Infiniti Q50 (2018 year). Instruction - part 8





2-38

Instruments and controls

— The brightness of the headlights

of the oncoming vehicle or leading
vehicle.

— The movement and direction of

the oncoming vehicle and the
leading vehicle.

— When only one light on the on-

coming vehicle or the leading
vehicle is illuminated.

— When the oncoming vehicle or the

leading vehicle is a two-wheeled
vehicle.

— Road conditions (incline, curve,

the road surface, etc.).

— The number of passengers and

the amount of luggage.

JVI0686X

High beam assist operations:
To activate the high beam assist system,
turn the headlight switch to the AUTO
position

and push the lever forward

(high beam position). The high beam assist
indicator light in the meter will illuminate
while the headlights are turned on.
If the high beam assist indicator light does
not illuminate in the above condition, it may
indicate that the system is not functioning
properly. It is recommended you have the
system checked by an INFINITI retailer.
When the vehicle speed lowers to less than
approximately 17 MPH (27 km/h), the head-
light remains the low beam.

To turn off the high beam assist system, turn
the headlight switch to the

position or

select the low beam position by placing the
lever in the neutral position.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVI0670X

Ambient image sensor maintenance:
The ambient image sensor

for the high

beam assist system is located in front of the
inside mirror. To keep the proper operation
of the high beam assist system and prevent a
system malfunction, be sure to observe the
following:
. Always keep the windshield clean.

. Do not attach a sticker (including trans-

parent material) or install an accessory
near the ambient image sensor.

. Do not strike or damage the areas around

the ambient image sensor. Do not touch
the sensor lens that is located on the
ambient image sensor.

If the ambient image sensor is damaged due
to an accident, it is recommended you
contact an INFINITI retailer.

Battery saver system

A chime will sound and the light reminder
warning will appear in the vehicle informa-
tion display when the driver side door is
opened with the light switch in the

or

position and the ignition switch in the

ACC, OFF or LOCK position.
When the headlight switch is in the

or

position while the ignition switch is in

the ON position, the lights will automatically
turn off after a period of time when the
ignition switch has been pushed to the OFF
position.
When the headlight switch remains in the

or

position after the lights auto-

matically turn off, the lights will turn on
when the ignition switch is pushed to the ON
position.

CAUTION

When you turn on the headlight

switch again after the lights auto-
matically turn off, the lights will not
turn off automatically. Be sure to
turn the light switch to the OFF
position when you leave the vehicle

for extended periods of time, other-
wise the battery will be discharged.

Never leave the light switch on when

the engine is not running for a period
of time even if the headlights turn off
automatically.

Daytime running light system

The daytime running lights automatically
illuminate when the engine is started with
the parking brake released. The daytime
running lights operate with the headlight
switch in the OFF, AUTO or

position.

Turn the headlight switch to the

position

for full illumination when driving at night.
If the parking brake is applied before the
engine is started, the daytime running lights
do not illuminate. The daytime running lights
illuminate once the parking brake is released.
The daytime running lights will remain on
until the ignition switch is pushed to the OFF
position.

WARNING

When the daytime running light system
is active, tail lights on your vehicle are
not on. It is necessary at dusk to turn on
your headlights. Failure to do so could
cause an accident injuring yourself and

Instruments and controls

2-39

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-40

Instruments and controls

others.

Adaptive Front lighting System
(AFS) (if so equipped)

The Adaptive Front lighting System (AFS)
will automatically adjust the headlights (low
beam) toward the turning direction to
improve the driver’s view. When the head-
light switch is ON and the driver operates
the steering wheel in a turn, the AFS system
will be activated.
The AFS will operate:
. when the headlight switch is ON.

. when the shift lever is in any position

other than P (Park) or R (Reverse).

. when the vehicle is driven at above 3

MPH (5 km/h) for the left-side head-
light. Note that the right-side low beam
headlight will swivel but the left-side
headlight will not swivel when the vehicle
is below 3 MPH (5 km/h) and the
steering wheel is turned.

AFS will also adjust the headlight to a proper
axis automatically, depending on the number
of occupants in the vehicle, the load the
vehicle is carrying and the road conditions.
If the AFS warning appears in the vehicle
information display after the ignition switch
has been pushed to the ON position, this

may indicate that the AFS is not functioning
properly. Have the system checked. It is
recommended you visit an INFINITI retailer
for this service. When the engine is started,
the headlights will vibrate to check the
system condition. This is not a malfunction.

