Mazda B4000 Truck (2007 year). Manual

AM/FM stereo single CD system

1. CD eject: Press to eject the

CD.

2. CLK (Clock): Press CLK until

SELECT HOUR or SELECT
MINUTE is displayed. Press

to adjust the

hours/minutes. Press CLK to display the time when the ignition is
off.

3. MUTE: Press to mute the

playing media. Press again to
return to the playing media.

4. MENU: Press MENU repeatedly

to toggle through the following
modes and use

to make

adjustment in those modes.

CIMS #1296341

com_scdpio.mbs04

itdseq=23

art=rancf806_c

art=rancf827_b

art=rancf833_a

art=rancf834_a

art=rancf838_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 21 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

Autoset: Press

set the strongest local radio stations
for AM/FM1/FM2 without losing
your original manually set preset
stations.
When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system
will store the last one in the remaining presets.

Bass: Press

to decrease/increase the bass setting.

Treble: Press

to decrease/increase the treble setting.

Balance: Press

to adjust the audio between the left and

right speakers.

Fade: Press

to adjust the audio between the front and

rear speakers.

5. TUNE: Press to manually go

down/up (

) the radio

frequency and also to select
various settings in menu mode.

6. SHUFF (Shuffle): Press to

play the tracks on the current
CD in random order.

7. REPEAT: Press to repeat the

current CD track.

8. FF (Fast forward): Press to

manually advance in a CD track.

9. REW (Rewind): Press to

manually reverse in a CD track.

10. Memory presets: To set a

station: Select frequency band
AM/FM; tune to a station, press
and hold a preset button until sound returns. To recall a previously
set station, press the desired memory preset button briefly.

11. SEEK/TRACK: Press to access the next/previous strong station. In

CD mode, press to advance to the next/previous track.

REW

art=rancf835_a

art=rancf845_a

art=221cf806_a

art=221cf805_a

art=rancf828_b

art=rancf839_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 22 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

12. SCAN: Press to toggle between

SCAN ON and SCAN OFF. When
activated, the system scans up
through and plays a brief sampling of available radio stations or CD
tracks. Press again to stop.

13. AM/FM:Press to select

AM/FM1/FM2 frequency band.

14. ON/OFF/Volume: Press to turn

ON/OFF. Turn to
increase/decrease volume.
If the volume is set above a
certain level and the ignition is
turned off, the volume will come
back on at a “nominal” listening level when the ignition switch is
turned back on.

15. CD: Press to enter CD mode. If

a CD is already present in the
system, the disc will begin to
play.

16. CD slot: Insert a CD label side

up.

CD units are designed to play commercially pressed 4.75 in (12
cm) audio compact discs only. Due to technical incompatibility,
certain recordable and re-recordable compact discs may not
function correctly when used in Mazda CD players. Irregular
shaped CDs, CDs with a scratch protection film attached, and CDs
with homemade paper (adhesive) labels should not be inserted
into the CD player. The label may peel and cause the CD to
become jammed. It is recommended that homemade CDs be
identified with permanent felt tip marker rather than adhesive
labels. Ballpoint pens may damage CDs. Please contact your
dealer for further information.

art=221cf812_a

art=rancf842_a

art=221cf819_a

art=rancf837_a

art=221cf823_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 23 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

AM/FM stereo single CD/MP3 Satellite Compatible system
(if equipped)

1. CD eject: Press to eject the

CD/MP3.

2. CLK (Clock): Press CLK until

SELECT HOUR or SELECT
MINS is displayed. Press

to adjust the

hours/minutes. Press CLK to display the time when the ignition is
off.

3. MUTE: Press to mute the

playing media. Press again to
return to the playing media.

4. MENU: Press MENU repeatedly

to scroll through the following

CIMS #1569891

com_mbsscd.pio

itdseq=24

art=rancf861_a

art=rancf827_b

art=rancf833_a

art=rancf834_a

art=rancf838_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 24 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

modes and use

to make an adjustment in those modes.

CATEGORY (Satellite Radio if
equipped): Press MENU until the
currently active category appears in
the display (CATEGORY ALL). In

CATEGORY ALL, press

to scroll through the list of available

Sirius Categories (Pop, Rock, News, etc.) Press

SEEK

or SCAN

to select the channels within each category. After a category is selected,
press SEEK to search for that specific channel. To select a different
category, press MENU until CATEGORY ALL appears in the display.

Press

to select a different category.

Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

Autoset: Press

to set the strongest local radio stations

for AM/FM1/FM2 without losing your original manually set preset
stations.
When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system
will store the last one in the remaining presets.

Bass: Press

to decrease/increase the bass setting.

Treble: Press

to decrease/increase the treble setting.

Balance: Press

to adjust the audio between the left and

right speakers.

Fade: Press

to adjust the audio between the front and

rear speakers.

Next/previous directory: In MP3 mode, press MENU

go to the previous/next directory.

Flat file/directory mode: In MP3 mode, press MENU to access this

feature. Use

to select flat file mode or directory mode.

Track # / Normal music name/File name: Press MENU to access and

use

to scroll through MP3 display options (track #, normal music

name or file name).

art=rancf835_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 25 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

5. TUNE: Press to manually go

down/up (

) the radio

frequency and also to select
various settings in menu mode.

In CATEGORY ALL, press

to scroll through the list of available

SIRIUS channel Categories (Pop, Rock, News, etc.). Refer to Category
Mode under Menu for further information.
Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

6. SHUFF (Shuffle): Press to

play the current CD/MP3 tracks
in random order. In MP3
directory mode, press to play the tracks within the current directory
in random order.

7. REPEAT: Press to repeat the

current CD/MP3 track. The
selection will repeat
continuously until deactivated. Press REPEAT again to deactivate.

8. FF (Fast forward): Press to

manually advance in a CD/MP3
track.

9. REW (Rewind): Press to

manually reverse in a CD/MP3
track.

10. Memory presets: To set a

station: Select frequency band
AM/FM; tune to a station, press
and hold a preset button until sound returns. To recall a previously
set station, press the desired memory preset button briefly. You can
save up to 18 stations, six in AM, six in FM1 and FM2.

In Satellite Radio mode (if equipped), there are 18 available presets, six
each for SAT1, SAT2 and SAT3. To save satellite channels in your
memory presets, tune to the desired channel then press and hold a
preset control until sound returns.
Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

REW

art=rancf835_a

art=rancf845_a

art=221cf806_a

art=221cf805_a

art=rancf828_b

art=rancf839_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 26 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

11. SEEK/TRACK: Press to access

the previous/next (

)

strong station. In CD/MP3 mode,
press to advance to the
previous/next (

) track.

In Satellite Radio mode (if equipped), press

SEEK

to seek to the

previous/next channel. If a specific category is selected, (Jazz, Rock,
News, etc.), press

SEEK

to seek to the previous/next channel in

the selected category. Press and hold

SEEK

to fast seek through

the previous /next channels.
In TEXT MODE, press

SEEK

to view the previous/additional

display text.
In CATEGORY ALL, press

TUNE

to select a category.

In CATEGORY MODE, press

SEEK

to select a channel within

that category.
Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

12. TEXT/SCAN: In radio and CD

mode, press for a brief sampling
of radio stations or CD tracks.
Press again to stop.

In MP3 flat file mode, press and hold to hear a brief sampling of MP3
tracks.
In MP3 directory mode, press and hold to hear a brief sampling of all
tracks in the current directory. Press again to stop.

In MP3 music name/file name mode, press and release to view the next
12 characters in the MP3 music name/file name of the current MP3 track
and directory.

In Satellite Radio mode (if equipped), press and release to view the
Satellite text message.

In Satellite Radio mode (if equipped), press and hold to hear a brief
sampling of the next channels. Press again to stop.
Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

art=rancf874_a

art=rancf862_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 27 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

13. AM/FM: Press to select

AM/FM1/FM2 frequency band.

14. AUX: Press to access AUX

modes. To return to radio mode,
press AM/FM.
If equipped with Satellite Radio, press AUX to cycle through
SAT1, SAT2 SAT3 (Satellite Radio mode, if available) and
LINE IN (Auxiliary audio mode, if equipped).

Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

15. ON/OFF/Volume: Press to turn

16. CD: Press to enter CD/MP3

mode. If a CD/MP3 is already
present in the system, the disc
will begin to play.

17. CD slot: Insert a CD/MP3 label

side up.

art=rancf858_a

art=rancf857_a

art=221cf819_a

art=rancf837_a

art=221cf823_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 28 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

Premium in-dash CD6/MP3 disc audio system

1. AM/FM: Press to select

AM/FM1/FM2 frequency bands.

2. CD: Press to enter CD/MP3

mode. If a CD/MP3 is already in
the system, the disc will start
playing.

