Quick Overview

STEERING COLUMN
ADJUSTMENT

Turn the control on left-hand side of
steering column to COLUMN and move
control to adjust the height and reach.

Automatic seat movement

To prevent automatic movement of the
driver's seat when the ignition switch is
turned on or off, turn the control to
COLUMN.

Drivers seat movement at ignition
switch off

If the control is set to AUTO, the position
of the steering column and driver's seat
will automatically adjust to provide
greater clearance for exit and entry when:
• the key is in the ignition switch and the

driver’s door is opened;

• the ignition key is removed.

ELECTROCHROMATIC REAR
VIEW MIRROR

With the ignition switch on, the rear view
mirror will automatically darken in
proportion to the amount of glare
detected from the following vehicles'
headlamps. This feature is automatically
switched off when reverse gear is
selected.

WINDOWS AND DOOR
MIRRORS

Windows

The windows are fitted with a facility that
allows them to be fully opened or closed
by briefly pressing the respective window
switch. Press the switch again to stop
window movement.
• To open the window, press and hold

the rear of the switch until the desired
position is reached, then release.

JAG0564

JOL4728

Quick Overview

• To close the window, press and hold

the front of the switch until the desired
position is reached, then release.

Press button 3 to inhibit the operation of
the rear window switches.

Door mirrors

To adjust the door mirrors, press the
mirror selector switch 2 left or right to
select the appropriate mirror. Use the
four-way switch 1 to adjust the position.

Global closing

If a window has been left open when
leaving the vehicle, it can be closed by
pressing and holding the lock button on
the remote handset (this will also close
the sunroof).

DRIVING POSITION MEMORY

Once you have adjusted the driver’s seat,
steering column and exterior mirrors for
your ideal driving position, the vehicle can
memorise these settings for future use.
• Push the MEMORY button and a red

indicator in the switch will illuminate
for five seconds.

• Whilst the indicator is illuminated,

press button 1 or 2 to memorise the
current settings.

The indicator will extinguish and an
audible chime will sound to confirm that
the settings are memorised. Any existing
settings will be overwritten.

To recall a memorised driving position
press button 1 or 2.

Remote handset programming

With the MEMORY button illuminated
you can programme a remote handset to
a memory position by pressing any button
on the remote handset and then pressing
button 1 or 2.

JOL4729

Quick Overview

SEAT BELTS AND CHILD
RESTRAINTS

WARNING:

The use of front and rear seat belts is
mandatory in most countries. Using
seat belts saves lives. They should be
worn by all occupants, whenever the
vehicle is in use.

A warning indicator on the
instrument pack will illuminate
to alert you that the driver’s

and/or front passenger’s seat belt is
unbuckled. Dependent upon specification
this may be accompanied by an
intermittent chime.

Child Seats

It is important to remember that your
child’s weight, rather than age,
determines the type of seat that is
required.

Refer to Child Safety to determine the
correct seat for your child, see page 69.

Recommended child seat

Jaguar’s recommended the use of a
Lower Anchors and Tethers for CHildren’s
(LATCH) child seat with a top tether strap.

The LATCH child seat can only be fitted in
the outer seating positions of the rear
passenger seat.

Automatic Locking Reels (ALR)

Passenger seat belts have ALR fitted for
use with child seats.
• To engage: extend the belt to the

maximum length to enable the ocking
mechanism.

• To disengage: unbuckle the belt and

allow the belt to fully retract.

With ALR enabled, the seat belt will
automatically lock as it retracts,
preventing re-extension.

Make sure passengers do not fully extend
the restraints and inadvertently engage
this feature during normal use.

OVERHEAD CONSOLE

Rear window blind

Press button 1 to raise the rear window
blind. Press the button again to lower the
blind.

Parking assist

Press button 2 to turn off the front and
rear parking sensors.

JOL4700

Quick Overview

Care points
• Sensors may activate on detection of

water, snow or ice on their surface.
This is entirely normal and regular
cleaning will aid performance.

• Parking assist may sound if it detects

a signal operating at the same
frequency to that of the sensors (e.g.
motorcycles, airbrakes).

Sunroof

The sunroof is fitted with a facility that
allows it to be fully opened or closed with
a single operation of switch 3.

Closing remotely
• If the sunroof has been left open when

leaving the vehicle, it can be closed by
pressing and holding the lock button
on the remote handset.

Garage door opener

The buttons 4 on the overhead console
(see page 13) can be programmed to
transmit radio frequencies that can
operate external devices, i.e. garage
doors, entry gates, security systems, etc.

For more information, see page 50.

CLIMATE CONTROL

These are the primary functions of the
climate control system:

For those vehicles fitted with
the touch-screen navigation
system, the advanced climate

control functions can be accessed by
pressing the Climate button.

AUTO (automatic) mode

Press to select automatic
operation of the climate
control system. The system

will automatically adjust the heat output,
blower speed, air intake and airflow
distribution to maintain the selected
temperature(s) and reduce misting,
without constant adjustments by the
driver or passengers.

JOL4701

˚ C / ˚ F

6 : 46

JOL4702
