7B-28 Automatic Transmission (Smoother) 10. Install the parking brake cable clip on the gearshift control box. 11. Connect the neutral switch connector, and install the battery cable clip. 12. Install the connector bracket. a. Install the frame harness clip on the connector bracket, and install the connector bracket on b. Install the reverse switch connector on the connector bracket. 13. Connect the two transmission harness connectors to the frame harness. connectors to the frame harness. b. Install one transmission harness clip and two frame harness clips on the connector bracket. c. Install the transmission harness connectors at two points on the connector bracket, and install
14. Connect the speed sensor connector. Tighten: ⋅m (7.7 kg⋅m / 56.1 lb⋅ft) 16. Install the upper oil filler tube. (Use a new O-ring.) Tighten: ⋅m (4.2 kg⋅m / 30.2 lb⋅ft) 17. Install the starter ground cable. Tighten: ⋅m (4.0 kg⋅m / 28.8 lb⋅ft) 18. Install the two starter harnesses. • Refer to “Parking Brake.” 20. Install the rear propeller shaft. • Refer to “Rear Drive Propeller Shaft”. 21. Install the propeller shaft guard. transmission drain plug and the O-ring (after Tighten: ⋅m (4.0 kg⋅m / 28.8 lb⋅ft) 23. Apply oil (Besco ATF III) to the O-ring, and then install the Smoother oil pan drain plug and the O- Tighten: ⋅m (4.1 kg⋅m / 29.5 lb⋅ft) 24. Supply transmission fluid (Besco ATF III) from the oil filler tube to the Smoother (after disassembly). N7A1032E N7A1030E Legend 1. Transmission Harness Connector N7A1287E |
