Infiniti M45 (2010 year). Instruction

Main power window switch (driver’s

side)

1. Driver side window
2. Front passenger side window
3. Rear left passenger side window
4. Rear right passenger side window
5. Window lock button
To open or close the window, push down

pull up

the switch and hold it. The main

switch (driver side switches) will open or close

all the windows.

Locking passengers’ windows

When the lock button

is pushed in, only the

driver side window can be opened or closed.

Push it in again to cancel.

Passenger side power window switch

The passenger side switch will open or close

only the corresponding window. To open or

close the window, push down or pull up the

switch and hold it.

SIC3279

SIC3241

2-44

Instruments and controls

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Automatic operation (for all door

windows)

To fully open or close the window, completely

push down or pull up the switch and release it;

it need not be held. The window will automati-

cally open or close all the way. To stop the

window, just push or lift the switch in the

opposite direction.
A light push or pull on the switch will cause the

window to open or close until the switch is

released.

Auto reverse function

WARNING

There are some small distances immediately

before the closed position which cannot be de-

tected. Make sure that all passengers have

their hands, etc., inside the vehicle before clos-

ing the window.

If the control unit detects something caught in

the window as it is closing, the window will be

immediately lowered.
The auto reverse function can be activated when

the window is closed by automatic operation

when the ignition switch is in the ON position or

for 45 seconds after the ignition switch is

pushed to the LOCK position.
Depending on the environment or driving condi-

tions, the auto reverse function may be activated

if an impact or load similar to something being

caught in the window occurs.

If the windows do not close

automatically

If the power window automatic function (closing

only) does not operate properly, perform the

following procedure to initialize the power win-

dow system.
1. Push the ignition switch to the ON posi-

tion.

2. Close the door.
3. Open the window completely by operating

the power window switch.

4. Pull the power window switch and hold it

to close the window, and then hold the

switch more than 3 seconds after the

window is closed completely.

5. Release the power window switch. Oper-

ate the window by the automatic function

to confirm the initialization is complete.

6. Perform steps 2 through 5 above for other

windows.

If the power window automatic function does

not operate properly after performing the pro-

cedure above, have your vehicle checked by an

INFINITI retailer.

SIC3289

Instruments and controls

2-45

—

05/19/09—tbrooks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

● In an accident you could be thrown from the

vehicle through an open moonroof. Always

use seat belts and child restraints.

● Do not allow anyone to stand up or extend

any portion of their body out of the moonroof

opening while the vehicle is in motion or

while the moonroof is closing.

CAUTION

● Remove water drops, snow, ice or sand from

the moonroof before opening.

● Do not place any heavy object on the moon-

roof or surrounding area.

AUTOMATIC MOONROOF

The moonroof only operates when the ignition

switch is in the ON position.
The automatic moonroof is operational for

about 45 seconds, even if the ignition switch is

pushed to the LOCK position. If the driver’s door

or the passenger’s door is opened during this

period of about 45 seconds, power to the

moonroof is canceled.

Sunshade

The sunshade will open automatically when the

moonroof is opened. However, it must be

closed instructionly.

Tilting the moonroof

To tilt up, first close the moonroof, then push

the OPEN

side of the moonroof switch and

release it; it need not be held. To tilt down the

moonroof, push the CLOSE

side.

Sliding the moonroof

To fully open or close the moonroof, push the

OPEN

or CLOSE

side of the moonroof

switch and release it; it need not be held. The

roof will automatically open or close all the way.

To stop the roof, push the switch once more

while it is opening or closing.

Auto reverse function

WARNING

There are some small distances immediately

before the closed position which cannot be de-

tected. Make sure that all passengers have

their hands, etc., inside the vehicle before clos-

ing the moonroof.

If the control unit detects something caught in

the moonroof when it is closing, the moonroof

will be immediately opened.
The auto reverse function can be activated when

the moonroof is closed by automatic operation

when the ignition switch is in the ON position or

for about 45 seconds after the ignition switch is

pushed to the LOCK position.
If the moonroof cannot be closed automatically

when the auto reverse function activates due to

a malfunction, push and hold the CLOSE

side of the moonroof switch.
Depending on the environment or driving condi-

tions, the auto reverse function may be activated

if an impact or load similar to something being

caught in the moonroof occurs.

