Engine Mechanical (4HK1-TC) 6A-125 Installation 1. Install the crankshaft front slinger. • Press-fit the slinger using an oil seal installer kit. Legend 1. Front Slinger
Special tool • Insert the front slinger into the end of the adapter and fit them on the crankshaft. • Put the sleeve over the adapter, place a washer on the center bolt and tighten the bolt until the • After you have pressed the front slinger, confirm the measurement shown (depth from the end Caution: Legend 1. Adapter ± 0.3 mm (1.594 ± 0.012 in) 5. 34 ± 0.1 mm (1.339 ± 0.004 in) No. Part Name Slinger Oil seal 1 Sleeve (front) { { 2 Adapter (front) { { 3 Adapter ring (front) — { 4 Washer (front) { { 5 Center bolt { { 6 Fixing bolt { { N6A6237E N6A6238E N6A6239E |
