When you push the main switch in,
the indicator comes on and the
passenger’s window cannot be raised
or lowered. Use the main switch
when you have children in the
vehicle so they do not injure
themselves by operating the window
unintentionally. To cancel this
feature, push on the switch again.
The switch will pop out and the
indicator will go off.

The windows and the main switch
feature will operate for up to 10
minutes after you turn off the
ignition switch. Opening either door
cancels this function.

If either

window (driver’s window only on
LX) senses any obstacle while it is
closing automatically, it will reverse
direction, and then stop. To close the
window, remove the obstacle, then
use the window switch again.

Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
before closing it.

The driver’s window auto

reverse function is disabled when
you continuously pull up the switch.

Power Windows

AUTO REVERSE

Inst

nd
Cont

109

NOTE:

Main Menu

You can open and close the windows
and the moonroof (if equipped) with
the key in the driver’s door lock.

Turn the key clockwise, then
release it.

Insert the key in the driver’s door
lock.

To open:

Press the UNLOCK button once
to unlock the driver’s door.

To open the windows and
moonroof further, press the
button again (within 10 seconds of
step 1) and hold it. If the windows
and the moonroof stop before the
desired position, repeat steps 1
and 2.

You cannot close the windows or the
moonroof with the remote
transmitter.

You can open both windows and the
moonroof (if equipped) from the
outside with the remote transmitter.

Press the UNLOCK button a
second time, and hold it. The
passenger’s door unlocks, and
both windows and the moonroof
start to open. To stop the windows
and moonroof, release the button.

Opening the Windows and
Moonroof with the Remote
Transmitter

Opening/Closing the Windows
and Moonroof with the Key

Power Windows

110

Open

Close

UNLOCK
BUTTON

Main Menu

To close:

Insert the key in the driver’s door
lock.

Turn the key counterclockwise,
then release it.

To close the windows and the
moonroof further, turn and hold
the key again (within 10 seconds
of step 2).

To open the windows and the
moonroof further, turn and hold
the key again (within 10 seconds
of step 2).

Turn the key clockwise again, and
hold it. Both windows and the
moonroof start to open. To stop
the windows and the moonroof,
release the key.

Turn the key counterclockwise
again, and hold it. Both windows
and the moonroof start to close.
To stop the windows and the
moonroof, release the key.

If the windows and the

moonroof stop before the desired
position, repeat steps 2 and 3.

Power Windows

Inst

nd
Cont

111

NOTE:

Main Menu

− To open the moonroof

fully, pull back the moonroof switch
firmly, then release it. The moonroof
automatically opens all the way. To
stop the moonroof from opening,
push the switch briefly.

To close the moonroof fully, firmly
push the moonroof switch forward,
then release it. The moonroof
automatically closes all the way. To
stop the moonroof from closing,
push the switch briefly.

To open or close the moonroof
partially, lightly pull the switch back
or push it forward and hold it. The
moonroof will stop when you release
the switch.

To tilt up the moonroof, push on the
center of the moonroof switch. To
stop the moonroof from tilting up
fully, push the switch briefly.

To open the moonroof, pull back on
the switch and hold it. Release the
switch when the moonroof reaches
the desired position. To close the
moonroof, push the switch forward
and hold it. Release the switch to
stop the operation.

The moonroof can be tilted up in the
back for ventilation, or it can be slid
back into the roof. Use the switch on
the front ceiling to operate the
moonroof. You must turn the
ignition switch to the ON (II)
position to operate the moonroof.

If equipped

AUTO

Moonroof

112

MOONROOF SWITCH

Open

Close

Tilt

Opening or closing the
moonroof on someone’s hands
or fingers can cause serious
injury.

Make sure all hands and fingers
are clear of the moonroof
before opening or closing it.

Main Menu

Auto reverse stops sensing when the
moonroof is almost closed. You
should always check that all
passengers and objects are away
from the moonroof before closing it.

If the moonroof runs into any
obstacle while it is closing
automatically, it will reverse
direction, and then stop. To close the
moonroof, remove the obstacle, then
use the moonroof switch again.

You can open and close the
moonroof for up to 10 minutes after
you turn off the ignition switch.
Opening either door cancels this
function.

