Engine Mechanical (4HK1-TC) 6A-53 Tighten: ⋅m (0.8 kg⋅m/69 lb⋅in) • Apply engine oil over the O-ring nice and thin and install it. Legend 1. Adapter
17. Install the cylinder head assembly. Refer to “Cylinder Head”. 18. Install the camshaft assembly. Refer to “Camshaft Assembly”. 19. Install the rocker arm shaft assembly. Refer to “Rocker Arm Shaft Assembly”. 20. Install the cylinder head cover. Refer to “Cylinder Head Cover”. N6A6081E |
