Driving your vehicle

NOTICE

To prevent vehicle damage:

•

Due to higher load during trailer

usage, overheating might occur

on hot days or during uphill driv-

ing. If the coolant gauge indi-

cates over-heating, switch off

the air conditioner and stop the

vehicle in a safe area to cool

down the engine.

•

Do not switch off the engine

while the coolant gauge indi-

cates over-heating.

(Keep the engine idle to cool

down the engine)

•

If your vehicle is not equipped

with an air conditioner, you

should install a condenser fan

to improve engine performance

when towing a trailer.

5-104

VEHICLE WEIGHT

Two labels on your driver’s door sill

GAW (Gross Axle Weight)

Overloading

show how much weight your vehicle

This is the total weight placed on

was designed to carry: the Tire and

each axle (front and rear) - including

WARNING

Loading Information Label and the

vehicle curb weight and all payload.

Certification Label.

The Gross Axle Weight Rating

Before loading your vehicle, familiar-

(GAWR) and the Gross Vehicle

GAWR (Gross Axle Weight Rating)

ize yourself with the following terms

Weight Rating (GVWR) for your

for determining your vehicle's weight

This is the maximum allowable

vehicle are on the Certification

ratings, from the vehicle's specifica-

weight that can be carried by a single

Label attached to the driver's

tions and the Certification Label:

axle (front or rear). These numbers

(or front passenger’s) door.

are shown on the Certification Label.

Exceeding these ratings can

The total load on each axle must

cause an accident or vehicle

Base Curb Weight

never exceed its GAWR.

damage. You can calculate the

This is the weight of the vehicle includ-

weight of your load by weighing

ing a full tank of fuel and all standard

the items (and people) before

GVW (Gross Vehicle Weight)

equipment. It does not include pas-

putting them in the vehicle. Be

sengers, cargo, or optional equipment.

This is the Base Curb Weight plus

careful not to overload your

actual Cargo Weight plus passen-

vehicle.

gers.

Vehicle Curb Weight

This is the weight of your new vehicle

GVWR (Gross Vehicle Weight

when you picked it up from your deal-

Rating)

er plus any aftermarket equipment.

This is the maximum allowable

weight of the fully loaded vehicle

Cargo Weight

(including all options, equipment,

This figure includes all weight added

passengers and cargo). The GVWR

to the Base Curb Weight, including

is shown on the Certification Label

cargo and optional equipment.

located on the driver’s door sill.

5-105

What to do in an emergency

Hazard warning flasher

6-2

If you have a flat tire (with tire mobility kit)

In case of an emergency while driving

6-2

- Type A

6-23

If the engine stalls while driving

6-2

Introduction

6-23

If the engine stalls at a crossroad or crossing

6-2

Notes on the safe use of the Tire Mobility Kit

6-24

If you have a flat tire while driving

6-3

Components of the Tire Mobility Kit

6-25

Using the Tire Mobility Kit

6-26

If the engine will not start

6-3

Checking the tire inflation pressure

6-28

If the engine doesn't turn over or

turns over slowly

6-3

If you have a flat tire (with tire mobility kit)

If the engine turns over normally but

- Type B

6-30

doesn't start

6-4

Introduction

6-30

Notes on the safe use of the Tire Mobility Kit

6-31

Jump starting

6-4

Components of the Tire Mobility Kit

6-32

If the engine overheats

6-7

Using the Tire Mobility Kit

6-33

Tire Pressure Monitoring System (TPMS)

6-8

Checking the tire inflation pressure

6-35

Check tire pressure

6-8

Towing

6-37

Tire pressure monitoring system

6-9

Towing service

6-37

Low tire pressure telltale

6-10

Removable towing hook

6-38

Low tire pressure position telltale and

Emergency towing

6-39

tire pressure telltale

6-10

Emergency commodity

6-41

TPMS (Tire Pressure Monitoring System)

Fire extinguisher

6-41

malfunction indicator

6-12

First aid kit

6-41

Changing a tire with TPMS

6-12

Triangle reflector

6-41

If you have a flat tire (with spare tire)

6-15

Tire pressure gauge

6-41

Jack and tools

6-15

Changing tires

6-16

Jack label

6-21

EC Declaration of conformity for Jack

6-22

What to do in an emergency

HAZARD WARNING FLASHER

IN CASE OF AN EMERGENCY

To turn the hazard warning flasher

WHILE DRIVING

on or off, press the hazard warning

flasher button with the ignition switch

If the engine stalls while driving

in any position. The button is located

• Reduce your speed gradually,

in the center fascia panel. All turn

keeping a straight line. Move cau-

signal lights will flash simultaneously.

tiously off the road to a safe place.