SIC3888

MOONROOF

2-46

Instruments and controls

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If the moonroof does not operate

If the moonroof does not operate properly,

perform the following procedure to initialize the

moonroof operation system.
1. If the moonroof is open, close it fully by

repeatedly pushing the CLOSE

side of

the moonroof switch.

2. Push and hold the CLOSE

side of the

moonroof switch to tilt the moonroof up.

3. Release the moonroof switch after the

moonroof moves slightly up and down.

4. Push and hold the OPEN

side of the

moonroof switch to fully tilt the moonroof

down.

5. Check if the moonroof switch operates

normally.

If the moonroof does not operate properly after

performing the procedure above, have your

vehicle checked by an INFINITI retailer.

The rear control cancel switch is located on the

center console.
Pushing the rear control cancel switch to the

cancel side will deactivate the following

switches in the rear center armrest.
● Automatic climate control
● Audio

CAUTION

● To avoid personal injury, keep your hands,

fingers and head away from the sunshade

arm, arm rail and screen inlet port.

● Do not allow children near the rear sunshade

system. They could be injured.

● Do not place objects on or near the rear sun-

shade. This could cause improper operation

or damage it.

● Do not pull or push the rear sunshade. This

could cause improper operation or damage

it.

SIC2786

REAR CONTROL CANCEL SWITCH (if so

equipped)

REAR SUNSHADE (if so equipped)

Instruments and controls

2-47

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The rear sunshade operates when the ignition

switch is in the ON position.
The rear sunshade switches are located on the

center console and inside the rear armrest.
To raise the screen, push the UP side of the

switch

To lower the screen, push the DOWN side of the

switch

. The switch need not be held.

CAUTION

● Do not place objects (such as newspapers,

handkerchiefs, etc.) on the screen inlet port.

Doing so may entangle these objects in the

screen when it is extending or retracting,

causing improper operation or damage to

the screen.

● Do not push the sunshade arm with your

hands, etc., as this may deform it. Improper

operation or damage to the screen may

result.

● Do not put any object into the screen inlet

port as this may result in improper operation

or damage the screen.

● Do not hang any object on the arm rail as this

may result in improper operation or damage

the screen.

● Do not forcefully pull the screen. Doing so

may elongate the screen. Improper opera-

tion or damage to the screen may result.

CAUTION

Do not use for extended periods of time with

the engine stopped. This could result in a dis-

charged battery.

SIC2787

INTERIOR LIGHTS

2-48

Instruments and controls

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MAP LIGHTS

Push the button as illustrated to turn the light

on or off.

PERSONAL LIGHTS
Rear

Push the button as illustrated to turn the light

on or off.

INTERIOR LIGHT CONTROL SWITCH

The interior light control switch has two posi-

tions: DOOR and OFF.

DOOR position

When the switch is in the DOOR position

, the

map lights and rear personal lights will illumi-

nate under the following conditions:
● ignition switch is in the LOCK position

– remain on for about 15 seconds.

SIC3889

SIC2789

SIC3890

Instruments and controls

2-49

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

● doors are unlocked by pushing the UNLOCK

button

on the Intelligent Key or door

handle request switch with the ignition

switch in the LOCK position

– remain on for about 15 seconds.

● any door is opened and then closed with the

ignition switch in the LOCK position

– remain on for about 15 seconds.

● any door is opened with the ignition switch

in the ACC or ON position

– remain on while the door is opened.

When the door is closed, the lights go off.

The lights will turn off after 30 minutes when the

lights remain illuminated to prevent the battery

from becoming discharged.

When the auto interior illumination is set to the

OFF position (see “VEHICLE INFORMATION AND

SETTINGS” in the “4. Monitor, climate, audio,

phone and voice recognition systems” section),

the lights will illuminate under the following

condition:
● any door is opened with the ignition switch

in any position

– remain on while the door is opened.

When the door is closed, the lights go off.

