4. The setting change is completed by

doing any one of the following:



Switching the ignition to ACC or
ON.



Closing the driver's door.



Opening the liftgate.



Not operating the key for ten
seconds.



Pressing any button except the
UNLOCK button on the key.



Pressing a request switch.



Confirm that all doors and the liftgate
are securely locked.
For the liftgate, move it without pressing
the electric liftgate opener to verify that
the liftgate has not been left ajar.



All doors and the liftgate cannot be
locked when any door or the liftgate is
open.



It may require a few seconds for the
doors to unlock after the request switch
is pressed.



A beep sound is heard for confirmation
when the doors and the liftgate are
locked/unlocked using the request
switch. If you prefer, the beep sound can
be turned off.
The volume of the beep sound can also
be changed. Refer to Personalization
Features on page 9-12.
Use the following procedure to change
the setting.
1. Switch the ignition off and close all

of the doors and the liftgate.

2. Open the driver's door.

3. Within 30 seconds of opening the

driver's door, press and hold the
LOCK button on the key for 5
seconds or longer (All of the doors
and the liftgate are locked and
unlocked when the LOCK button on
the key is pressed and held for 5
seconds.).
The beep sound activates at the
currently set volume. The setting
changes each time the LOCK button
on the key is pressed and the beep
sound activates at the set volume. (If
the beep sound has been set to not
activate, it will not activate.)

4. The setting change is completed by

doing any one of the following:



Switching the ignition to ACC or
ON.



Closing the driver's door.



Opening the liftgate.



Not operating the key for ten
seconds.



Pressing any button except the
LOCK button on the key.



Pressing a request switch.



(With theft-deterrent system)
The hazard warning lights flash when
the theft-deterrent system is armed or
turned off.
Refer to Theft-Deterrent System on page
3-45.



The setting can be changed so that the
doors and the liftgate are locked
automatically without pressing the
request switch.
Refer to Personalization Features on
page 9-12.

Before Driving

Doors and Locks

3-14

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

(Walk-away auto lock function)
A beep sound is heard when all doors
and the liftgate are closed while the
advanced key is being carried. All doors
and the liftgate are locked automatically
after about three seconds when the
advanced key is out of the operational
range. Also, the hazard warning lights
flash once. (Even if the driver is in the
operational range, all doors and the
liftgate are locked automatically after
about 30 seconds.) If you are out of the
operational range before the doors and
the liftgate are completely closed or
another key is left in the vehicle, the
walk-away auto lock function will not
work. Always make sure that all doors
and the liftgate are closed and locked
before leaving the vehicle. The
walk-away auto lock function does not
close the power windows.



(Auto re-lock function)
After unlocking with the request switch,
all doors and the liftgate will
automatically lock if any of the
following operations are not performed
within about 60 seconds. If your vehicle
has a theft-deterrent system, the hazard
warning lights will flash for
confirmation.
The time required for the doors to lock
automatically can be changed.
Refer to Personalization Features on
page 9-12.



Opening a door or the liftgate.



Switching the ignition to any position
other than off.

▼ Locking, Unlocking with

Transmitter

All doors and the liftgate can be locked/
unlocked by operating the keyless entry
system transmitter, refer to Keyless Entry
System (page 3-3).

▼ Locking, Unlocking with Door-Lock

Switch

All doors and the liftgate lock
automatically when the lock side is
pressed. They unlock when the unlock
side is pressed.
Driver's door

Unlock

Lock

Front passenger's door

Unlock

Lock

To lock all the doors and the liftgate from
an open front door, press the lock side of
the door lock switch and then close the
door.

Before Driving

Doors and Locks

3-15

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

NOTE
When locking the doors this way, be
careful not to leave the key inside the
vehicle.

▼ Auto Lock/Unlock Function

WARNING

Do not pull the inner handle on a front
door:
Pulling the inner handle on a front door
while the vehicle is moving is dangerous.
Passengers can fall out of the vehicle if the
door opens accidentally , which could
result in death or serious injury.



When the vehicle speed exceeds 20
km/h (12 mph), all doors and the liftgate
lock automatically.



When the ignition is switched off, all
doors and the liftgate unlock
automatically.

These functions can also be disabled so
that they do not operate.

Auto lock/unlock function setting
change using door-lock switch

The doors and the liftgate can be set to
lock or unlock automatically by selecting
any one of the functions from the
following table and using the driver's
door-lock switch on the interior door
panel.