•

The hazard warning flasher oper-

• Turn on your hazard warning flash-

ates whether your vehicle is run-

er.

ning or not.

• Try to start the engine again. If your

•

The turn signals do not work when

vehicle will not start, we recom-

the hazard flasher is on.

mend that you contact an author-

OPD066001

ized HYUNDAI dealer.

The hazard warning flasher serves

as a warning to other drivers to exer-

If the engine stalls at a cross-

cise extreme caution when approach-

road or crossing

ing, overtaking, or passing your vehi-

cle.

If the engine stalls at a crossroads or

It should be used whenever emer-

crossing, if safe to do so, move the

gency repairs are being made or

shift lever to the N (Neutral) position

when the vehicle is stopped near the

and then push the vehicle to a safe

edge of a roadway.

location.

6-2

IF THE ENGINE WILL NOT

If you have a flat tire while

•

When the vehicle is stopped, press

START

driving

the hazard warning flasher button,

move the shift lever into neutral,

If the engine doesn't turn over

If a tire goes flat while you are driving:

apply the parking brake, and place

or turns over slowly

•

Take your foot off the accelerator

the ignition switch in the LOCK/

• Be sure that you have fully

pedal and let the vehicle slow

OFF position.

depressed the clutch pedal.

down while driving straight ahead.

•

Have all passengers get out of the

• Check the battery connections to

Do not apply the brakes immedi-

vehicle. Be sure they all get out on

be sure they are clean and tight.

ately or attempt to pull off the road

the side of the vehicle that is away

as this may cause loss of vehicle

• Turn on the interior light. If the light

from traffic.

control resulting in an accident.

dims or goes out when you operate

•

When changing a flat tire, follow

When the vehicle has slowed to

the starter, the battery is drained.

such a speed that it is safe to do

the instructions provided later in

Do not push or pull the vehicle to

this chapter.

so, brake carefully and pull off the

start it. This could cause damage to

road. Drive off the road as far as

your vehicle. See instructions for

possible and park on firm, level

"Jump Starting" provided in this

ground. If you are on a divided

chapter.

highway, do not park in the median

area between the two traffic lanes.

CAUTION

Push or pull starting the vehicle

may cause the catalytic con-

verter to overload which can

lead to damage to the emission

control system.

6-3

What to do in an emergency

JUMP STARTING

If the engine turns over nor-

Jump starting can be dangerous if

(Continued)

mally but doesn't start

done incorrectly. Follow the jump

starting procedure in this section to

Hydrogen is always

• Check the fuel level and add fuel if

avoid serious injury or damage to

present in battery cells,

necessary.

your vehicle. If in doubt about how to

is highly combustible,

If the engine still does not start, we

properly jump start your vehicle, we

and may explode if ignit-

recommend that you call an author-

strongly recommend that you have a

ed.

ized HYUNDAI dealer for assistance.

service technician or towing service

Keep batteries out of

do it for you.

reach of children.

Batteries contain sulfu-

WARNING

ric acid which is highly

corrosive. Do not allow

To prevent SERIOUS INJURY or

acid to contact your

DEATH to you or bystanders,

eyes, skin or clothing.

always follow these precautions

If acid gets into your eyes, flush

when working near or handling

your eyes with clean water for at

the battery:

least 15 minutes and get imme-

Always read and follow

diate medical attention. If acid

instructions carefully

gets on your skin, thoroughly

when handling a battery.

wash the area. If you feel pain or

Wear eye protection

a burning sensation, get med-

designed to protect the

ical attention immediately.

eyes from acid splashes.

(Continued)

Keep all flames, sparks,

or smoking materials

away from the battery.

