fails during running, please park at a
safe place as soon as possible.
Warning and sound of safety
belt
When the ignition switch is turned to "
ON" or "START" position from "OFF"
position, the warning light will illumi鄄
nate for about 6 seconds. If the pas鄄
senger does not tie the safety belt,
the system will sound at the same
time.
Charging system warning light
When the ignition switch is on,
charging system warning light will il鄄
luminate. After starting the engine,
this warning light should extinguish.
Warning light illuminating during run鄄
ning indicates the failure of charging
system. If such case, drive the vehi鄄
cle to a safe place and park careful鄄
ly. First check the generator driving
belt for loosening or breaking.
Warning light for slightly open
door
When the ignition switch is in any po鄄
sition, if a door does not close tightly,
warning light and buzz will warn at
the same time.
Low fuel warning light
Illumination of this warning light indi鄄
cates that the fuel tank will be empty
soon. In this case, please add fuel
immediately.
When there is no fuel or fuel level is
below "E", if you drive the vehicle, the
engine will stop and the catalytic
converter will be destroyed.
Warning light for opening of
the trunk
When the trunk is open, this system
will warn.
Air bag warning light
When the ignition switch is in "ON"
position, or after starting the engine,
SRS warning light (SRI) will flash for
6 seconds and then extinguish.
When the SRS fails, the warning light
Note院
音 Do not lock the vehicle inside
of it, because the warning light
will still warn under the condition
that the vehicle is locked or the
door is open. In the locked po鄄
sition and when the driver door
is open, buzzer will be on.
Pulling out the key will stop the
warning light and buzzer.
Characteristics of JAC vehicle
28
will also illuminate, if it does not illu鄄
minate, or illuminate for more than 6
seconds, or illuminate during run鄄
ning, please quickly ask JAC dealer
to check.
Failure indicator of engine
This indicator is part of onboard di鄄
agnosis system, and it can monitor
different exhaust emission control
system. When the ignition switch is in
"ON" position, the indicator will illumi鄄
nate, and extinguish after several
seconds. If the running indicator illu鄄
minates or the indicator does not illu鄄
minate in the "ON" position, please
quickly ask JAC dealer to check.
Fuel gauge
Fuel gauge indicates the fuel level in
the fuel tank.
Water temperature gauge of en鄄
gine
If the engine overheats, do not open
the water tank cover; otherwise seri鄄
ous scald will occur. So, you can not
open the water tank cover until the
engine returns to normal tempera鄄
ture.
If the pointer of water temperature
gauge exceeds normal range and is
near to "H" (hot) position, which indi鄄
cates the water temperature is too
high and the engine will be dam鄄
aged. At this time, stop the engine,
open the engine cover, and check
the coolant level and water pump
belt. If there is problem in cooling
system, please ask authorized JAC
dealer to check.
