Mercedes-Benz ML320. Service manual - part 54





43

Getting started

Driving

1 Latch plate
2 Buckle
3 Release button
4 Seat belt outlet

A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle and
the child is not properly secured in the child
restraint.

Warning!

G

Never ride in a moving vehicle with the back-
rest reclined. Sitting in an excessively re-
clined position can be dangerous. You could
slide under the seat belt in a collision. If you
slide under it, the belt would apply force at
the abdomen or neck. That could cause se-
rious or even fatal injuries. The backrest and
seat belt provide the best restraint when the
wearer is in an upright position and the belt
is properly positioned on the body.

Warning!

G

Never let more people ride in the vehicle
than there are seat belts available. Be sure
everyone riding in the vehicle is correctly re-
strained with a separate seat belt.

Warning!

G

Read and observe the additional warning no-
tices printed in the “Safety and Security”
section (

page 62) and (

page 64).

44

Getting started

Driving

With a smooth motion, pull the belt
from seat belt outlet 4.

Place the belt over your shoulder.

Push latch plate 1 into buckle 2 until
it clicks.

If necessary, tighten the lap portion to
a snug fit by pulling shoulder portion
up.

If necessary, adjust the seat belt to the
correct height (

page 45).

Proper use of seat belts:

Do not twist the belt when fastening.

Adjust the seat belt so that the shoul-
der portion is located as close as possi-
ble to the middle of the shoulder (it
should not touch the neck or pass un-
der the arm).

Position the lap belt as low as possible
on your hips (over hip joint) and not
across the abdomen.

Place the seat backrest in a nearly up-
right position.

Never use a seat belt for more than one
person at a time.

Do not fasten a seat belt around a per-
son and another object at the same
time.

Check your seat belt during travel to
ensure that it is properly positioned.

Ensure that the seat belt is always fit-
ted snugly. You should avoid wearing
bulky clothing, such as winter coats,
when traveling in the vehicle.

Warning!

G

Do not pass belts over sharp edges. They
could tear.

Do not allow the belt to get caught in the
door or in the seat adjustment mechanism.
This could damage the belt.

Never attempt to make modifications to
seat belts. This could impair the effective-
ness of the belts.

Damaged seat belts or belts that were highly
stressed in an accident must be replaced.
Contact an authorized Mercedes-Benz Light
Truck Center.

45

Getting started

Driving

Seat belt height adjustment

Seat belt height can be adjusted for the fol-
lowing seats:

Driver’s seat

Passenger seat

Outer rear seats

Adjust seat belt so that the shoulder por-
tion is located as close as possible to the
middle of the shoulder (it should not touch
the neck or pass under the arm).

1 Release button

Adjusting seat belt higher

Slide belt outlet upward.

The belt outlet engages in various posi-
tions.

Adjusting seat belt lower

Press and hold release button 1.

Slide belt outlet in desired position and
let go of release button 1.

46

Getting started

Driving

Starting the engine

Automatic transmission

Gearshift pattern for automatic
transmission

Park position with gear selector lever

lock

Reverse gear

Neutral

Drive position

More information can be found in the
“Controls in detail” section (

page 119).

Starting

Make sure the gear selector lever is set
to P.

Do not depress the accelerator.

Turn the key in the steering lock to
position 3 and hold until the engine
starts (

page 33).

Depress the brake pedal.

The gear selector lever lock is released.

For information on turning off the engine,
see “Turning off engine” (

page 54).

Warning!

G

Inhalation of exhaust gas is hazardous to
your health. All exhaust gas contains carbon
monoxide, and inhaling it can cause uncon-
sciousness and lead to death.

Do not run the engine in confined areas
(such as a garage) which are not properly
ventilated. If you think that exhaust gas
fumes are entering the vehicle while driving,
have the cause determined and corrected
immediately. If you must drive under these
conditions, drive only with at least one win-
dow fully open.
