Mercedes-Benz ML320. Service manual - part 97





215

Operation

At the gas station

Replace the fuel cap by turning it to the
right.

You will hear when the fuel cap is tight-
ened.

Close the fuel filler flap.

Check regularly and before a long trip

Open the hood (

page 217)

1 Engine oil level
2 Coolant level

For normal replenishing, use water (po-
table water quality). More information
on the coolant level can be found in the
“Operation” section (

page 222).

3 Brake fluid
4 Windshield washer system and

headlamp cleaning system*
More information on filling the reser-
voir can be found in the “Operation”
section (

page 224).

i

Use only premium unleaded gasoline
with a minimum Posted Octane Rating
of 91  (average of 96 RON/86 MON).
Information on gasoline quality can
normally be found on the fuel pump.

More information on gasoline can be
found in the Factory Approved Service
Products pamphlet.

i

Leaving the engine running and the fuel
cap open can cause the yellow fuel
tank reserve warning lamp to flash and
the

? lamp to illuminate.

See also “Practical hints” section
(

page 248).

216

Operation

At the gas station

Engine oil level

More information on engine oil see “Engine
oil” (

page 218).

Vehicle lighting

Check function and cleanliness. More in-
formation on replacing light bulbs can be
found in the “Practical hints” section
(

page 266).

Tire inflation pressure

More information on tire inflation pressure
can be found in the “Operation” section
(

page 227).

!

If you find that the brake fluid in the
brake fluid reservoir has fallen to the
minimum mark or below, have the
brake system checked for brake pad
thickness and leaks immediately. Noti-
fy an authorized Mercedes-Benz Light
Truck Center immediately. Do not add
brake fluid as this will not solve the
problem. For more information, see
“Practical Hints” (

page 245).

217

Operation

Engine compartment

Engine compartment

Hood

Opening

1 Release lever

Pull release lever 1 downwards.

The hood is unlocked. Handle 2 pro-
trudes slightly from the radiator-grille.
If not, lift the hood slightly.

2 Handle for opening the hood

Pull handle 2 to its stop out of the
radiator-grille.

Pull up on the hood and then release it.

The hood will be automatically held
open at shoulder height by gas-filled
struts.

Warning!

G

Do not pull the release lever while the vehi-
cle is in motion. Otherwise the hood could
be forced open by passing air flow.

!

To avoid damage to the windshield wip-
ers or hood, never open the hood if the
wiper arms are folded forward away
from the windshield.

Warning!

G

To help prevent personal injury, stay clear of
moving parts when the hood is open and the
engine is running. Make sure the hood is
properly closed before driving. When closing
the hood, use extreme caution not to catch
hands or fingers.

The radiator fan may continue to run for ap-
proximately 30 seconds or even restart af-
ter the engine has been turned off. Stay
clear of fan blades.

컄컄

218

Operation

Engine compartment

Closing

Let the hood drop from a height of ap-
proximately 1 ft (30 cm).

The hood will lock audibly.

Check to make sure the hood is fully
closed.

If you can raise the hood at a point
above the headlamps, then it is not
properly closed. Open it again and let it
drop with somewhat greater force.

Engine oil

The amount of oil your engine needs will
depend on a number of factors, including
driving style. Higher oil consumption can
occur when

the vehicle is new

the vehicle is driven frequently at
higher engine speeds

Engine oil consumption checks should only
be made after the vehicle break-in period.

Warning!

G

If you see flames or smoke coming from the
engine compartment, or if the coolant tem-
perature gauge indicates that the engine is
overheated, do not open the hood. Move
away from vehicle and do not open the hood
until the engine has cooled. If necessary,
call the fire department.

Warning!

G

The engine is equipped with a transistorized
ignition system. Because of the high voltage
it is dangerous to touch any components (ig-
nition coils, spark plug sockets, diagnostic
socket) of the ignition system

with the engine running

while starting the engine

if ignition is “on” and the engine is
turned manually

Warning!

G

Be careful that you do not close the hood on
anyone.

!

Do not push the hood closed manually,
as this could damage it.

i

Do not use any special lubricant addi-
tives, as these may damage the drive
assemblies. Using special additives not
approved by Mercedes-Benz will
restrict your warranty entitlement.

More information on this subject is
available at any Mercedes-Benz Light
Truck Center.

컄컄