(Continued)

6-4

NOTICE

Jump starting procedure

(Continued)

1. Position the vehicles close enough

•

When lifting a plastic-cased

To prevent damage to your vehi-

that the jumper cables will reach,

battery, excessive pressure

cle:

but do not allow the vehicles to

on the case may cause battery

• Only use a 12-volt power supply

touch.

acid to leak. Lift with a battery

(battery or jumper system) to

carrier or with your hands on

2. Avoid fans or any moving parts in

jump start your vehicle.

the engine compartment at all

opposite corners.

• Do not attempt to jump start

times, even when the vehicles are

•

Do not attempt to jump start

your vehicle by push-starting.

turned off.

your vehicle if your battery is

frozen.

3. Turn off all electrical devices such

Information

as radios, lights, air conditioning,

•

NEVER attempt to recharge

etc. Put the vehicles in neutral,

the battery when the vehicle’s

An inappropriately disposed

and set the parking brakes. Turn

battery cables are connected

battery can be harmful to the

both vehicles OFF.

to the battery.

environment and human

health. Dispose the battery

•

The electrical ignition system

according to your local law(s)

works with high voltage.

or regulations.

NEVER touch these compo-

nents with the engine running

or when the ignition switch is

in the ON position.

•

Do not allow the (+) and (-)

jumper cables to touch. It may

cause sparks.

•

The battery may rupture or

explode when you jump start

with a low or frozen battery.

6-5

What to do in an emergency

7. Connect the other end of the sec-

Disconnect the jumper cables in the

ond jumper cable to the black,

exact reverse order you connected

negative

(-) chassis ground of

them:

your vehicle (4).

1. Disconnect the jumper cable from

Do not allow the jumper cables to

the black, negative

(-) chassis

contact anything except the cor-

ground of your vehicle (4).

rect battery or jumper terminals or

2. Disconnect the other end of the

the correct ground. Do not lean

jumper cable from the black, neg-

over the battery when making

ative (-) battery/chassis ground of

connections.

the assisting vehicle (3).

8. Start the engine of the assisting

3. Disconnect the second jumper

1VQA4001

vehicle and let it run at approxi-

cable from the red, positive

(+)

4. Connect the jumper cables in the

mately 2,000 rpm for a few min-

battery/jumper terminal of the

exact sequence shown in the illus-

utes. Then start your vehicle.

assisting vehicle (2).

tration. First connect one jumper

If your vehicle will not start after a

4. Disconnect the other end of the

cable to the red, positive

(+)

few attempts, it probably requires

jumper cable from the red, positive

jumper terminal of your vehicle

servicing. In this event please seek

(+) jumper terminal of your vehicle

(1).

qualified assistance. If the cause of

(1).

5. Connect the other end of the

your battery discharging is not

jumper cable to the red, positive

apparent, have your vehicle checked

(+) battery/jumper terminal of the

by an authorized HYUNDAI dealer.

assisting vehicle (2).

6. Connect the second jumper cable

to the black, negative (-) battery/

chassis ground of the assisting

vehicle (3).

6-6

IF THE ENGINE OVERHEATS

If your temperature gauge indicates

WARNING

overheating, you experience a loss

of power, or hear loud pinging or

While the engine is

NEVER remove the

knocking, the engine may be over-

running, keep hands,

radiator cap or the

heating. If this happens, you should:

clothing and tools

drain plug while the

1. Pull off the road and stop as soon

away from the mov-

engine and radiator

as it is safe to do so.

ing parts such as the

are hot. Hot coolant

2. Place the shift lever in neutral and

cooling fan and drive

and steam may blow out under

set the parking brake. If the air

belt to prevent seri-

pressure, causing serious injury.

conditioning is ON, turn it OFF.

ous injury.

Turn the engine off and wait

3. If engine coolant is running out

until the engine cools down.

under the vehicle or steam is com-

Use extreme care when remov-

ing out from the hood, stop the

4. Check for coolant leaking from the

ing the radiator cap. Wrap a

engine. Do not open the hood until

radiator, hoses or under the vehi-

thick towel around it, and turn it

the coolant has stopped running

cle.