OFF position

When the switch is in the OFF position

, the

lights will not illuminate, regardless of the

condition.

The light on the vanity mirror will turn on when

the cover on the vanity mirror is opened.
When the cover is closed, the light will turn off.
The lights will turn off after 30 minutes when the

lights remain illuminated to prevent the battery

from becoming discharged.

SIC2555B

VANITY MIRROR LIGHTS

2-50

Instruments and controls

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The light illuminates when the trunk lid is

opened. When the trunk lid is closed, the light

will turn off.
The light will turn off after 30 minutes when the

light remains illuminated to prevent the battery

from becoming discharged.

HomeLink

T Universal Transceiver provides a

convenient way to consolidate the functions of

up to three individual hand-held transmitters

into one built-in device.
HomeLink

T Universal Transceiver:

● Will operate most Radio Frequency (RF) de-

vices such as garage doors, gates, home and

office lighting, entry door locks and security

systems.

● Is powered by your vehicle’s battery. No

separate batteries are required. If the vehi-

cle’s battery is discharged or is discon-

nected, HomeLink

T will retain all program-

ming.

Once HomeLinkT Universal Transceiver is pro-

grammed, retain the original transmitter for fu-

ture programming procedures (Example: new ve-

hicle purchases). Upon sale of the vehicle, the

programmed HomeLinkT Universal Transceiver

buttons should be erased for security purposes.

For additional information, see “PROGRAMMING

HomeLinkT” later in this section.

WARNING

● Do not use HomeLinkT Universal Transceiver

with any garage door opener that lacks

safety stop and reverse features as required

by federal safety standards. (These stan-

dards became effective for opener models

manufactured after April 1, 1982.) A garage

door opener which cannot detect an object in

the path of a closing garage door and then

automatically stop and reverse, does not

meet current federal safety standards. Using

a garage door opener without these features

increases the risk of serious injury or death.

● During programming procedure, your garage

door or security gate may open or close.

Make sure that people and objects are clear

of the garage door, gate, etc. that you are

programming.

● Your vehicle’s engine should be turned off

while programming HomeLinkT Universal

Transceiver.

PROGRAMMING HOMELINK

To program your HomeLink

T Transceiver to op-

erate a garage door, gate, or entry door opener,

home or office lighting, you need to be at the

same location as the device. Note: Garage door

openers (manufactured after 1996) have “rolling

TRUNK LIGHT

HOMELINKT UNIVERSAL TRANSCEIVER

Instruments and controls

2-51

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

code protection”. To program a garage door

opener equipped with “rolling code protection”;

you will need to use a ladder to get up to the

garage door opener motor to be able to access

the “smart or learn” program button.

1. To begin, push and hold the 2 outer

HomeLink

T buttons (to clear the memory)

until the indicator light

blinks (after 20

seconds). Release both buttons.

2. Position the end of the hand-held trans-

mitter 1 to 3 in (20 to 70 mm) away from

the HomeLink

T surface.

3. Using both hands, simultaneously push

and hold both the HomeLink

T button you

want to program and the hand-held trans-

mitter button.
DO NOT release the buttons until step 4 has

been completed.

SIC3612

SIC3613

2-52

Instruments and controls

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

4. Hold down both buttons until the indica-

tor light on HomeLink

T flashes, changing

from a “slow blink” to a “rapid blink”.

This could take up to 90 seconds. When

the indicator light blinks rapidly, both

buttons may be released. The rapidly

flashing light indicates successful pro-

gramming. To activate the garage door or

other programmed device, push and hold

the programmed HomeLink

T button - re-

leasing when the device begins to acti-

vate.

5. If the indicator light on HomeLink

T blinks

rapidly for two seconds and then turns

solid, HomeLink

T has picked up a “rolling

code” garage door opener signal. You will

need to proceed with the next steps to

train HomeLink

T, completing the pro-

gramming may require a ladder and an-

other person for convenience.

6. Push and release the program button

located on the garage door opener’s mo-

tor to activate the “training mode”. This

button is usually located near the an-

tenna wire that hangs down from the

motor. If the wire originates from under a

light lens, you will need to remove the

lens to access the program button.