NOTE



Function number 3 in the following
table is the factory setting for your
vehicle.



There are only a total of six auto lock/
unlock settings available for automatic
transaxle vehicles, and three for manual
transaxle vehicles. Be sure to press the
unlock side of the driver's door-lock
switch the correct number of times
according to the selected function
number. If the switch is mistakenly
pressed seven times on an automatic
transaxle vehicle or four times on a
manual transaxle, the procedure will be
cancelled. If this occurs, start the
procedure from the beginning.

Function

number

Function

The auto door-lock function is disa‐
bled.

All the doors and the liftgate lock au‐
tomatically when the vehicle speed is
about 20 km/h (12 mph) or more.

3 (Factory

Setting)

All the doors and the liftgate lock au‐
tomatically when the vehicle speed is
about 20 km/h (12 mph) or more. All
the doors and the liftgate unlock
when the ignition is switched from
ON to Off.

Before Driving

Doors and Locks

3-16

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Function

number

Function

(Automatic transaxle vehicles only)
When the ignition is switched ON
and the selector lever is shifted from
park (P) to any other gear position, all
the doors and the liftgate lock auto‐
matically.
When the selector lever is shifted to
park (P) while the ignition is switched
ON, all the doors and the liftgate un‐
lock automatically.

(Automatic transaxle vehicles only)
All the doors and the liftgate lock au‐
tomatically when the vehicle speed is
about 20 km/h (12 mph) or more.
When the selector lever is shifted to
park (P) while the ignition is switched
ON, all the doors and the liftgate un‐
lock automatically.

1 Other settings for the auto door lock function are

available at an Authorized Mazda Dealer. For
details consult an Authorized Mazda Dealer.
Refer to Personalization Features on page 9-12.

Settings can be changed using the
following procedure.
1. Safely park the vehicle. All doors and

the liftgate must remain closed.

2. Switch the ignition ON.
3. Press and hold the lock side of the

driver's door-lock switch within 20
seconds of switching the ignition ON,
and make sure a beep sound is heard
about eight seconds afterwards.

4. Refer to the auto lock/unlock function

setting table, determine the function
number for the desired setting. Press
the unlock side of the driver's
door-lock switch the same number of
times as the selected function number
(Ex. If you select function 2, press the
unlock side of the switch only 2 times).

5. Three seconds after the function

setting has been changed, a beep sound
will beep in the amount of the selected
function number. (Ex. Function
number 3 = 3 beep sounds)

(Manual transaxle vehicles)

Press 2 times

Press 3 times

Current Function Number

Function Number 1

Function Number 2

Function Number 3

Press 4 times

Press unlock side of
lock switch once

Cancel setting

Function set (The
number of beeps
heard is the same as
the selected function
number)

Press lock side of
lock switch

Wait for 3 second

Before Driving

Doors and Locks

3-17

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

(Automatic transaxle vehicles)

Press unlock side of
lock switch once

Press 2 times

Press 3 times

Current Function Number

Function Number 1

Function Number 2

Press 4 times

Function Number 3

Press 5 times

Function Number 4

Press 7 times

Function Number 5

Press 6 times

Function Number 6

Cancel setting

Function set (The
number of beeps
heard is the same as
the selected function
number)

Press lock side of
lock switch

Wait for 3 second

NOTE



The doors and the liftgate cannot be
locked or unlocked while the setting
function is being performed.



The procedure can be cancelled by
pressing the lock side of the driver's
door-lock switch.

▼ Locking, Unlocking with Auxiliary

Key

Turn the auxiliary key toward the front to
lock, toward the back to unlock.

To lock

All doors and the liftgate lock
automatically when the driver's door is
locked using the auxiliary key.

To unlock

The driver’s door unlocks when the
auxiliary key is turned briefly to the
unlock position and then immediately
returned to the center position.
All doors and the liftgate unlock when the
driver's door is unlocked and the auxiliary
key is held in the unlock position for one
second or longer.

Lock

Unlock

▼ Locking, Unlocking with Door-Lock

Knob

Operation from inside

To lock any door from the inside, press the
door-lock knob.
To unlock, pull it outward.
This does not operate the other door locks.

