and ignition system with engine diagnostic tester Datascope D 980

ENGINE 112.910 /920, 113.944 in MODEL 202

ME-SFI fuel injection and ignition system with engine diagnostic tester Datascope D 980

ENGINE 112.940, 113.943 in MODEL 208

ME-SFI fuel injection and ignition system with engine diagnostic tester Datascope D 980

ENGINE 112.911 /921 /941, 113.940/980 in MODEL 210

ME-SFI fuel injection and ignition system with engine diagnostic tester Datascope D 980

ENGINE 112.922 /944, 113.941 /960 in MODEL 220

ME-SFI fuel injection and ignition system with engine diagnostic tester Datascope D 980



Risk of accident.
Accidents may result if the
vehicle starts off
unintentionally with the
engine running. Risk of
injury
 as working around
the engine during start-up
or while running may result
in contusions and burns

Secure vehicle to prevent
it from moving. Wear
closed and snug-fitting
work clothes. Do not
grasp hot or rotating parts.

AS00.00-Z-0005-01A



Risk of death. Death may
result if contact is made
with parts carrying high
voltages.

Do not touch parts
carrying high voltages.
Persons who wear
electronic implants (e.g.
heart pacemakers) must
not carry out work on the
ignition system.

AS15.10-Z-0001-01A

1

Remove air cleaner





2

Remove trim panel of
cylinder head cover





3

Test ignition circuits

 Datascope engine

diagnostic tester

*WH58.30-Z-1003-13A



General information on
rotorless high voltage
distribution



AH15.10-P-1002-01WA



General information on
testing rotorless high



AH15.10-P-1003-01W



2001 Mercedes-Benz ML320

1998-2005 ENGINE Electrical System - Engine - 163 Chassis



me



Commercially available tools

REMOVE/INSTALL IGNITION COILS - AR15.12-P-2003A

ENGINE 112.910 in MODELS 202.026 /086

ENGINE 112.920 in MODELS 202.029 /089

ENGINE 112.921 in MODELS 210.063 /081 /263 /281

ENGINE 112.922 in MODELS 220.063 /163

ENGINE 112.923 in MODEL 129.059

ENGINE 112.940 in MODELS 208.365 /465

ENGINE 112.941 in MODELS 210.065 /082 /265 /282

ENGINE 112.942 in MODEL 163.154

ENGINE 112.943 in MODEL 129.064

ENGINE 112.944 in MODELS 220.065 /165

ENGINE 112.945 in MODEL 463

ENGINE 113.940 in MODELS 210.070 /270

ENGINE 113.941 in MODELS 220.070 /170

voltage distribution





if necessary: ?
Test secondary side

 Secondary adapter

cable in place of kV
clamp.

 kV clamp in ignition

coil recess alternately at
ignition coil T1/1-T1/6 or
T1/8
Test primary side

 Primary adapter cable

alternatively at ignition
coil T1/1-T1/6 or T1/8



Number

Designation

WH58.30-Z-1003-13A

Engine tester



2001 Mercedes-Benz ML320

1998-2005 ENGINE Electrical System - Engine - 163 Chassis



me



ENGINE 113.960 in MODEL 215.375, 220.075 /175 /875

ENGINE 113.961 in MODEL 129.068

ENGINE 113.962 /982 in MODEL 463

ENGINE 113.980 in MODELS 210.074 /274

ENGINE 113.944 in MODELS 202.033 /093

ENGINE 113.942 in MODEL 163.172

ENGINE 113.943 in MODELS 208.370 /470

ENGINE 113.984 in MODELS 208.374

ENGINE 113.981 in MODEL 163.174

ENGINE 112.912 in MODELS 203.061 /261, 209.361 /461

ENGINE 112.946 in MODELS 203.064 /264

ENGINE 112.947 in MODEL 170.465

ENGINE 112.960 in MODEL 170.466

ENGINE 113.986 in MODEL 215.373, 220.073 /173

ENGINE 112.961 in MODELS 203.065 /265

ENGINE 113.965 in MODEL 163.175

ENGINE 113.963 in MODEL 230.475

ENGINE 113.968 in MODEL 209.375 /475

ENGINE 112.913 in MODELS 211.061 /261

ENGINE 112.949 in MODELS 211.065 /265

ENGINE 113.967 in MODELS 211.070 /270

ENGINE 113.992 in MODEL 230.474

ENGINE 113.987 in MODELS 209.376 /476



2001 Mercedes-Benz ML320

1998-2005 ENGINE Electrical System - Engine - 163 Chassis



me
