Engine Mechanical (4HK1-TC) 6A-49 Tighten: ⋅m (9.8 kg⋅m/71 lb⋅ft) Bolts (2) to 77 N ⋅m (7.9 kg⋅m/57 lb⋅ft) Bolts (3) to 38 N ⋅m (3.9 kg⋅m/28 lb⋅ft) • Tighten up the Mark 3 from the cylinder block side. 5. Install the power steering pump idle gear. • Apply engine oil over the part where the gear of the idle gear shaft is to be put together. • Put the idle gear and the shaft together and install it on the location given on the figure and Tighten: ⋅m (13.6 kg⋅m/98 lb⋅ft) N6A6070E N6A6071E |