You can use the remote transmitter
or the key to operate the moonroof
from the outside. Refer to page

for details.

110

Auto Reverse

Moonroof

Inst

nd
Cont

113

If you try to open the moonroof in
below-f reezing temperatures, or when
it is covered with snow or ice, you can
damage the moonroof panel or its
motor.

Main Menu

To apply the parking brake, pull the
lever up fully. To release it, pull up
slightly, push the button, and lower
the lever. The parking brake
indicator on the instrument panel
should go out when the parking
brake is fully released (see page

Parking Brake

114

PARKING BRAKE LEVER

Driving the vehicle with the parking
brake applied can damage the rear
brakes and hubs. A beeper will sound if
the vehicle is driven with the parking
brake on.

Main Menu

Interior Convenience Items

Inst

nd
Cont

115

VANITY MIRROR

SUN VISOR

TRUNK

CENTER POCKETS

AUXILIARY INPUT JACK

COAT HOOK

BEVERAGE HOLDER

ACCESSORY POWER SOCKET

DOOR POCKET

SUNGLASSES HOLDER

GLOVE BOX

BEVERAGE HOLDER

USB ADAPTER CABLE

ACCESSORY POWER
SOCKET

CONSOLE COMPARTMENT

Main Menu

Open the glove box by pulling the
handle to the left. Close it with a firm
push. Lock or unlock the glove box
with the master key.

Be careful when you are using the
beverage holders. A spilled liquid
that is very hot can scald you or your
passengers. Spilled liquids can
damage the upholstery, carpeting,
and electrical components in the
interior.

Be careful when you are using the
beverage holders. A spilled liquid
that is very hot can scald you or your
passengers. Liquid can also spill
from the door pocket beverage
holders when you open or close the
doors. Use only resealable
containers in the door pockets.

Spilled liquids can damage the
upholstery, carpeting, and electrical
components in the interior.

Glove Box

Beverage Holders

Interior Convenience Items

116

To lock

GLOVE BOX

An open glove box can cause
serious injury to your passenger
in a crash, even if the
passenger is wearing the seat
belt.

Always keep the glove box
closed while driving.

Main Menu

To close, lower the armrest, and
push it down until it latches.

Open the front beverage holder by
pulling up on the lid.

Each rear side panel also has a
beverage holder.

To open the console compartment,
pull up on the lever and lift the
armrest.

Interior Convenience Items

Console Compartment

Inst

nd
Cont

117

FRONT

CONSOLE COMPARTMENT

LEVER

Main Menu

Each socket is intended to supply
power for 12 volt DC accessories
that are rated 120 watts or less (10
amps).

Your vehicle has two accessory
power sockets; one is at the front of
the center console and the other is in
the console compartment.

To use an accessory power socket,
the ignition switch must be in the
ACCESSORY (I) or ON (II) position.

None of the sockets will power an
automotive type cigarette lighter
element.

Make sure to put the socket cover
back in place to prevent any small
foreign objects from getting into the
socket.

Interior Convenience Items

Accessory Power Sockets

118

FRONT

CONSOLE COMPARTMENT

Main Menu

To use the sun visor, pull it down.
When using the sun visor for the
side window, remove the support rod
from the clip, and swing it out.
In this position, the sun visor can be
adjusted by moving it on its slider.
Do not use the extended sun visor
over the inside mirror.

Make sure you put the sun visor
back in place when you are getting
into or out of the vehicle.

To use the vanity mirror on the back
of the sun visor, pull up the cover.

The vanity mirror lights come on
when you pull up the cover.

To open the sunglasses holder, push
then release the indent. It will
unlatch and swing down. To close it,
push it until it latches. Make sure the
holder is closed while you are driving.

CONTINUED

Interior Convenience Items

Sun Visor

Vanity Mirror

Sunglasses Holder

Inst

nd
Cont

119

SUN VISOR

Push

Slide

Main Menu

To use a coat hook, pull it down.
Close it with a firm push.

Make sure the coat hook is closed
when you are not using it. This hook
is not designed for large or heavy
items.

Some larger styles of sunglasses
may not fit in the holder.