Lock

Unlock

Unlocked: Red indicator

Before Driving

Doors and Locks

3-18

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Operation from outside

To lock any door using its door-lock knob
from the outside, press the door-lock knob
to the lock position and close the door
(holding the door handle in the open
position is not required).
This does not operate the other door locks.

Door-lock knob

NOTE
When locking the door this way:



Be careful not to leave the key inside the
vehicle.



The doors cannot be locked using the
driver's door lock knob if any door is
open when the ignition is switched to
ACC or ON.

▼ Rear Door Child Safety Locks

These locks are intended to help prevent
children from accidentally opening the
rear doors. Use them on both rear doors
whenever a child rides in the rear seat of
the vehicle.

If you slide the child safety lock to the
lock position before closing that door, the
door cannot be opened from the inside.
The door can only be opened by pulling
the outside handle.

Lock

Unlock

Before Driving

Doors and Locks

3-19

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Liftgate

WARNING

Never allow a person to ride in the luggage
compartment:
Allowing a person to ride in the luggage
compartment is dangerous. The person in
the luggage compartment could be
seriously injured or killed during sudden
braking or a collision.

Do not drive with the liftgate open:
Exhaust gas in the cabin of a vehicle is
dangerous. An open liftgate in a moving
vehicle will cause exhaust gas to be drawn
into the cabin. This gas contains CO
(carbon monoxide), which is colorless,
odorless, and highly poisonous, and it can
cause loss of consciousness and death.
Moreover, an open liftgate could cause
occupants to fall out in an accident.

Do not stack or leave loaded luggage
unsecured in the luggage compartment:
Otherwise, the luggage may move or
collapse, resulting in injury or an accident.
In addition, do not load luggage higher
than the seatbacks. It may affect the side or
rear field of view.

CAUTION

Before opening the liftgate, remove any

snow and ice accumulation on it.
Otherwise, the liftgate could close under
the weight of the snow and ice resulting
in injury.

Be careful when opening/closing the

liftgate during strong winds. If a strong
gust blows against the liftgate, it could
close suddenly resulting in injury.

Fully open the liftgate and make sure

that it stays open. If the liftgate is only
opened partially, it could slam shut by
vibration or wind gusts resulting in
injury.

When loading or unloading luggage in

the luggage compartment, turn off the
engine. Otherwise, you could get burned
by the heat of the exhaust gas.

Be careful not to apply excessive force to

the damper stay on the liftgate such as
by putting your hand on the stay.
Otherwise, the damper stay may bend
and affect the liftgate operation.

Damper stay

Do not modify or replace the liftgate

damper stay. Consult an Authorized
Mazda Dealer if a liftgate damper stay is
deformed or damaged for reasons such
as a collision or if there is some other
problem.

Before Driving

Doors and Locks

3-20

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

▼ Opening and Closing the Liftgate

Opening the liftgate with Electric
liftgate opener

Unlock the doors and liftgate, then press
the electric liftgate opener on the liftgate
and raise the liftgate when the latch
releases.
For the power liftgate operation, refer to
Power Liftgate on page 3-22.

Electric liftgate
opener

NOTE
(With the advanced keyless function)



A locked liftgate can also be opened
while the key is being carried.



When opening the liftgate with the doors
and the liftgate locked, it may require a
few seconds for the liftgate latch to
release after the electric liftgate opener
is pressed.



The liftgate can be closed when the
doors are locked with the key left in the
vehicle. However, to prevent locking the
key in the vehicle, the liftgate can be
opened by pressing the electric liftgate
opener. If the liftgate cannot be opened
despite doing this procedure, first push
the liftgate completely closed, then press
the electric liftgate opener to fully open
the liftgate.



When the liftgate latch is released by
pressing the electric liftgate opener, the
liftgate raises slightly. If the liftgate is
not operated for a certain period of
time, the liftgate cannot be raised.
To open
Press the electric liftgate opener again.
To close
To close the liftgate from its slightly
raised position, open it first by pressing
the electric liftgate opener, then close it
after waiting at least 1 second.



If the liftgate is not fully closed, the
driver is notified by a warning indicated
in the instrument cluster.



If the vehicle battery is dead or there is
a malfunction in the electrical system
and the liftgate cannot be unlocked, the
liftgate can be opened by performing the
emergency procedure.
Refer to When Liftgate Cannot be
Opened on page 7-48.

