Characteristics of JAC vehicle
switch to "INT" position. Use the ad鄄
justing button to change between 1
and 18 seconds. It can change au鄄
tomatically based on the vehicle
speed.
Rear wiper and cleaner switch
1.
When the rear window wiper
blade is in correct position, spray
cleaning agent and run.
2援OFF院If at "OFF" position, the rear
window wiper stops running.
3援INT院It indicates intermittent wiper.
Put the rear window wiper in "INT"
position.
4援ON院If at "ON" position, the rear
window wiper runs continually.
Hazard warning system
If you need to brake for emergency
in a dangerous place, you should
use hazard warning system. For such
braking, please select appropriate
position.
Pressing the hazard warning switch
can turn on hazard warning light.
During this period, all lamps for di鄄
rectional signals will flash. Whether
the ignition key is in "ON" position or
not, hazard warning light will work
normally.
To close hazard warning light, please
press the switch again.
Rear window defroster switch (if
installed)
Press the switch to turn on rear win鄄
dow defroster. At the same time, the
rear defroster indicator will illuminate.
36
Press the switch again to turn off the
defroster. After 15 seconds, the rear
defroster should close automatically.
If you want to turn on the defroster
again, press the switch again after
automatic closing.
Digital clock
The digital clock has three control
buttons. Its functions are as the fol鄄
lowing:
Hour: Press "H" and add figure.
Second: Press "M" and add figure.
Setting: Press "R" and set second as
":00". Now, you can adjust time.
After that period院
Press "R" between 10院30 and 11院29,
you can read 11院00.
Press "R" between 11院30 and 12院29,
you can read 12院00.
Calendar display
Light of control instrument pan鄄
el (rheostat)
Turning the control button of panel
light can adjust its brightness.
Caution院
音 In order to avoid damage of
heat conductor inside the rear
window, do not clean the win鄄
dow with sharp tool or cleaning
agent causing corrosion.
Note院
音 To avoid battery discharging,
the defroster can only be turned
on when the engine is on.
37