NOTE:
Once you have pushed and released the training

button on the garage door opener’s motor and

the “training light” is lit, you have 30 seconds in

which to perform step 7. For convenience, use

the help of a second person to assist when per-

forming this step.
7. Quickly (within 30 seconds of pushing

and releasing the garage door opener

program button) and firmly push and re-

lease the HomeLink

T button you’ve just

programmed. Push and release the

HomeLink

T button up to three times to

complete the training.

8. Your HomeLink

T button should now be

programmed.

To program the remaining HomeLink

T buttons

for additional door or gate openers, follow

steps 2 through 8 only.

NOTE:
Do not repeat step 1 unless you want to “clear”

all previously programmed HomeLinkT buttons.
If you have any questions or are having diffi-

culty programming your HomeLink

T buttons,

please refer to the HomeLink

T web site at:

www.homelink.com or call 1-800-355-3515.

PROGRAMMING HOMELINK

T FOR

CANADIAN CUSTOMERS

Prior to 1992, D.O.C. regulations required hand-

held transmitters to stop transmitting after 2

seconds. To program your hand-held transmit-

ter to HomeLink

T, continue to push and hold

the HomeLink

T button (note steps 2 through 4

under “Programming HomeLink

T”) while you

push and re-push (“cycle”) your hand-held

transmitter every 2 seconds until the indicator

light flashes rapidly (indicating successful pro-

gramming).

NOTE:
If programming a garage door opener, etc., it is

advised to unplug the device during the “cy-

cling” process to prevent possible damage to

the garage door opener components.

OPERATING THE HOMELINK

UNIVERSAL TRANSCEIVER

HomeLink

T Universal Transceiver (once pro-

grammed) may now be used to activate the

garage door, etc. To operate, simply push the

appropriate programmed HomeLink

T Universal

Transceiver button. The red indicator light will

illuminate while the signal is being transmitted.

Instruments and controls

2-53

—

05/19/09—tbrooks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PROGRAMMING TROUBLE-DIAGNOSIS

If HomeLink

T does not quickly learn the hand-

held transmitter information:
● replace the hand-held transmitter batteries

with new batteries.

● position the hand-held transmitter with its

battery

area

facing

away

from

the

HomeLink

T surface.

● push and hold both the HomeLinkT and

hand-held transmitter buttons without inter-

ruption.

● position the hand-held transmitter 2 to 5 in

(50 to 127 mm) away from the HomeLink

surface. Hold the transmitter in that position

for up to 15 seconds. If HomeLink

T is not

programmed within that time, try holding

the transmitter in another position - keeping

the indicator light in view at all times.

If you continue to have programming difficul-

ties, please contact the INFINITI Consumer Af-

fairs Department. The phone numbers are lo-

cated in the Foreword of this Owner’s Manual.

CLEARING THE PROGRAMMED

INFORMATION

Individual buttons cannot be cleared, however

to clear all programming, push and hold the two

outside buttons and release when the indicator

light begins to flash (in approximately 20 sec-

onds).

REPROGRAMMING A SINGLE

HOMELINK

T BUTTON

To reprogram a HomeLink

T Universal Trans-

ceiver button, complete the following.
1. Push and hold the desired HomeLink

button.

Do not release the button until

step 4 has been completed.

2. When the indicator light begins to flash

slowly (after 20 seconds), position the

hand-held transmitter 2 to 5 in (50 to 127

mm) away from the HomeLink

T surface.

3. Push and hold the hand-held transmitter

button.

4. The HomeLink

T indicator light will flash,

first slowly and then rapidly. When the

indicator light begins to flash rapidly,

release both buttons.

The HomeLink

T Universal Transceiver button

has now been reprogrammed. The new device

can be activated by pushing the HomeLink

button that was just programmed. This proce-

dure will not affect any other programmed

HomeLink

T buttons.