3. EJ (CD eject): To eject an

individual CD/MP3, press the
eject control and select the
correct slot number by pressing the corresponding memory preset.
Press and hold to eject all loaded CDs.

4. CLK (Clock): Press CLK until

SELECT HOUR or SELECT
MINUTE is displayed. Press
MENU

to adjust the

hours/minutes. Press CLK to display the time when the ignition is
off.

CIMS #1273156

com_premcd.mbs

itdseq=25

art=rancf804_c

art=rancf825_a

art=rancf837_a

art=rancf827_b

art=rancf833_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 29 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

5. MUTE: Press to mute the

playing media. Press again to
return to the playing media.

6. MENU: Press MENU repeatedly

to toggle through the following
modes and use

to make

adjustment in those modes.

Autoset: Allows you to set the
strongest local radio stations
without losing your original
manually set preset stations for
AM/FM1/FM2 . Press MENU to access. Use

to set.

When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system
will store the last one in the remaining presets.

Bass: Press

to decrease/increase the bass setting.

Treble: Press

to decrease/increase the treble setting.

Balance: Press

to adjust the audio between the left and

right speakers.

Fade: Press

to adjust the audio between the front and

rear speakers.

Next/previous directory: In MP3 mode, press MENU

to go to

the previous/next directory.
Flat file/directory mode: In MP3 mode, press MENU to access this
feature. Use

to select flat file mode or directory mode.

Track #/normal music name/file name: Press MENU to access and
use

to scroll through MP3 display options (track #, normal music

name or file name).

7. TUNE/DISC: Press to manually go down/up (

) the radio

frequency, select the previous/next CD or to select various settings
in menu mode. In MP3 directory mode, press

to access the

previous/next directory

8. TEXT: In MP3 normal music name/file name mode, press to view the

next 12 characters in the MP3 music name/filename of the current
MP3 track and directory.

art=rancf834_a

art=rancf838_a

art=rancf846_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 30 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

9. SHUFF (Shuffle): Press to

play the tracks on the current
CD/MP3 in random order. In
MP3 directory mode, press to play the tracks within the current
directory in random order.

10. COMP (Compression): In

CD/MP3 modes, press to bring
loud and soft passages together
for a more consistent listening level.

11. REPEAT: Press to repeat the

current CD/MP3 track.

12. FF (Fast forward): Press to

manually advance in a CD/MP3
track.

13. REW (Rewind): Press to

manually reverse in a CD/MP3
track.

14. Memory presets: To set a

station: Select frequency band
AM/FM; tune to a station, press
and hold a preset button until sound returns. To select a preset
station, press the desired memory preset.

15. SEEK/TRACK: In radio, CD and MP3 flat file mode, press

to access the next/previous strong station or track. In MP3 directory
mode, press to select the next/previous track in the current
directory.

16. SCAN: In radio, CD and MP3

flat file mode, press for a brief
sampling of radio stations or
CD/MP3 tracks. In MP3 directory mode, press to hear a brief
sampling of all tracks in the current directory. Press again to stop.

17. ON/OFF/Volume: Press to turn

REW

art=rancf845_a

art=221cf807_a

art=221cf806_a

art=221cf805_a

art=rancf828_b

art=rancf840_a

art=221cf812_a

art=221cf841_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 31 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

18. LOAD: To load a CD/MP3 disc to a specific slot, press LOAD and

select the slot number by pressing the memory preset buttons. Press
and hold LOAD to autoload up to six discs.

19. CD slot: Insert a CD/MP3, label side up.

Premium and Audiophile In-dash CD6/MP3 disc Satellite
Compatible audio systems (if equipped)

CIMS #1569892

com_mbscdx6.pio

itdseq=26

art=rancf863_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 32 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

1. AM/FM: Press to select

AM/FM1/FM2 frequency bands.

2. CD: Press to enter CD/MP3

mode. If a CD/MP3 is already in
the system, the disc will start
playing.

3. AUX: Press to access AUX

modes. To return to radio mode,
press AM/FM.
If equipped with Satellite
Radio, press AUX to cycle through SAT1, SAT2 SAT3
(Satellite Radio mode, if available) and LINE IN (Auxiliary
audio mode, if equipped).

Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

4. EJ (CD eject): To eject an

individual CD/MP3, press the
eject control and select the
correct slot number by pressing the corresponding memory preset.
Press and hold to eject all loaded CDs.

5. CLK (Clock): Press CLK until

SELECT HOUR or SELECT
MINS is displayed. Press
MENU

to adjust the

hours/minutes. Press CLK to display the time when the ignition is
off.