Closing the liftgate

Lower the liftgate slowly using the liftgate
grip recess, then push the liftgate closed
using both hands.
Do not slam it. Pull up on the liftgate to
make sure it is secure.
For the power liftgate operation, refer to
Power Liftgate on page 3-22.

Liftgate grip
recess

Before Driving

Doors and Locks

3-21

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

NOTE
Confirm that the liftgate is securely closed.
The liftgate, move it without pressing the
electric liftgate opener to verify that the
liftgate has not been left ajar.

▼ Power Liftgate

The power liftgate opens/closes
electrically by operating the switches in
the vehicle or the buttons on the keyless
entry system transmitter.

WARNING

Be sure to watch the power liftgate as it
opens or closes, and make sure that it
closes completely:
Opening or closing the power liftgate while
not watching it move is dangerous.
Because of unseen obstacles and the
jam-safe feature, a liftgate may not close
completely and, if left unnoticed, could
result in serious injury or death if an
occupant were to fall out of the vehicle.
Always be sure that the area around the
liftgate is clear before activating it.

Always confirm the safety of the area
around the power liftgate before operating
it electrically.
Not checking the area around the liftgate
for people before operating it using the
power liftgate switch or the button on the
keyless entry system is dangerous. A person
could become caught between the liftgate
and an obstruction while it is opening
electrically or between the liftgate and
vehicle while it is closing electrically,
resulting in an accident and serious injury.

Never allow children to operate the power
liftgate system:
Allowing children to operate the power
liftgate switch and the keyless entry system
is dangerous. Children are not aware of the
dangers of people getting fingers and
hands caught in a moving liftgate. If
someone's neck, head or hands get caught
in a closing door, it could result in death or
serious injury.

CAUTION

When closing the power liftgate, make

sure there are no foreign objects around
the striker. If foreign objects are
obstructing the striker, the liftgate may
not close properly.

Striker

Do not install accessories to the power

liftgate other than specified accessories.
Otherwise, it cannot be opened/closed
automatically and could result in a
malfunction.

Be careful when switching the power

liftgate from electrical to manual
operation. The power liftgate may open/
close unexpectedly depending on its
position which could result in injury.

Before Driving

Doors and Locks

3-22

*Some models.

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

NOTE



Do not apply unnecessary force to the
power liftgate when it is opening/closing
electrically. Unnecessary force on the
liftgate may cause it to reverse direction
of movement automatically. Also, it
could result in a malfunction.



The power liftgate may not open/close
electrically if the vehicle is parked on an
incline, or there is strong wind, or the
liftgate is laden with snow.



If a power liftgate system fuse has
blown, the liftgate cannot be opened
using the power liftgate switch or the
electric liftgate opener. Use the
emergency lever to open the liftgate.



Fully close the power liftgate before
disconnecting the vehicle battery. If the
battery is disconnected with the liftgate
open, it cannot be opened or closed
automatically after the battery is
reconnected. If this happens, fully close
the liftgate manually to restore the auto
full open/close function.



If the system detects weight such as that
caused by a snow-laden liftgate when it
is opened electrically, after the beep
activates three times, the liftgate stops
after reversing.



If the power liftgate is snow-laden,
remove the snow before operating the
liftgate.

Operation using the transmitter

Press the power liftgate button for one
second or more. The hazard warning lights
flash twice and the liftgate opens/closes
after the beep sounds.
Refer to Transmitter on page 3-5.

NOTE



When the ignition is switched ON, the
transmitter does not operate.



When opening the liftgate by pressing
the power liftgate button on the
transmitter, the liftgate can be opened
even when it is locked.



If the power liftgate button on the
transmitter is pressed while the liftgate
is opening/closing electrically, the beep
is activated and the liftgate stops. When
pressing the power liftgate button again,
the liftgate moves in the reverse
direction.

Before Driving

Doors and Locks

3-23

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Operation using each switch

Operation conditions

Opening the liftgate
If the vehicle has satisfied all the
following operation conditions, the power
liftgate can be opened using the power
function.



All doors and the liftgate are unlocked.



The ignition is switched OFF, or the
selector lever is in P with the ignition
switched ON.

Closing the liftgate



The ignition is switched OFF, or the
selector lever is in P with the ignition
switched ON.

