SRS 9B-19 3. Remove the glove box, and connect the SRS air- bag onboard deployment tool to disposal connec- Legend 1. Disposal connector 4. Place SRS airbag onboard deployment tool away from it. 5. Make sure that there are no personnel, objects or flammable materials in or around the vehicle. 6. Cover windshield glass and front door glass with cloth or blanket completely. This reduces possibili- 7. Turn on the SRS airbag onboard deployment tool. This activates SRS control unit to be ready for de- Caution: Let nearby personnel know about SRS deployment be- 8. Press the two ignition switches on SRS airbag on- board deployment tool at the same time to deploy 9. If SRS airbag has not been deployed in these steps, perform the steps from 10 to 11, then from 10. Carefully remove the cloth from the vehicle, and re- move broken pieces from it or dispose itself. 11. Remove the SRS airbag onboard deployment tool from the vehicle. 12. After deploying SRS airbag, the vehicle can be dis- posed in the same method as vehicles non- 13. Remove the undeployed SRS airbag from the ve- hicle. Refer to “Removal” in “SRS Airbag Assem- WARNING: WHEN STORING UNDEPLOYED SRS AIRBAG AS- 14. Store temporarily the SRS airbag with the trim cov- er facing upward. Do not pile it up. Removal 1. Stop the function of SRS. (Refer to “Procedure to stop the function of SRS” in “SRS System Assem- 2. Loosen the mounting bolt from the back of steering wheel using TORX ® driver or equivalent to remove SRS airbag. 1 N9A0043E N9A0039E N9A0044E |
