SA-23 3. Mount the guide lever on the lower arm Fastening torque (96 0)Nm 4. Link the transverse stabilizer rod with the lower arm. Fastening torque (23 3)Nm 5. Mount the vibration damper. 6. Mount the ending part of the drag rod: (a) Link the drag rod end to the steering knuckle arm, mount and screw up the nuts according to the specified torque. Fastening torque (91 0)Nm (b) Lock the nut with the new split pin. 7. Mount the torsion rod spring. 8. Check the Alignment of Front Wheel. (See the page SA-3) Suspension System and Automobile Axle (Dr/2WD) Front Suspension (Lower Arm and Vibration Damper) |