NOTE



If the vehicle moves with the selector
lever shifted to a position other than P
while the liftgate is opening/closing
electrically, the liftgate moves as
follows:
While opening electrically
The buzzer is activated, and the liftgate
moves in the reverse direction
automatically and closes. When the
selector lever is shifted to P, you can
resume the power liftgate operation
using the switches.
While closing electrically
The buzzer is activated, but the liftgate
continues closing.

Operation from the driver's seat (To
open/close)

Press the power liftgate switch for about
one second or more while the liftgate is in
the fully closed/open position. The hazard
warning lights flash twice and the liftgate
opens/closes fully after the beep sound is
heard.

Power liftgate switch

Operation from outside (To open)

Press the electric liftgate opener on the
liftgate and raise the liftgate. The hazard
warning lights flash twice and the liftgate
opens automatically after the beep sound
is heard.
(With the advanced keyless function)
A locked liftgate can also be opened while
the key is being carried.

Electric liftgate
opener

Before Driving

Doors and Locks

3-24

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Operation from outside (To close)

Press the power liftgate close switch while
the liftgate is fully opened. The hazard
warning lights flash twice and the liftgate
closes automatically after the beep sound
is heard.

Power liftgate
close switch

NOTE
If the power liftgate switch/power liftgate
close switch is pressed or the electric
liftgate opener is operated while the
liftgate is opening/closing electrically, the
beep sound is heard and the liftgate stops.
Then, it reverses when any of the switches
are pressed again.

Changing the power liftgate fully open
position

The power liftgate fully-open position can
be changed according to the height of a
garage.

When changing the position

1. Stop the liftgate at the desired position.
2. Press the power liftgate close switch

for about three seconds.
A beep sound is activated two times to
indicate that the position change has
been completed.

NOTE
Set the desired fully-open position of the
liftgate at the position where it is open
more than halfway. The position where it
is less than halfway open cannot be set.

To reset

1. Open the liftgate.
2. Press the power liftgate close switch

for about seven seconds.
A beep sound is activated three times
to indicated that the reset has been
completed.

NOTE
After about 3 seconds have elapsed since
the switch was pressed, a beep sound is
activated 2 times to indicate that the
liftgate fully-open position has changed.
Continuously press the switch for about 7
seconds to complete the reset.

Jam-safe equipment

While the power liftgate is opening/
closing electrically and the system detects
a person or an object in the liftgate's path,
the liftgate will move in the reverse
direction automatically and stops.

Before Driving

Doors and Locks

3-25

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

WARNING

Always check the area around the power
liftgate before opening/closing it:
Not checking for occupants and objects
around the power liftgate before opening/
closing it is dangerous. The jam-safe
equipment is designed to prevent jamming
in the event an obstruction is in the
liftgate's path. The system may not detect
certain objects obstructing the liftgate
depending on the way they are positioned
and their shape. However, if the jam-safe
function detects an obstruction and moves
the liftgate in the reverse direction, an
occupant in the liftgate's path could be
seriously injured.

CAUTION

Sensors are installed on both ends of the
power liftgate. Be careful not to allow the
sensors to be scratched or damaged by
sharp objects, otherwise the liftgate may
no longer open/close automatically. In
addition, if the sensor is damaged while the
liftgate is closing automatically, the system
will stop.

Sensor

NOTE
The jam-safe equipment does not activate
during easy closure operation when the
power liftgate is between the near-shut
position and fully closed position.

When the power liftgate is moving in the
open/close direction and an obstruction is
detected, the beep sound will be heard and
the liftgate moves in the reverse direction
and stops.

Liftgate easy closure

The Easy Closure system automatically
closes the liftgate completely from the
near-shut position.
This system also operates when the liftgate
is closed manually.

WARNING

When closing a liftgate, always keep hands
and fingers away from the liftgate:
Placing hands or fingers around a liftgate is
dangerous because the liftgate closes
automatically from the near-shut position,
which could cause hands and fingers to be
pinched and injured.

NOTE



If the electric liftgate opener is pressed
while the easy closure function is
operating, the liftgate can be opened.



If the liftgate is opened/closed
repeatedly in a short period of time, the
easy closure function may not operate.
Wait for about 2 seconds and then try
again.

Before Driving

Doors and Locks

3-26

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Fuel and Engine Exhaust Precautions

▼ Fuel Requirements

Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED FUEL,
which will reduce exhaust emissions and keep spark plug fouling to a minimum.

This vehicle will perform best with fuel listed in the table.