JVI0644X

JVI0937X

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Instrument brightness control

The instrument brightness control switch
can be operated when the ignition switch is
in the ON position. When the switch is
operated, the vehicle information display
switches to the brightness adjustment
mode.
Push the + side of the switch

to brighten

the instrument panel lights. The bar

moves

to the + side.
Push the - side of the switch

to dim the

instrument panel lights. The bar

moves to

the − side. When the brightness level reaches
the minimum, the instrument panel lights will
turn off during the nighttime.
When the brightness level reaches the max-
imum or minimum, a beep will sound.
The vehicle information display returns to
the normal display when the instrument
brightness control switch is not operated
for more than 5 seconds.

SIC3271

TURN SIGNAL SWITCH

Turn signal

Move the lever up or down to signal the
turning direction. When the turn is com-
pleted, the turn signals cancel automatically.

Lane change signal

. Move the lever up or down until the turn

signal begins to flash, but the lever does
not latch, to signal a lane change. Hold
the lever until the lane change is com-
pleted.

. Move the lever up or down until the turn

signal begins to flash, but the lever does
not latch, and release the lever. The turn

signal will automatically flash three
times.

Choose the appropriate method to signal a
lane change based on road and traffic
conditions.

Instruments and controls

2-41

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-42

Instruments and controls

SIC3272

FOG LIGHT SWITCH

To turn the fog lights on, turn the headlight
switch to the

position, then turn the

switch to the

position. To turn them off,

turn the switch to the OFF position.
The headlights must be on with the low
beams selected for the fog lights to operate.
The fog lights automatically turn off when
the high beam headlights are selected.

JVI1491X

To sound the horn, push the center pad area
of the steering wheel.

WARNING

Do not disassemble the horn. Doing so
could affect proper operation of the
supplemental front air bag system. Tam-
pering with the supplemental front air
bag system may result in serious perso-
nal injury.

SIC4336

The vehicle should be driven with the Vehicle
Dynamic Control (VDC) system on for most
driving conditions.
If the vehicle is stuck in mud or snow, the
VDC system reduces the engine output to
reduce wheel spin. The engine speed will be
reduced even if the accelerator is depressed
to the floor. If maximum engine power is
needed to free a stuck vehicle, turn the VDC
system off.
To turn off the VDC system, push the VDC
OFF switch. The

indicator light will

illuminate.
Push the VDC OFF switch again or restart
the engine to turn on the system. (See
“Vehicle Dynamic Control (VDC) system”

HORN

VEHICLE DYNAMIC CONTROL
(VDC) OFF SWITCH

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(P.5-132).)

WARNING

Do not use or allow occupants to use the
seat heater if you or the occupants
cannot monitor elevated seat tempera-
tures or have an inability to feel pain in
those body parts in contact with the
seat. Use of the seat heater by such
people could result in serious injury.

CAUTION

The battery could run down if the

seat heater is operated while the
engine is not running.

Do not use the seat heater for

extended periods or when no one is
using the seat.

Do not put anything on the seat

which insulates heat, such as a blan-
ket, cushion, seat cover, etc. Other-
w i s e , t h e s e a t m a y b e c o m e
overheated.

Do not place anything hard or heavy

on the seat or pierce it with a pin or
similar object. This may result in
damage to the heater.

Any liquid spilled on the heated seat

should be removed immediately with
a dry cloth.

When cleaning the seat, never use

gasoline, thinner, or any similar ma-
terials.

If any malfunctions are found or the

heated seat does not operate, turn
the switch off and have the system
checked. It is recommended you visit
an INFINITI retailer for this service.

Instruments and controls

2-43

HEATED SEATS (if so equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-44

Instruments and controls

JVR0505X

The front seats can be warmed by built-in
heaters. The heating system of driver’s seat
and front passenger seat can be operated
independently.

OPERATION WITH SWITCH

1. Start the engine.
2. Push the switch on the instrument panel.

.

Each time the switch is pushed, the

seat heating mode will change in the
following order.
AUTO

? High ? Mid ? Low ? OFF

.

The indicator light on the switch will

illuminate when the heater is on.

When the vehicle’s interior is warmed, or
before you leave the vehicle, be sure to turn

off the seat heater.

OPERATION WITH TOUCH
SCREEN

Push the CLIMATE button and touch [

]

or [

] on the lower display. Select an item

from [AUTO], [High], [Mid], [Low] or [OFF].

AUTO MODE SETTING

When in the AUTO mode, the heater will
turn on or off automatically according to the
conditions such as the temperature inside
the vehicle compartment. Depending on the
conditions, the heater will not turn on even if
AUTO is selected. The settings for the AUTO
mode can be changed. For details, see the
Infiniti InTouch Owner’s Instruction.