You may also store small items in
this holder. Make sure they are
small enough to let the holder close
and latch, and that they are not
heavy enough to cause the holder to
pop open while driving.

Pull up the lid to open each pocket.

Coat Hook

Center Pocket

Interior Convenience Items

120

COAT HOOK

Vehicle without navigation system
is shown.

Main Menu

The ceiling light has a three-position
switch: ON, Door Activated, and
OFF. In the Door Activated (center)
position, the light comes on when
you:

The ceiling light (with the switch in
the center position) comes on when
you remove the key from the ignition
switch. If you do not open a door, the
light stays on, then fades out in
about 30 seconds.

Unlock the driver’s door with the
key or remote transmitter.

Open either door.

After both doors are closed tightly,
the light dims slightly, then fades out
in about 30 seconds.

If you leave either door open without
the key in the ignition switch, the
ceiling light will go off after about 15
minutes.

Turn on a spotlight by pushing the
lens. Push the lens again to turn it
off. You can use the spotlights at all
times.

CONTINUED

Ceiling Light

Spotlights

Interior Lights

Inst

nd
Cont

121

DOOR ACTIVATED POSITION

Main Menu

The spotlights have a two-position
switch. In the DOOR position, the
lights come on when you open either
door. The lights fade out in about 30
seconds after the doors are closed
tightly. In the OFF position, the
lights do not come on.

The spotlights (with the switch in
the DOOR position) also come on
when you unlock the door with the
key or the remote transmitter, and
when you remove the key from the
ignition switch.

Your vehicle has a courtesy light in
the ignition switch. This light comes
on when you open the driver’s door.
It fades out in about 30 seconds after
the door is closed.

Except LX

Interior Lights

Courtesy Lights

122

DOOR ACTIVATED

SPOTLIGHT

OFF POSITION

Main Menu

The heating and air conditioning
system in your vehicle provides a
comfortable driving environment in
all weather conditions.

The standard audio system has
many features. This section
describes those features and how to
use them.

Your vehicle has an anti-theft audio
system that requires a code number
to enable it.

The security system helps to dis-
courage vandalism and theft of your
vehicle.

.............

Vents, Heating, and A/C

. 124

...............

Climate Control System

. 130

................................

Audio System

. 138

................................

Audio System

. 139

..........

Playing the FM/AM Radio

. 140

................

Playing the XM Radio

. 147

.................................

Playing Discs

. 153

...

Disc Changer Error Messages . 162

............................

Playing an iPod

. 163

.................

iPod Error Messages

. 171

Playing a USB Flash Memory

........................................

Device

. 172

USB Flash Memory Device Error

...................................

Messages

. 180

................................

Audio System

. 181

..........

Playing the FM/AM Radio

. 182

................

Playing the XM Radio

. 194

.................................

Playing Discs

. 201

...

Disc Changer Error Messages . 212

............................

Playing an iPod

. 213

.................

iPod Error Messages

. 221

Playing a USB Flash Memory

........................................

Device

. 222

USB Flash Memory Device Error

...................................

Messages

. 231

..................

Protecting Your Discs

. 232

............

FM/AM Radio Reception

. 235

................

Remote Audio Controls

. 237

......................

Auxiliary Input Jack

. 239

.................

Radio Theft Protection

. 240

..........................

Setting the Clock

. 241

............................

Security System

. 244

.........................................

Compass

. 246

...............................

Cruise Control

. 250

HomeLink Universal

................................

Transceiver

. 253

........

HandsFreeLink

. 257

Models without navigation system

Models with navigation system

Bluetooth

Features

Fe
a

123

Main Menu

＊

: If equipped

Vents, Heating, and A/C

LX and U.S. EX

124

MODE CONTROL
BUTTONS

FAN CONTROL DIAL

RECIRCULATION BUTTON

TEMPERATURE CONTROL DIAL

MAX A/C BUTTON

AIR CONDITIONING (A/C)
BUTTON

REAR WINDOW DEFOGGER

REAR WINDOW DEFOGGER/
HEATED MIRROR BUTTON

Main Menu

Content .. 6 7 8 9 ..