IF YOUR VEHICLE IS STOLEN

If your vehicle is stolen, you should change the

codes of any non-rolling code device that has

been programmed into HomeLink

T. Consult the

Owner’s Manual of each device or call the

manufacturer or retailer of those devices for

additional information.
When your vehicle is recovered, you will need to

reprogram the HomeLinkT Universal Transceiver

with your new transmitter information.
FCC Notice:
This device complies with FCC rules part 15. Op-

eration is subject to the following two condi-

tions: (1) This device may not cause harmful in-

terference and (2) This device must accept any

interference that may be received, including in-

terference that may cause undesired operation.
The transmitter has been tested and complies

with FCC and DOC/MDC rules. Changes or modi-

fications not expressly approved by the party

responsible for compliance could void the user’s

authority to operate the device.
DOC: ISTC 1763K1313
FCC I.D.: CB2V67690

2-54

Instruments and controls

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

A key number plate is supplied with your keys.

Record the key number and keep it in a safe

place (such as your wallet), not in the vehicle. If

you lose your keys, see an INFINITI retailer for

duplicates by using the key number. INFINITI

does not record any key numbers so it is very

important to keep track of your key number

plate.
A key number is only necessary when you have

lost all keys and do not have one to duplicate

from. If you still have a key, this key can be

duplicated by an INFINITI retailer.

1. Intelligent Key (2)
2. Mechanical key (inside Intelligent Keys)

(2)

3. Key number plate (1)

INTELLIGENT KEY

Your vehicle can only be driven with the Intelli-

gent Keys which are registered to your vehicle’s

Intelligent Key system components and INFINITI

Vehicle Immobilizer System components. As

many as 4 Intelligent Keys can be registered

and used with one vehicle. The new keys must

be registered by an INFINITI retailer prior to use

with the Intelligent Key system and INFINITI

Vehicle Immobilizer System of your vehicle.

Since the registration process requires erasing

all memory in the Intelligent Key components

when registering new keys, be sure to take all

Intelligent Keys that you have to the INFINITI

retailer.

CAUTION

● Be sure to carry the Intelligent Key with you

when driving. The Intelligent Key is a preci-

sion device with a built-in transmitter. To

avoid damaging it, please note the

following.

– The Intelligent Key is water resistant;

however, wetting may damage the Intelli-

gent Key. If the Intelligent Key gets wet,

immediately wipe until it is completely

dry.

– Do not bend, drop or strike it against an-

other object.

– Do not place the Intelligent Key for an

extended period in a place where tem-

peratures exceed 140°F (60°C).

– Do not change or modify the Intelligent

Key.

– Do not use a magnet key holder.
– Do not place the Intelligent Key near an

electric appliance such as a television

set, personal computer or cellular phone.

SPA2505

KEYS

3-2

Pre-driving checks and adjustments

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

– Do not allow the Intelligent Key to come

into contact with water or salt water, and

do not wash it in a washing machine. This

could affect the system function.

● If an Intelligent Key is lost or stolen, INFINITI

recommends erasing the ID code of that In-

telligent Key. This will prevent the Intelli-

gent Key from unauthorized use to unlock

the vehicle. For information regarding the

erasing procedure, please contact an

INFINITI retailer.

Mechanical key

To remove the mechanical key, release the lock

knob at the back of the Intelligent Key.
To install the mechanical key, firmly insert it

into the Intelligent Key until the lock knob

returns to the lock position.
Use the mechanical key to lock or unlock the

doors, trunk lid, glove box and trunk pass-

through lid, if they are equipped with a key

cylinder.
See “DOORS” later in this section and “TRUNK

LID” later in this section, “STORAGE” in the “2.

Instruments and controls” section and “SEATS”

in the “1. Safety — Seats, seat belts and supple-

mental restraint system” section.

CAUTION

Always carry the mechanical key installed in

the Intelligent Key.

VALET HAND-OFF

When you have to leave a key with a valet, give

them the Intelligent Key itself and keep the

mechanical key with you to protect your belong-

ings.
To prevent the glove box and the trunk from

being opened during valet hand-off, follow the

procedures below.
1. Push the trunk release power cancel

switch to the CANCEL side.

2. Remove the mechanical key from the In-

telligent Key.

3. Lock the glove box and the trunk pass-

through with the mechanical key.