WARNING

Do not use or allow occupants to come
into contact with the heated steering
wheel if you or the occupants cannot
monitor elevated steering wheel tem-
peratures or have an inability to feel pain
in those body parts in contact. Use of the
heated steering wheel by such people
could result in serious injuries.

CAUTION

The battery could run down if the

steering wheel heater is operated
while the engine is not running.

Do not use the steering wheel heater

for extended periods of time as it may
cause burns and overheating.

Any liquid spilled on the steering

wheel should be removed immedi-
ately with a dry cloth.

When cleaning the steering wheel,

never use gasoline, thinner, or any
similar materials.

If any malfunctions are found or the

steering wheel heater does not oper-
ate, turn the switch off and have the

HEATED STEERING WHEEL (if so
equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

system checked. It is recommended
that you visit an INFINITI retailer for
this service.

Push the CLIMATE button and touch
[Steering Heater] on the lower display to
turn on or off the steering wheel heating
instructionly. The steering wheel heating will
turn off automatically 30 minutes after it
has been turned on. When the steering
wheel heating is turned on, the indicator
above [Steering Heater] will turn on.
If the surface temperature of the steering
wheel is above the temperature within which
the system is designed to operate, the
system will not heat the steering wheel. This
is not a malfunction.
Automatic steering wheel heating can be
turned on or off from the climate control
settings screen. For details, see the Infiniti
InTouch Owner’s Instruction.

SIC4316

In the storage box

JVI1298X

In the console box

The power outlets are located in the storage
box and in the console box.

CAUTION

The outlet and plug may be hot

during or immediately after use.

Do not use with accessories that

exceed a 12 volt, 120W (10A) power
draw. Do not use double adapters or
more than one electrical accessory.

Use power outlet with the engine

running to avoid discharging the
vehicle battery.

Avoid using power outlet when the

air conditioner, headlights or rear
window defroster is on.

This power outlet is not designed for

use with a cigarette lighter unit.

Push the plug in as far as it will go. If

good contact is not made, the plug
may overheat or the internal tem-
perature fuse may blow.

Before inserting or disconnecting a

plug, be sure the electrical accessory
being used is turned OFF.

When not in use, be sure to close the

cap. Do not allow water or any liquid
to contact the outlet.

Instruments and controls

2-45

POWER OUTLETS

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-46

Instruments and controls

SIC2570

REAR

To open the ashtray lid, pull

.

To empty the ashtray, push down

, and pull

out.

CUP HOLDERS

CAUTION

Avoid abrupt starting and braking

when the cup holder is being used to
prevent spilling the drink. If the liquid
is hot, it can scald you or your
passenger.

Use only soft cups in the cup holder.

Hard objects can injure you in an
accident.

JVI0649X

Front

JVI0650X

Rear

ASHTRAY

STORAGE

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Open the lid of the rear armrest to use the
cup holder.

JVI0715X

SOFT BOTTLE HOLDER

CAUTION

Do not use bottle holder for any other

objects that could be thrown about in
the vehicle and possibly injure people
during sudden braking or an accident.

Do not use bottle holder for open

liquid containers.

JVI0651X

SUNGLASSES HOLDER

WARNING

Keep the sunglasses holder closed while
driving to avoid obstructing the driver’s
view and to help prevent an accident.

To open the sunglasses holder, push the
holder.

Instruments and controls

2-47

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-48

Instruments and controls

CAUTION

Do not use for anything other than

glasses.

Do not leave glasses in the sunglasses

holder while parking in direct sun-
light. The heat may damage the
glasses.

JVI0763X

GLOVE BOX

WARNING

Keep glove box lid closed while driving to
help prevent injury in an accident or a
sudden stop.

To open the glove box, pull the handle

.

To close, push the lid in until the lock latches.
To lock

/unlock

the glove box, use the

mechanical key. For the mechanical key
usage, see “Keys” (P.3-2).

JVI0653X

CONSOLE BOX

To open the console box, push up the knob
and pull up the lid.
To close, push the lid down until latched.
The console box light illuminates when the
headlight switch is in the

position.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SIC4348

CARD HOLDER

The card holder is located on the driver’s or
passenger’s sun visor.
To use the card holder, slide the card in the
card holder.

JVI0664X

STORAGE BOX

To open, push the storage box lid.
Do not place valuable items in the storage
box.
Do not use the storage box as an ashtray.

SIC3248

COAT HOOKS

The coat hooks are equipped beside the rear
personal lights.

