Mercedes-Benz ML320. Service manual - part 264





INTERIOR LIGHTS TEST OF ELECTRICAL SYSTEM - AD82.20-P-6000GH

MODEL 163

WIPER SYSTEM DIAGNOSIS CONTENTS - AD82.30-P-1002GHZ

MODEL 163



Connection and use of
test equipment



AD00.00-P-1000AZ



Interior lighting
diagnosis, previous
knowledge



AD82.20-P-2000GH

I

AAM voltage supply in
order



AD54.21-P-6000GH

II

Battery voltage 11-14 V





III

Fuses in order







Lighting equipment in
order







Testing





1

Front dome lamp, testing
electrical system of
interior lighting



AD82.20-P-6000-01GH

2

Rear lamps, testing
electrical system of
interior lighting



AD82.20-P-6000-02GH

3

Rear dome lamp, testing
electrical system of
interior lighting



AD82.20-P-6000-03GH

4

Front doors rotary
tumbler microswitch



AD80.20-P-6001-39GH

5

Rear doors rotary tumbler
microswitch



AD80.20-P-6001-40GH

6

Tailgate rotary tumbler
microswitch



AD80.20-P-6001-44GH

A2.2 [] 11a

Wiper system diagnosis,
previous knowledge



AD82.30-P-2002GH

A2.2 [] 12a

Wiper system diagnosis,
function check



AD82.30-P-3002GH

A2.2 [] 14a

Wiper system diagnosis,
troubleshooting



AD82.30-P-5002GH

A2.2 [] 21a

Wiper system, testing
electrical system



AD82.30-P-6002GH



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me



WIPER SYSTEM DIAGNOSIS PREVIOUS KNOWLEDGE - AD82.30-P-2002GH

MODEL 163

WIPER SYSTEM DIAGNOSIS OPERATIONAL CHECK - AD82.30-P-3002GH

MODEL 163



Risk of injury due to
getting jammed or
crushed in extreme cases
due to limbs being
severed by coming into
contact with the
windshield wiper
mechanism

Always remove the
ignition key when
working on the
windshield wiper
mechanism.

AS82.30-Z-0001-01A



Location of components,
front screen wiper system



GF82.30-P-0005-01GH



Location of components,
rear screen wiper system



GF82.30-P-0004-01GH



Function description,
wiper system



GF82.30-P-0003GH



Electric wiring diagram,
wiper system



PE82.30-P-2000F



Inter-function groups of
wiring diagrams



PE00.19-P-1100E



Connection and use of
test equipment



AD00.00-P-1000AZ



Diagnostic tools, wiper
system



AD54.21-P-2000-01GH



Location of components, wiper
system

Rear screen wiper
system

&(GF82.30-P-0004-
01GH
)





Front screen wiper
system

&(GF82.30-P-0005-
01GH
)



Wiper system diagnosis, previous
knowledge



AD82.30-P-2002GH



Prerequisites for function check





I

Battery voltage 11-14V





II

Fuses in order





III

AAM voltage supply in order



AD54.21-P-6000-
01GH


IV

Ignition (terminal 15) ON







Function check





Scope of test

Operation/requirement

Specified value

Possible cause/



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me



WIPER SYSTEM DIAGNOSIS TROUBLESHOOTING - AD82.30-P-5002GH

MODEL 163

Remedy

1 Tip wiping

Combination switch (S4) in "Tip
wiping" position

Wiper runs at slower
speed, while S4 is
operated

Cables
AD82.30-P-6002-
09GH

AD82.30-P-6002-
02GH

2 Front screen wiping
Stage 1

Combination switch (S4) in
"Wiping stage 1" position

Wiper runs at slow
speed

Cables
AD82.30-P-6002-
09GH

AD82.30-P-6002-
02GH

3 Front screen wiping
Stage 2

Combination switch (S4) in
"Wiping stage 2" position

Wiper runs quickly

Cables
AD82.30-P-6002-
09GH

AD82.30-P-6002-
02GH

4 Front screen
intermittent wiping

Combination switch (S4) in
"Intermittent wiping" position.

Wiper runs, an
interval of approx. 5
seconds follows each
complete wiping
process

Cables
Intermittent wiper
control
AD82.30-P-6002-
01GH

5 Front screen
washing

Combination switch (S4) in
"Washing" position

Windshield washer
pump (M5/1) operates
while S4 is actuated,
the wiper carries out
three more wiper
processes after the
switch is released

Cables
AD82.30-P-6002-
10GH

AD82.30-P-6002-
04GH


AD82.30-P-6002-
02GH

6 Rear screen
intermittent wipe

Operate "Rear screen intermittent
wipe" on rear window wiper/washer
switch (S78).

Rear wiper runs, an
interval of approx. 5
seconds follows each
complete wiping
process

Cables
AD82.30-P-6002-
06GH

AD82.30-P-6002-
08GH

7 Rear screen washing Operate "Rear screen intermittent

wipe" on rear window wiper/washer
switch (S78).

The rear window
washer pump (M5/3)
operates while S78 is
operated, the wiper
carries on wiping for
3 seconds after the
switch is released and
then stops in the rest
position

Cables
AD82.30-P-6002-
06GH

AD82.30-P-6002-
08GH


AD82.30-P-6002-
05GH



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me





Location of components,
wiper system

Front screen

&(GF82.30-P-0005-
01GH
)





Rear screen

&(GF82.30-P-0004-
01GH
)



Battery voltage 11-14 V







Fuses in order







AAM voltage supply in
order



AD54.21-P-6000-01GH



Troubleshooting





Complaint

Possible cause

Notes

Remedy/Test step

Front wiper system
inoperative

Combination switch (S4)



AD82.30-P-6002-09GH



Wiper motor (M6/1)



AD82.30-P-6002-
02GH
cables

Front wiper does not
function when washing
front screen

Wiper motor (M6/1)



AD82.30-P-6002-02GH

Windshield washer
pump does not function
when washing front
screen

Windshield washer pump
(M5/1)



AD82.30-P-6002-04GH

Front wiper does not
function in wiping stage
1 or stage 2

Combination switch (S4)



AD82.30-P-6002-09GH



Wiper motor (M6/1)



AD82.30-P-6002-02GH

Front wiper does not
function with
intermittent wiping

Combination switch (S4)
All-Activity Module (AAM)
(N10)



AD82.30-P-6002-01GH

Front wiper does not
stop in rest position
when switched off.

Cam-operated switch on
wiper motor (M6/1)



AD82.30-P-6002-07GH

Rear wiper system
inoperative

Rear window wiper/washer
switch (S78)
All-Activity Module (AAM)
(N10)



AD82.30-P-6002-06GH

Rear window wiper
inoperative

Rear window wiper/washer
switch (S78)



AD82.30-P-6002-06GH



Rear window wiper motor
inoperative (M6/4)



AD82.30-P-6002-08GH

Rear window wiper does
not function when
washing rear window

Rear window wiper/washer
switch (S78)



AD82.30-P-6002-06GH

Rear window wiper
cannot be switched off

Rear window wiper motor
relay (M6/4)



AD82.30-P-6002-
03GH
cables