(If the air conditioning had

counterclockwise slowly to the

or the steaming has stopped. If

been in use, it is normal for cold

first stop. Step back while the

there is no visible loss of engine

water to be draining from it when

pressure is released from the

coolant and no steam, leave the

you stop.)

cooling system. When you are

engine running and check to be

5. If engine coolant is leaking out,

sure all the pressure has been

sure the engine cooling fan is

stop the engine immediately and

released, press down on the

operating. If the fan is not running,

we recommend that you call an

cap, using a thick towel, and

turn the engine off.

authorized HYUNDAI dealer for

continue turning counterclock-

assistance.

wise to remove it.

6-7

What to do in an emergency

TIRE PRESSURE MONITORING SYSTEM (TPMS) (IF EQUIPPED)

6. If you cannot find the cause of the

Check tire pressure

overheating, wait until the engine

temperature has returned to nor-

mal. Then, if coolant has been

lost, carefully add coolant to the

reservoir to bring the fluid level in

the reservoir up to the halfway

mark.

7. Proceed with caution, keeping

alert for further signs of overheat-

OPD066009

ing. If overheating happens again,

we recommend that you call an

authorized HYUNDAI dealer for

OPDEN047205

assistance.

•

You can check the tire pressure in

the Assist mode on the cluster.

CAUTION

Refer to the "LCD Display

• Serious loss of coolant indi-

Modes" in chapter 3.

cates a leak in the cooling

•

Tire pressure is displayed after a

system and we recommend

few minutes of driving after initial

the system be checked by an

OPDEN047202

engine start up.

authorized HYUNDAI dealer.

(1) Low Tire Pressure Telltale/

•

If tire pressure is not displayed

• When the engine overheats

TPMS Malfunction Indicator

when the vehicle is stopped, "Drive

from low engine coolant, sud-

to display" message will appear.

(2) Low tire pressure position telltale

denly adding engine coolant

and tire pressure telltale

After driving, check the tire pres-

may cause cracks in the

sure.

(Shown on the LCD display)

engine. To prevent damage,

add engine coolant slowly in

small quantities.

6-8

•

The displayed tire pressure values

Tire pressure monitoring sys-

As an added safety feature, your

may differ from those measured

tem

vehicle has been equipped with a tire

with a tire pressure gauge.

pressure monitoring system (TPMS)

that illuminates a low tire pressure

•

You can change the tire pressure

WARNING

telltale when one or more of your

unit in the User Settings mode on

tires is significantly under-inflated.

the instrument cluster.

Over-inflation or under-inflation

Accordingly, when the low tire pres-

- psi, kpa, bar

(Refer to "LCD

can reduce tire life, adversely

sure telltale illuminates, you should

Modes" in chapter 3).

affect vehicle handling, and

stop and check your tires as soon as

lead to sudden tire failure that

possible, and inflate them to the

may cause loss of vehicle con-

proper pressure. Driving on a signifi-

trol resulting in an accident.

cantly under-inflated tire causes the

tire to overheat and can lead to tire

Each tire, including the spare (if pro-

failure. Under-inflation also reduces

vided), should be checked monthly

fuel efficiency and tire tread life, and

when cold and inflated to the inflation

may affect the vehicle’s handling and

pressure recommended by the vehi-

stopping ability.

cle manufacturer on the vehicle plac-

ard or tire inflation pressure label. (If

Please note that the TPMS is not a

substitute for proper tire mainte-

your vehicle has tires of a different

size than the size indicated on the

nance, and it is the driver's responsi-

bility to maintain correct tire pres-

vehicle placard or tire inflation pres-

sure label, you should determine the

sure, even if under-inflation has not

reached the level to trigger illumina-

proper tire inflation pressure for

those tires.)

tion of the TPMS low tire pressure

telltale.

6-9

What to do in an emergency

Your vehicle has also been equipped

NOTICE

Low tire pressure

with a TPMS malfunction indicator to

telltale

indicate when the system is not

If any of the below happens, we

operating properly. The TPMS mal-

recommend that the system be

function indicator is combined with

checked by an authorized HYUNDAI

the low tire pressure telltale. When

dealer.

