6C-38 FUEL SYSTEM 7) Adjust injection pump downward so that the “8 °” (98EPA) or “9°” (Spec EURO3) comes to position in the timing check hole. (for 4HE1-TC Notice: 8) Tighten the injection pump bracket nuts and bolts to the specified torque. Tighten: ⋅m (4.9 kg⋅m / 35 lb ⋅ft) 9) Install the injection pump rear bracket. Tighten: ⋅m (4.9 kg⋅m / 35 lb ⋅ft) 10) Install the inspection hole plug. Tighten: ⋅m (4.9 kg⋅m / 35 lb⋅ft) Notice: ° mark on the second crest and (2) TDC mark on the third crest (as viewed from the front side), be sure Legend 1. TDC Legend 1. 8 ° mark 2. Pointer ° mark 4. Timing check hole N6A0910E N6A0911E N6A0912E |