6. MUTE: Press to mute the

playing media. Press again to
return to the playing media.

7. MENU: Press MENU repeatedly

to toggle through the following
modes and use

to make

adjustment in those modes.

CATEGORY (Satellite Radio if
equipped): Press MENU until the
currently active category appears in
the display (CATEGORY ALL). In

art=rancf869_a

art=rancf867_a

art=rancf868_a

art=rancf827_b

art=rancf833_a

art=rancf834_a

art=rancf838_a

art=rancf846_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 33 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

CATEGORY ALL, press

to scroll through the list of available

Sirius Categories (Pop, Rock, News, etc.) Press

SEEK

or SCAN

to select a different category.

Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

Autoset: Allows you to set the strongest local radio stations without
losing your original manually set preset stations for AM/FM1/FM2 . Press
MENU to access. Use

to set.

When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system
will store the last one in the remaining presets.

Bass: Press

to decrease/increase the bass setting.

Treble: Press

to decrease/increase the treble setting.

Balance: Press

to adjust the audio between the left and

right speakers.

Fade: Press

to adjust the audio between the front and

rear speakers.

Next/previous directory: In MP3 mode, press MENU

to go to

the previous/next directory.

Flat file/directory mode: In MP3 mode, press MENU to access this
feature. Use

to select flat file mode or directory mode.

Track #/ normal music name/file name: Press MENU to access and
use

to scroll through MP3 display options (track #, normal music

name or file name).

8. TUNE/DISC: In radio mode,

press to manually go down/up
(

) the radio frequency,

or to access another CD/MP3.
Also use in menu mode to select various settings.

In CATEGORY ALL, press

to scroll through the list of available

SIRIUS channel categories (Pop, Rock, News, etc.). Refer to Category
Mode under Menu for further information.

art=rancf870_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 34 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

9. SHUFF (Shuffle): Press to

play the tracks on the current
CD/MP3 in random order. In
MP3 directory mode, press to play the tracks within the current
directory in random order.

10. COMP (Compression): In

CD/MP3 modes, press to bring
loud and soft passages together
for a more consistent listening level.

11. REPEAT: Press to repeat the

current CD/MP3 track. The
selection will repeat
continuously until deactivated. Press REPEAT again to deactivate.

12. FF (Fast forward): Press to

manually advance in a CD/MP3
track.

13. REW (Rewind): Press to

manually reverse in a CD/MP3
track.

14. Memory presets: To set a

station: Select frequency band
AM/FM; tune to a station, press
and hold a preset button until sound returns. To select a preset
station, press the desired memory preset. You can save up to 18
stations, six in AM, six in FM1 and FM2.

15. SEEK/TRACK: In radio, CD

and MP3 flat file mode,
press

to access the

previous/next strong station or
track. In MP3 directory mode, press to select the next/previous track
in the current directory.

In Satellite Radio mode (if equipped), press

SEEK

to seek to the

previous/next channel. If a specific category is selected, (Jazz, Rock,

REW

REPEAT

SHUFF

COMP

art=221cf808_a

art=221cf807_a

art=221cf806_a

art=221cf805_a

art=rancf828_b

art=rancf877_a

art=rancf874_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 35 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

News, etc.), press

SEEK

to seek to the previous/next channel in

the selected category. Press and hold

SEEK

to fast seek through

the previous /next channels.
In TEXT MODE, press

SEEK

to view the previous/additional

display text.
In CATEGORY ALL, press

TUNE

to select a category.

In CATEGORY MODE, press

SEEK

to select a channel within

that category.
Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

16. TEXT/SCAN: In radio and CD

mode, press for a brief sampling
of radio stations or CD tracks.
Press again to stop.

In MP3 music name/file name mode, press and release to view the next
12 characters in the MP3 music name/file name of the current MP3 track
and directory.

In Satellite Radio mode (if equipped), press and release to view the
Satellite text message.

In Satellite Radio mode (if equipped), press and hold to hear a brief
sampling of the next channels. Press again to stop.

17. ON/OFF/Volume: Press to turn

18. LOAD: Press to load a CD/MP3.

To load a CD/MP3 disc to a
specific slot, press LOAD and
select the slot number by pressing the memory preset buttons. Press
and hold LOAD to autoload up to six discs.

art=rancf862_a

art=221cf841_a

art=rancf875_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 36 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Entertainment Systems

Mazda B4000 Truck (2007 year). Manual - part 2