Low tire pressure

the system detects a malfunction,

1. The low tire pressure telltale/

position telltale

the telltale will flash for approximate-

TPMS malfunction indicator

and tire pressure

ly one minute and then remain con-

does not illuminate for 3 sec-

telltale

tinuously illuminated. This sequence

onds when the ignition switch

will continue upon subsequent vehi-

is turned to the ON position or

OPDEN047202

cle start-ups as long as the malfunc-

the engine is running.

tion exists. When the malfunction

2. The TPMS malfunction indicator

When the tire pressure monitoring

indicator is illuminated, the system

remains illuminated after blink-

system warning indicators are illumi-

may not be able to detect or signal

ing for approximately 1 minute.

nated and a warning message dis-

low tire pressure as intended.

3. The Low tire pressure position

played on the cluster LCD display,

TPMS malfunctions may occur for a

telltale remains illuminated.

one or more of your tires is signifi-

variety of reasons, including the

cantly under-inflated. The low tire

installation of replacement or alter-

pressure position telltale light will

nate tires or wheels on the vehicle

indicate which tire is significantly

that prevent the TPMS from function-

under-inflated by illuminating the cor-

ing properly. Always check the TPMS

responding position light.

malfunction telltale after replacing

one or more tires or wheels on your

vehicle to ensure that the replace-

ment or alternate tires and wheels

allow the TPMS to continue to func-

tion properly.

6-10

If either telltale illuminates, immedi-

NOTICE

WARNING

ately reduce your speed, avoid hard

cornering and anticipate increased

The spare tire is not equipped with

a tire pressure sensor.

Low pressure damage

stopping distances. You should stop

and check your tires as soon as pos-

Significantly low tire pressure

sible. Inflate the tires to the proper

makes the vehicle unstable and

CAUTION

pressure as indicated on the vehi-

can contribute to loss of vehicle

cle’s placard or tire inflation pressure

control and increased braking

In winter or cold weather, the low

label located on the driver’s side cen-

tire pressure telltale may illumi-

distances.

ter pillar outer panel. If you cannot

nate if the tire pressure was

Continued driving on low pres-

reach a service station or if the tire

adjusted to the recommended

sure tires can cause the tires to

cannot hold the newly added air,

tire inflation pressure in warm

overheat and fail.

replace the low pressure tire with a

weather. It does not mean your

spare tire.

TPMS is malfunctioning because

If you drive the vehicle for about 10

the decreased temperature leads

minutes at speeds above 25 km/h

to a lowering of tire pressure.

after replacing the low pressure tire

When you drive your vehicle

with the spare tire, the below will

from a warm area to a cold area

happen:

or from a cold area to a warm

• The TPMS malfunction indicator

area, or the outside temperature

may blink for approximately 1 minute

is higher or lower, you should

and then remain continuously illumi-

check the tire inflation pressure

nated because the TPMS sensor is

and adjust the tires to the recom-

not mounted on the spare wheel.

mended tire inflation pressure.

6-11

What to do in an emergency

TPMS (Tire Pressure

Changing a tire with TPMS

CAUTION

Monitoring System)

If you have a flat tire, the low Tire

malfunction indicator

Pressure and Position telltales will

•

The TPMS malfunction indicator

come on. We recommend that the

may blink for approximately 1

system be checked by an authorized

The TPMS malfunction indicator will

minute and then remain contin-

uously illuminated if the vehicle

HYUNDAI dealer.

illuminate after it blinks for approxi-

mately one minute when there is a

is moving around electric power

supply cables or radios trans-

CAUTION

problem with the Tire Pressure

Monitoring System.

mitter such as at police sta-

tions, government and public

NEVER use a puncture-repair-

We recommend that the system be

offices, broadcasting stations,

ing agent to repair and/or inflate

checked by an authorized HYUNDAI

military installations, airports,

a low pressure tire. The tire

dealer.

or transmitting towers, etc. This

sealant can damage the tire

can interfere with normal opera-

pressure sensor. If used, you

NOTICE

tion of the Tire Pressure

will have to replace the tire

Monitoring System (TPMS).

pressure sensor.

