7B-20 Automatic Transmission (Smoother) Input Shaft Speed Sensor Removal 1. Connector Inspection • Replace if the harness, the connector or the seal is damaged. • Measure the resistance between terminals. Replace if the resistance between 1 — 2 is not Ω. Installation 1. Input shaft speed sensor • Apply 5W-30 engine oil to the sensor O-ring, and install. Tighten: ⋅m (0.9 kg⋅m / 6.6 lb⋅ft) 2. Connector N7A1025E N7A1026E |