CAUTION

Do not place items which are more than
2 lb (1 kg) on the hook.

Instruments and controls

2-49

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-50

Instruments and controls

SIC4350

TRUNK HOOKS

WARNING

Always make sure that the cargo is

properly secured. Use the suitable
ropes and hooks.

Unsecured cargo can become danger-

ous in an accident or sudden stop.

CAUTION

Do not apply a total load of more than
22 lb (10 kg) to a single hook.

POWER WINDOWS

WARNING

Make sure that all passengers have

their hands, etc. inside the vehicle
while it is in motion and before
closing the windows. Use the window
lock switch to prevent unexpected
use of the power windows.

To help avoid risk of injury or death

through unintended operation of the
vehicle and or its systems, including
entrapment in windows or inadver-
tent door lock activation, do not
leave children, people who require
the assistance of others or pets
unattended in your vehicle. Addition-
ally, the temperature inside a closed
vehicle on a warm day can quickly
become high enough to cause a sig-
nificant risk of injury or death to
people and pets.

The power windows operate when the
ignition switch is in the ON position or for
about 45 seconds after the ignition switch is
pushed to the OFF position. If the driver’s or
front passenger’s door is opened during this
period of about 45 seconds, power to the
windows is canceled.

WINDOWS

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVI0740X

1.

Driver side window

2.

Front passenger side window

3.

Rear left passenger side window

4.

Rear right passenger side window

5.

Window lock button

Main power window switch (dri-
ver’s side)

To open or close the window, push down
or pull up

the switch and hold it. The main

switch (driver side switches) will open or
close all the windows.

Locking passengers’ windows

When the lock button

is pushed in, only

the driver side window can be opened or
closed. Push it in again to cancel.

SIC4353

Passenger side power window
switch

The passenger side switch will open or close
only the corresponding window. To open or
close the window, push down or pull up the
switch and hold it.

Instruments and controls

2-51

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-52

Instruments and controls

SIC4354

Automatic operation

To fully open or close the window, comple-
tely push down or pull up the switch and
release it; it need not be held. The window
will automatically open or close all the way.
To stop the window, just push or lift the
switch in the opposite direction.
A light push or pull on the switch will cause
the window to open or close until the switch
is released.

Auto reverse function

WARNING

There are some small distances immedi-
ately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., inside
the vehicle before closing the window.

If the control unit detects something caught
in the window as it is closing, the window
will be immediately lowered.
The auto reverse function can be activated
when the window is closed by automatic
operation when the ignition switch is in the
ON position or for 45 seconds after the
ignition switch is pushed to the OFF posi-
tion.
Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the window
occurs.

If the windows do not close auto-
matically

If the power window automatic function
(closing only) does not operate properly,
perform the following procedure to initialize

the power window system.
1. Place the ignition switch in the ON

position.

2. Close the door.
3. Open the window completely by operat-

ing the power window switch.

4. Pull the power window switch and hold it

to close the window, and then hold the
switch more than 3 seconds after the
window is closed completely.

5. Release the power window switch. Op-

erate the window by the automatic
function to confirm the initialization is
complete.

6. Perform steps 2 through 5 above for

other windows.

If the power window automatic function
does not operate properly after performing
the procedure above, it is recommended you
have your vehicle checked by an INFINITI
retailer.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

In an accident you could be thrown

from the vehicle through an open
moonroof. Always use seat belts
and child restraints.

Do not allow anyone to stand up or

extend any portion of their body out
of the moonroof opening while the
vehicle is in motion or while the
moonroof is closing.

CAUTION

Remove water drops, snow, ice or

sand from the moonroof before
opening.

Do not place any heavy object on the

moonroof or surrounding area.

POWER MOONROOF

The moonroof only operates when the
ignition switch is in the ON position.
The moonroof is operational for about 45
seconds, even if the ignition switch is pushed
to the OFF position. If the driver’s door or
the passenger’s door is opened during this
period of about 45 seconds, power to the
moonroof is canceled.

JVI0655X

Sunshade

The sunshade will open automatically when
the moonroof is opened. However, it must
be closed instructionly.

Tilting the moonroof

To tilt up, first close the moonroof, then
push the switch to the tilt up position

and

release it; it need not be held. To tilt down
the moonroof, push the switch to the tilt
down position

.

Sliding the moonroof

To fully open or close the moonroof, push
the switch to the open

or close

position

and release it; it need not be held. The roof

Instruments and controls

2-53

MOONROOF (if so equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     6      7      8      9     ..