Fuel

Octane Rating

(Anti-knock index)

Regular unleaded fuel

87 [(R M)/2 method] or above (91 RON or above)

 U.S. federal law requires that octane ratings be posted on gasoline station pumps.

Fuel with a rating lower than 87 octane (91 RON) will negatively affect the emission control
system performance and could also cause engine knocking and serious engine damage.

CAUTION

USE ONLY UNLEADED FUEL.

Leaded fuel is harmful to the catalytic converter and oxygen sensors and will lead to
deterioration of the emission control system and or failures.

This vehicle can only use oxygenated fuels containing no more than 10 % ethanol by

volume. Damage to the vehicle may occur when ethanol exceeds this recommendation, or
if the gasoline contains any methanol. Stop using gasohol of any kind if your vehicle engine
is performing poorly.

Never add fuel system additives, otherwise the emission control system could be damaged.

Consult an Authorized Mazda Dealer for details.

Gasoline blended with oxygenates such as alcohol or ether compounds are generally
referred to as oxygenated fuels. The common gasoline blend that can be used with your
vehicle is ethanol blended at no more than 10 %. Gasoline containing alcohol, such as
ethanol or methanol, may be marketed under the name "Gasohol".

Vehicle damage and drivability problems resulting from the use of the following may not be
covered by the warranty.



Gasohol containing more than 10 % ethanol.



Gasoline or gasohol containing methanol.



Leaded fuel or leaded gasohol.

Before Driving

Fuel and Emission

3-27

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

▼ Emission Control System

This vehicle is equipped with an emission control system (the catalytic converter is part of
this system) that enables the vehicle to comply with existing exhaust emissions
requirements.

WARNING

Never park over or near anything flammable:
Parking over or near anything flammable, such as dry grass, is dangerous. Even with the
engine turned off, the exhaust system remains very hot after normal use and could ignite
anything flammable. A resulting fire could cause serious injury or death.

CAUTION

Ignoring the following precautions could cause lead to accumulate on the catalyst inside the
converter or cause the converter to get very hot. Either condition will damage the converter
and cause poor performance.

USE ONLY UNLEADED FUEL.
Do not drive your Mazda with any sign of engine malfunction.
Do not coast with the ignition switched off.
Do not descend steep grades in gear with the ignition switched off.
Do not operate the engine at high idle for more than 2 minutes.
Do not tamper with the emission control system. All inspections and adjustments must be

made by a qualified technician.

Do not push-start or pull-start this vehicle.

NOTE



Under U.S. federal law, any modification to the original-equipment emission control
system before the first sale and registration of a vehicle is subject to penalties. In some
states, such modification made on a used vehicle is also subject to penalties.



While the engine is off, the sound of a valve opening and closing can be heard at the rear
of the vehicle, however this does not indicate an abnormality. The vehicle has a
self-checking device and it operates while the engine is off.

Before Driving

Fuel and Emission

3-28

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

▼ Engine Exhaust (Carbon monoxide)

WARNING

Do not drive your vehicle if you smell exhaust gas inside the vehicle:
Engine exhaust gas is dangerous. This gas contains carbon monoxide (CO), which is colorless,
odorless, and poisonous. When inhaled, it can cause loss of consciousness and death. If you
smell exhaust gas inside the vehicle, keep all windows fully open and contact an Authorized
Mazda Dealer immediately.

Do not run the engine when inside an enclosed area:
Running the engine inside an enclosed area, such as a garage, is dangerous. Exhaust gas,
which contains poisonous carbon monoxide, could easily enter the cabin. Loss of
consciousness or even death could occur.

Open the windows or adjust the heating or cooling system to draw fresh air when idling the
engine:
Exhaust gas is dangerous. When the vehicle is stopped with the windows closed and the
engine running for a long time even in an open area, exhaust gas, which contains poisonous
carbon monoxide, could enter the cabin. Loss of consciousness or even death could occur.

Clear snow from underneath and around your vehicle, particularly the tail pipe, before
starting the engine:
Running the engine when a vehicle is stopped in deep snow is dangerous. The exhaust pipe
could be blocked by the snow, allowing exhaust gas to enter the cabin. Because exhaust gas
contains poisonous carbon monoxide, it could cause loss of consciousness or even death to
occupants in the cabin.

Before Driving

Fuel and Emission

3-29

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Mazda CX-5 (2019 year). Manual - part 7