4. Hand the Intelligent Key to the valet,

keeping the mechanical key in your

pocket or bag for insertion into the Intel-

ligent Key when you retrieve your vehicle.

See “TRUNK LID” later in this section, “STOR-

AGE” in the “2. Instruments and controls” sec-

tion and “SEATS” in the “1. Safety — Seats, seat

belts and supplemental restraint system” sec-

tion.

SPA2033

Pre-driving checks and adjustments

3-3

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

● Always have the doors locked while driving.

Along with the use of seat belts, this pro-

vides greater safety in the event of an acci-

dent by helping to prevent persons from be-

ing thrown from the vehicle. This also helps

keep children and others from unintention-

ally opening the doors, and will help keep

out intruders.

● Before opening any door, always look for and

avoid oncoming traffic.

● Do not leave children unattended inside the

vehicle. They could unknowingly activate

switches or controls. Unattended children

could become involved in serious accidents.

LOCKING WITH MECHANICAL KEY

The power door lock system allows you to lock

or unlock all doors simultaneously using the

mechanical key.
● Turning the driver’s door key cylinder to the

front of the vehicle

will lock all doors.

● Turning the driver’s door key cylinder once

to the rear of the vehicle

will unlock the

driver’s door. After returning the key to the

neutral position

, turning it to the rear

again within 5 seconds will unlock all doors.

● You can switch the lock system to the mode

that allows you to open all the doors when

the key is turned once. (See “HOW TO USE

SETTING BUTTON” in the “4. Monitor, cli-

mate, audio, phone and voice recognition

systems” section.)

OPENING AND CLOSING WINDOWS

WITH THE MECHANICAL KEY

The driver’s door key operation also allows you

to open and close all door windows.
To open the windows, turn the driver’s door key

cylinder to the rear of the vehicle for

longer than

1 second . The door is unlocked and the window

keeps opening while turning the key.
This function can also be performed by pushing

and holding the door UNLOCK button of the

Intelligent Key. (See “HOW TO USE REMOTE

KEYLESS ENTRY FUNCTION” later in this sec-

tion.)
To close the windows, turn the driver’s door key

cylinder to the front of the vehicle for

longer

than 1 second . The door is locked and the

window keeps closing while turning the key.

SPA2117

DOORS

3-4

Pre-driving checks and adjustments

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKING WITH INSIDE LOCK KNOB

To lock the door individually, move the inside

lock knob to the lock position

then close the

door.
To unlock, move the inside lock knob to the

unlock position

When locking the door without an Intelligent

Key, be sure not to leave the Intelligent Key

inside the vehicle.

LOCKING WITH POWER DOOR LOCK

SWITCH

Operating the power door lock switch will lock

or unlock all the doors. The switches are lo-

cated on the driver’s and front passenger’s door

armrests.
To lock the doors, push the power door lock

switch to the lock position

with the driver’s

or front passenger’s door open, then close the

door.
When locking the door this way, be certain not to

leave the Intelligent Key inside the vehicle.
To unlock the doors including the fuel-filler

door, push the power door lock switch to the

unlock position

Lockout protection

When the power door lock switch (driver or front

passenger) is moved to the lock position with

the Intelligent Key in the port and any door

open, all doors will lock and unlock automati-

cally. With the Intelligent Key left in the vehicle

(not in the Intelligent Key port) and any door

open, all doors will unlock automatically and a

chime will sound after the door is closed.
These functions help to prevent the Intelligent

Key from being accidentally locked inside the

vehicle.

AUTOMATIC DOOR LOCKS

● All doors will be locked automatically when

the vehicle speed reaches 15 MPH (24 km/h).

● All doors will be unlocked automatically

when the ignition switch is pushed to the

OFF position.

The automatic lock and unlock functions can be

deactivated or activated independently of each

other.
To deactivate or activate the automatic lock or

unlock system, perform the following proce-

dure:
1. Close all doors.
2. Push the ignition switch to the “ON”

position.

SPA2000

SPA2300

Pre-driving checks and adjustments

3-5

—

05/14/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infiniti M45 (2010 year). Instruction - part 8