If there is a malfunction with the

TPMS, the low tire pressure posi-

•

The TPMS malfunction indica-

tion telltale will not be displayed

tor may blink for approximately

Each wheel is equipped with a tire

even though the vehicle has an

1 minute and then remain con-

pressure sensor mounted inside the

tinuously illuminated if snow

tire behind the valve stem. You must

under-inflated tire.

chains are used or some sepa-

use TPMS specific wheels. It is rec-

rate electronic devices such as

ommended that you have your tires

notebook computer, mobile

serviced by an authorized HYUNDAI

charger, remote starter or nav-

dealer.

igation etc., are used in the

vehicle.

This can interfere with normal

operation of the Tire Pressure

Monitoring System (TPMS).

6-12

If you drive the vehicle for about 10

You may not be able identify a tire

WARNING

minutes at speeds above 25 km/h

with low pressure by simply looking

after replacing the low pressure tire

at it. Always use a good quality tire

•

The TPMS cannot alert you to

with the spare tire, the below will

pressure gauge to measure the tire's

happen:

inflation pressure. Please note that a

severe and sudden tire dam-

age caused by external factors

tire that is hot (from being driven) will

• The TPMS malfunction indicator

such as nails or road debris.

have a higher pressure measure-

may blink for approximately 1 minute

ment than a tire that is cold (from sit-

•

If you feel any vehicle instabil-

and then remain continuously illumi-

ting stationary for at least 3 hour and

ity, immediately take your foot

nated because the TPMS sensor is

driven less than 1.6 km (1 mile) dur-

off the accelerator, apply the

not mounted on the spare wheel.

ing that 3 hour period).

brakes gradually and with

light force, and slowly move to

Allow the tire to cool before measur-

a safe position off the road.

ing the inflation pressure. Always be

sure the tire is cold before inflating to

the recommended pressure.

A cold tire means the vehicle has

been sitting for 3 hours and driven for

less than 1.6 km (1 mile) in that 3

hour period.

6-13

What to do in an emergency

WARNING

(Continued)

❈All vehicles sold in the

Tampering with, modifying, or

For EUROPE

EUROPE market during below

disabling the Tire Pressure

period must be equipped with

•

Do not modify the vehicle; it

Monitoring System (TPMS) com-

TPMS.

may interfere with the TPMS

ponents may interfere with the

function.

- New model vehicle :

system's ability to warn the driv-

Nov. 1, 2012 ~

•

The wheels on the market do

er of low tire pressure condi-

not have a TPMS sensor.

- Current model vehicle :

tions and/or TPMS malfunctions.

Nov. 1, 2014~ (Based on

Tampering with, modifying, or

For your safety, we recom-

vehicle registrations)

disabling the Tire Pressure

mend that you use parts for

Monitoring System (TPMS) com-

replacement from an author-

ponents may void the warranty

ized HYUNDAI dealer.

for that portion of the vehicle.

•

If you use the wheels on the

market, use a TPMS sensor

approved by a HYUNDAI deal-

er. If your vehicle is not

equipped with a TPMS sensor

or TPMS does not work prop-

erly, you may fail the periodic

vehicle inspection conducted

in your country.

(Continued)

6-14

IF YOU HAVE A FLAT TIRE (WITH SPARE TIRE, IF EQUIPPED)

Jack and tools

WARNING

Changing a tire can be danger-

ous. Follow the instructions in

this section when changing a

tire to reduce the risk of serious

injury or death.

CAUTION

OPDEN067037

Be careful as you use the jack

Turn the winged hold down bolt

handle to stay clear of the flat

OPDEN067027

counterclockwise to remove the

end. The flat end has sharp

(1) Jack handle

spare tire.

edges that could cause cuts.

(2) Jack

Store the spare tire in the same com-

(3) Wheel nut wrench

partment by turning the winged hold

down bolt clockwise.

To prevent the spare tire and tools

The jack, jack handle, and wheel nut

from "rattling", store them in their

wrench are stored in the luggage

proper location.

compartment under the luggage box

cover.

The jack is provided for emergency

tire changing only.

6-15

Hyundai i30 N (2018 year). Manual - part 21
