6A-18 ENGINE MECHANICAL Camshaft and Camshaft Bearing Clearance Use an inside dial indicator to measure the camshaft If the clearance between the camshaft bearing inside di- Reassembly 1. Key • With the projection of the camshaft gear center boss turned to the camshaft side, set it to the knock Tighten: ⋅m (14.5 kg⋅m / 105 lb⋅ft) 3. Camshaft Bearing Lower Above works refer to “CYLINDER HEAD” section Camshaft Bearing Inside mm (in) Standard 40.000 — 40.037 (1.5748 — 1.5763) Camshaft Bearing Clear- mm (in) Standard Limit 0.025 — 0.087 (0.00098 — 0.00343) 0.15 (0.0059) N6A0147E N6A0148E N6A0149E |
