Mercedes-Benz ML320. Service manual - part 84





163

Controls in detail

Loading

Installing cargo floor plates

1 Opening
2 Pins
3 Attachment opening
4 Latch

Grip into opening 1 and guide pins 2
into attachment opening 3.

The center pin must snap into place in
latch 4.

Roof rack*

Roof rails

For further information, inquire at your
Mercedes-Benz Light Truck Center.

Warning!

G

Take into consideration that when the roof
rack is loaded, the handling characteristics
are different from those when operating the
vehicles without the roof rack loaded.

The maximum roof load when using roof
rack systems is 220 lbs (100 kg).

!

Attach roof racks to the roof rails only.

Use only those roof racks approved by
Mercedes-Benz for your vehicle model.
Follow manufacturer’s installation in-
structions.

The vehicle could otherwise be dam-
aged.

164

Controls in detail

Useful features

Useful features

Interior storage spaces

Glove box

1 Glove box lid release
2 Glove box lid

Opening the glove box

Grab in recess and pull lid release 1.

The glove box lid 2 opens downward.

Closing the glove box

Push glove box lid up to close.

Storage compartment under front
passenger seat*

The storage compartment is lockable with
its separate key.

1 Lock cylinder
2 Handle

Locking and unlocking the storage com-
partment

Turn the key clockwise.

The storage compartment is locked.

Turn the key counterclockwise.

The storage compartment is unlocked.

Warning!

G

To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when stowing objects in the vehicle. Put lug-
gage or cargo in the cargo compartment if
possible. Do not pile luggage or cargo higher
than the seat backs.

Always use partition net when transporting
cargo. Partition net cannot secure hard or
heavy objects.

Parcel nets cannot secure hard or heavy ob-
jects.

Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during
an accident.

i

The opened glove box is illuminated
with the key in steering lock position 1
(

page 33).

165

Controls in detail

Useful features

Opening the storage compartment

Press the lock cylinder in and pull stor-
age compartment out using handle 2.

Closing the storage compartment

Push the storage compartment in until
the lock engages.

Armrest storage spaces

A flat storage tray with a deeper storage
compartment underneath is located below
the armrest. Both can be opened separate-
ly.

1 Button to open storage tray
2 Button to open storage compartment
3 Open cover

4 Storage tray
5 Coin holder

Opening the storage tray

Press button 1 and lift up armrest.

The armrest contains two coin holders.

Opening the storage compartment

Press button 2 and lift up armrest.

166

Controls in detail

Useful features

Opening the storage compartment in
front of armrest

Slide the cover 3 rearward.

The storage compartment below con-
tains a cup holder (

page 167).

Cup holders

Cup holder in instrument panel

A cup holder is located on both the right
and left side of the instrument panel.

Opening the cup holder

Briefly touch top of cover.

The cup holder opens automatically.

Closing the cup holder

Fold the cup holder upwards and press
on it until it engages.

Warning!

G

When not in use, keep the cup holder
closed. Place only containers that fit into the
cup holder to prevent spills. Use lids on
open containers and do not fill containers to
a height where the contents, especially hot
liquids, could spill during vehicle maneu-
vers.
