Engine Mechanical (4HK1-TC) 6A-17 • Operate a hoist slowly and hoist the engine until it comes up to the surface of the chassis • Turn the engine at an angle of 90 degrees to move from the surface of the chassis frame and Installation Notice: 1. Install the engine assembly. • Hang wire on the engine hanger and hoist to lift up the engine. • Operate a hoist slowly to move the engine to the place where it is to be installed. • Turn the engine at an angle of 90 degrees to lower the engine slowly to the place it is to be • Make the transmission side lower and operate a hoist slowly, pulling it backward to the engine. 2. Install the engine mount. • Install the engine mount to fit into the holes of the engine mounting cross member and tighten Tighten: ⋅m (4.9 kg⋅m/35 lb⋅ft) 3. Install the feed and return sides of the fuel hose. N6A6016E N6A6017E N6A6017E N6A6016E |
