Passenger Side Lamp

A

E142455

E160818

(A) Individual lamp on and off
switch.

Rear Interior Lamp

 (If Equipped)

E190496

B

A

E160817

(A)Passenger side lamp on and
off switch.

E160818

(B)Driver side lamp on and off
switch.

AMBIENT LIGHTING

 (If Equipped)

The ambient lighting system illuminates
the interior with a choice of several colors.
The ambient lighting control is located in
the overhead console.

E142456

A

B

C

Color palette

A

Control knob

B

Search mode

C

Rotate B past the first detent to switch on
and adjust to the desired brightness.

Press A to cycle through the color choices.

Press C to switch on all interior lamps and
the ambient lighting. Press C again to
switch off the interior lamps and return the
ambient lighting to the previously selected
color.

The ambient lighting will switch on when
the following conditions have been met:
•

you switch the ignition on

•

you switch the headlamps on

The ambient lighting will remain on until
you switch the ignition off and one of the
following conditions have been met:
•

you lock your vehicle

•

the accessory delay timer expires.

POWER WINDOWS

WARNINGS

Do not leave children unattended in
your vehicle and do not let them play
with the power windows. They may

seriously injure themselves.

When closing the power windows,
you should verify they are free of
obstructions and make sure that

children and pets are not in the proximity
of the window openings.

E70848

Note: You may hear a pulsing noise when
just one of the windows is open. Lower the
opposite window slightly to reduce this
noise.

Press the switch to open the window.

Lift the switch to close the window.

One-Touch Down

Press the switch fully and release it. Press
again or lift it to stop the window.

One-Touch Up

Lift the switch fully and release it. Press or
lift it again to stop the window.

Window Lock

E70850

Press the control to lock or unlock the rear
window controls. It illuminates when you
lock the rear window controls.

Bounce-Back

 (If Equipped)

The window will stop automatically while
closing. It will reverse some distance if
there is an obstacle in the way.

Overriding the Bounce-Back Feature

WARNING

When you override the bounce-back
feature the window will not reverse
if it detects an obstacle. Take care

when closing the windows to avoid
personal injury or damage to your vehicle.

Proceed as follows to override this
protection feature when there is a
resistance, for example in winter:

1.

Close the window twice until it reaches
the point of resistance and let it
reverse.

2. Close the window a third time to the

point of resistance. The bounce-back
feature is now disabled and you can
close the window manually. The
window will go past the point of
resistance and you can close it fully.

See an authorized dealer as soon as
possible if the window does not close after
the third attempt.

Resetting the Bounce-Back Feature

WARNING

The bounce-back feature remains
turned off until you reset the
memory.

If you have disconnected the battery, you
must reset the bounce-back memory
separately for each window.

1.

Lift and hold the switch until the
window is fully closed.

2. Release the switch.

3. Lift the switch again for one more

second.

4. Press and hold the switch until the

window is fully open.

5. Release the switch.

6. Lift and hold the switch until the

window is fully closed.

7.

Open the window and then try to close
it automatically.

8. Reset and repeat the procedure if the

window does not close automatically.

Accessory Delay

 (If Equipped)

You can use the window switches for
several minutes after you switch the
ignition off or until you open either front
door.

GLOBAL OPENING

You can use the remote control to operate
the windows with the ignition off.

Note: To operate this feature, accessory
delay must not be active.

Opening the Windows

You can use the global opening feature to
open the windows only for a short time
after you unlock your vehicle by using the
remote control.

To use the global opening feature:
1.

Press and release the remote control
unlock button.

2. Press the remote control unlock button

again and hold it for approximately
three seconds. Release the control
when the windows begin to open.

3. Press the lock or unlock button on your

remote control to stop the window
opening function.

Note: Contact an authorized Ford dealer to
deactivate this feature.

EXTERIOR MIRRORS

Power Exterior Mirrors

WARNING

Do not adjust the mirrors when your
vehicle is moving.

E70846

A

C

B

Left-hand mirror

A

Off

B

Right-hand mirror

C

E70847

Press the arrows to adjust the mirror.

Fold-Away Exterior Mirrors

Push the mirror toward the door window
glass. Make sure that you fully engage the
mirror in its support when returning it to its
original position.

Signal Indicator Mirrors

The outer portion of the appropriate mirror
housing blinks when you activate the turn
signal.

Heated Exterior Mirrors

 (If Equipped)

See Heated Windows and Mirrors (page
111).

Integrated Blind Spot Mirrors

WARNING

Objects in the blind spot mirror are
closer than they appear.

Blind spot mirrors have an integrated
convex mirror built into the upper outboard
corner of the exterior mirrors. They are
designed to increase your visibility along
the side of your vehicle.

Check the main mirror first before a lane
change, then check the blind spot mirror.
If no vehicles are present in the blind spot
mirror and the traffic in the adjacent lane
is at a safe distance, signal that you intend
to change lanes. Glance over your shoulder
to verify traffic is clear and carefully
change lanes.
