3B4-8 STEERING COLUMN 3. Starter Switch and Key Cylinder Assembly • Install the steering lock assembly and insert the snap ring positively. • Use new screws. 4. Tilt Control (or Support Bolt) • Tighten the retaining nuts for the lower steering column support brackets to the specified torque. • Tighten the nuts outside the tilt control to the spec- ified torque to install the lever, and tighten the lever Tighten: • Lower support bolt and nut to 14 N ⋅m (1.4 kg⋅m/122 lb ⋅ft) • Tilt control bolt and nut to Bolt : 45 N ⋅m (4.5 kg⋅m/33 lb⋅ft) Nut : 16 N ⋅m (1.6 kg⋅m/12 lb⋅ft) Nut (Non-tilt) : 20 N ⋅m (2.0 kg⋅m/14 lb⋅ft) 5. Steering Wheel • Install the combination switch. the specified torque. Tighten: • Steering wheel nut to 50 N ⋅m (5 kg⋅m/36 lb⋅ft) 6. Horn Button • Hook up the harness connectors and install the steering cowl. N3A0335E N3A0344E N3A0336E N3A0329E |
