Mercedes-Benz ML320. Service manual - part 262





Parts ordering notes

NAVIGATION SYSTEM ERRONEOUS OR NO GUIDANCE - AF82.85-P-6061A

MODEL 163, 168, 170, 203, 208, 209, 210, 211, 215, 220, 230, 414, 463

phone calls are received.





2 Replace CD changer

 See parts ordering

notes.

AR82.64-P-7507GH

Part no.

Designation

Quantity

163 820 38 89

CD changer

1

Damage code

Cause

Remedy





Defective digitization of
map material

1 Perform test drive with
other vehicle





Possible switch-off or
falsification of GPS
signals during worldwide
crisis

 This must be

compared with the same
navigation system and the
same version of
navigation CD.





 The satellite signal

includes the time at
which the signal was sent

If the complaint is still

present: ?





The navigation processor
Calculate the
transmission time of the
signal resulting from the
satellite position and the
transmission time of the
GPS signal and can
therefore determine the
vehicle position (min. 3
satellites).

2 Perform test drive with
new navigation CD
version.





If the GPS signal is
falsified the transmitted
time from the satellites is
changed. A change of 10
ns corresponds to approx.
3 m position change

When the complaint is

eliminated, use new
navigation CD.







If the complaint is still

present: ?
3 Perform test drive with
other vehicle and
navigation system of





2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me



MCS MALFUNCTION - OCCASIONAL FAILURE OF STARGUIDE, SOUND OR CD CHANGER. DTC'S N1111, N1112, N1116
- AF82.95-P-6002A

MODEL 163.157 /174 /175 #A as of 409851 up to 419036 with CODE (349) E Call emergency call system
with CODE (522) Modular control system (MCS) radio USA


Operation no. of operation texts or standard texts and flat rates

other manufacturer.





 If the complaint does

not occur during the test
drive, a digitization error
on the navigation CD is
present: ?
4 Inform customers of
facts and manufacturer of
CD with report form

 If the correct report

form from the
manufacturer is not
available, please contact
corresponding service
center (telephone number
is given on label of
navigation CD):







5 Check antenna system
for proper function and
repair according to
condition.







 If the antenna system

is okay and errors also
occur on other vehicles: ?
6 Inform customer that
the GPS system is
operated by the US
military



Range

Op. no.

Operation text

Time

Acc. no.

Code

P

023843

FLASH TELEAID
EMERGENCY CALL
SYSTEM CONTROL
MODULE

008 WU/0.7 h 82 876 90

-

Damage code

Cause

Remedy





Data transmission of D2B
ring is interrupted. The E-
call control module is in a

Recode E-call control
module: ?





2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me



bypass mode.



 The E-call control

module is not recognized
by the D2B ring.
The emergency call
function is not affected,
this function is
INDEPENDENT of the
D2B ring.

1 Connect STAR-
DIAGNOSIS.







2 Select "Information and
communication" in the
"Control module" menu







3 Select "TELE AID, E-
call or telephone -
telematic system (K-
line)".







4 Select "Control module
version".







5 Check "Software
version".

 If the "software

version" has the status of
04/03 , NO FURTHER
STEPS ARE
REQUIRED. If "Software
version" has the status of
02/02 ?
6 Select "Program control
module according to
factory data" in "TELE
AID" menu.







7 Follow instructions until
procedure is completed.

 Complete DAS and

remove before SOS
button is pressed.







8 Connect STAR-
DIAGNOSIS.







9 Perform short test and
erase all DTC's.

 DTC's are stored in

MCS and E-call control
module.







10 Select "Control module
version" and "Software
version" in "TELE AID"





2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me



SELF-DIAGNOSTIC SYSTEM

INTERIOR LIGHTS DIAGNOSIS CONTENTS - AD82.20-P-1000GHZ

MODEL 163

INTERIOR LIGHTS DIAGNOSIS PREVIOUS KNOWLEDGE - AD82.20-P-2000GH

MODEL 163

INTERIOR LIGHTS DIAGNOSIS OPERATIONAL CHECK - AD82.20-P-3000GH

menu and ensure that
software status 04/03 is
available.





11 Complete DAS and
finish STAR-
DIAGNOSIS.



A2.20 [] 11b

Interior lighting
diagnosis, previous
knowledge



AD82.20-P-2000GH

A2.2 [] 12b

Interior lighting
diagnosis, function check



AD82.20-P-3000GH

A2.2 [] 14b

Interior lighting
diagnosis, troubleshooting



AD82.20-P-5000GH

A2.2 [] 21b

Interior lighting
diagnosis, testing
electrical system



AD82.20-P-6000GH



Function description,
interior lighting



GF82.20-P-0002GH



Location of components,
interior lighting



GF82.20-P-0002-01GH



Electric wiring diagram,
interior lighting



PE82.20-P-2000G



Inter-function groups of
wiring diagrams



PE00.19-P-1100E



Connection and use of
test equipment



AD00.00-P-1000AZ



Diagnostic tools, interior
lighting



AD54.21-P-2000-01GH



Assignment of coupling
on door separation points



AD72.29-P-2000-03GH



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me
