Mercedes-Benz ML320. Service manual - part 56





51

Getting started

Driving

Rear window wiper

The button is on the upper part on the cen-
ter console.

1 Intermittent wiping
2 Indicator lamp
3 Wiping with washer fluid

Switching on intermittent wiping

Make sure the ignition is switched on.

Press upper half 1 of the button.

Switching off intermittent wiping

Press upper half 1 of the button
again.

Wiping with washer fluid

Press and hold lower half 3 of the but-
ton.

After releasing the button the wiper op-
erates for additional five seconds.

More information on windshield wipers can
be found in the “Controls in detail” section
(

page 129).

Problems while driving

The engine runs erratically and misfires

An ignition cable may be damaged.

The engine electronics may not be
operating properly.

Unburned gasoline may have entered
the catalytic converter and damaged it.

Give very little gas.

Have the problem repaired by an au-
thorized Mercedes-Benz Light Truck
Center as soon as possible.

52

Getting started

Driving

The coolant temperature is over 248°F
(120°C)

The coolant is too hot and is no longer
cooling the engine.

Stop the vehicle as soon as possible
and turn off the engine. Allow engine
and coolant to cool.

Check the coolant level and add cool-
ant if necessary (

page 222).

In case of accident

If the vehicle is leaking gasoline:

Do not start the engine under any cir-
cumstances.

Notify local fire and /or police authori-
ties.

If the extent of the damage cannot be de-
termined:

Notify an authorized Mercedes-Benz
Light Truck Center.

If no damage can be determined on the

major assemblies

fuel system

engine mount:

Start the engine in the usual manner.

53

Getting started

Parking and locking

Parking and locking

You have now completed your first drive.
You have properly stopped and parked
your vehicle. End your drive as follows.

Parking brake

1 Parking brake
2 Release handle

Step firmly on parking brake 1.

When the engine is running, the indica-
tor lamp

É in the instrument cluster

will be illuminated.

Warning!

G

Wait until the vehicle is stationary before re-
moving the key from the steering lock. The
vehicle cannot be steered when the key is
removed.

Warning!

G

With the engine not running, there is no
power assistance for the brake and steering
system. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the
vehicle.

Warning!

G

Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.

To reduce the risk of personal injury as a re-
sult of vehicle movement, before turning off
the engine and leaving the vehicle always:

Keep right foot on brake pedal.

Firmly depress parking brake pedal.

Move the gear selector lever to
position P.

Slowly release brake pedal.

When parked on an incline, turn front
wheel towards the road curb.

Turn the key to starter switch position 0
and remove.

Take the key and lock vehicle when leav-
ing.

54

Getting started

Parking and locking

Switching off headlamps

Turn the combination switch to 1
(

page 48).

More information can be found in the
“Controls in detail” section (

page 107).

Turning off engine

Place the gear selector lever in
position P.

Turn the key in the steering lock
(

page 33) to position 0 and remove

it.

The immobilizer is activated.

Move the steering wheel slightly to al-
low the locking mechanism to engage.

Warning!

G

When leaving the vehicle, always remove the
key from the steering lock and lock the vehi-
cle. Do not leave children unattended in the
vehicle, or with access to an unlocked vehi-
cle. Children could release the parking
brake and/or move the gear selector lever
from position P, either of which could result
in an accident and/or serious personal
injury.

Warning!

G

Getting out of your vehicle with the gear
selector lever not fully engaged in position P
is dangerous. Also, when parked on an in-
cline, position P alone may not prevent your
vehicle from moving, possibly hitting people
or objects.

Always set the parking brake in addition to
shifting to position P (

page 53).

When parked on an incline, also turn front
wheel towards the road curb.

i

Always set the parking brake in addi-
tion to shifting to position P.

On steep slopes, turn the front wheels
towards the road curb.

i

The key can only be removed from the
steering lock with the gear selector le-
ver in position P.
