BYD G3. Service Instruction - part 7





BYD G3 AUTO Owner’s Instruction





94

Tips

●  Before  driving,  make  sure  that

parking  brake  is  released  fully
and  the  parking  brake indicator
goes out.

●  Do not  leave  the  car  when  the

engine is running.

●  Do not  rest  your  feet  on  brake

pedal  in  driving,  which  may
cause  dangerous  overheating,
wear

and

higher

fuel

consumption.

● When on long downhill slope,

slow down the speed and shift
to low gear. Please note that the
brake will overheat and function
abnormally if you steps on the
brake pedal too many times.


● Take special care when

speeding up, shift to
higher/lower gear, or braking on
slippery road. Hard acceleration
or engine braking may result in
skidding or spinning of the car.


● Do not continue driving when

the brake is wet. Wet brake
requires longer braking
distance and may cause
deviation of the direction of the
car. Also, in this case parking
brake can not stop the car
firmly.


Do not stretch any part of your

body out of the window in
driving, which may cause
severe accidents and risk
severe personal injury. Take
special care when there are kids
on the car.





Note

When  driving  on  damp  road,
avoid deep water as when a large
amount  of  water  enters  engine
compartment,  the  engine  and/or
electrical parts may be damaged.
















Driving Tips in Winter



Make sure coolant is suitable for use
in winter.

Only  use  cooling  fluid  authorized  by
BYD  service  station.  Choose  and  add
suitable type of cooling fluid into cooling
system

according

to

environment

temperature.
Improper  cooling  fluid  may  damage
engine cooling system.


Note

Do not over use water, which may
damage engine cooling system in
winter.



Check Battery and Cable Status

Cold  weather  may  reduce  battery
performance,  and  you  shall  keep  the
battery  high  enough  for  starting  in  the
winter.  Visual  check  of  the  battery  is
described  in  section  7-3.  BYD  service
station can check charging status of the
battery for you.


-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





95

Make sure viscosity of the engine oil
is suitable for driving in winter.

Please  refer  to  section  7-2  for
information  on  recommended  viscosity
of engine oil. If a large volume of engine
oil for summer use is left in the engine in
winter, it may cause difficulty for engine
starting.  If  you  are  not  sure  about
choosing engine oil, please contact BYD
service station for help.

Avoid Door Lock Freezing
Spray some deicing agent or glycerin in
door  lock  hole  to  prevent  the  lock  from
freezing.

Use Cleanser with Antifreeze
It  is  available  in  BYD  service  stations
and  all  auto  part  stores.  Mixing  ratio  of
water  and  antifreeze  shall  follow
manufacturer's instruction.


Note

Don’t  use  engine  antifreeze  or
other  substitutes  as  cleanser,  as
they  will  damage  the  vehicle
paint.




Do not  apply  parking  brake if it  may
be frozen up.
In  parking,  shift  to  gear  shift  lever  to  N
gear  and  place  obstacles  around  rear
wheels  to  retain  the  car.  Do  not  apply
parking brake as it may be frozen up by
water  or  snow,  resulting  in  difficulty  to
release the parking brake.

Prevent  snow  from  staying  under
mudguard.
Snow or ice under mudguard may make
steering difficult. When driving in winter,
you  shall  stop  the  check  regularly  to
check  whether  there  is  ice  or  snow
under mudguard.

You  are  recommended  to  keep
certain  emergency  tools  on  the  car
according to your region.
Examples of such articles are tire chains,
window  wiper,  a  bag  of  sand  or  salt,
flasher  signaling  device,  shovel  and
connection cables.



Tow Trailer


BYD G3 is designed for transportation of
passengers.  Towing  a  trailer  may  pose
bad  effect  to  operation,  performance,
braking, endurance, fuel economy of the
car.      Safety  and  comfort  in  driving
depends  on  proper  use  of  devices  and
the driver’s habitual care in driving.
For  the  sake  of  safety  of  yourself  and
others, do not over load the car or tow a
trailer.Damage  or  failure  cause  by
towing  a  trailer  for  business  purpose  is
not covered by BYD warranty.

Weight Limit
Before  towing  a  trailer,  make  sure  it  is

within  the  car’s  capacity.  You  can
contact the local BYD service station to
check the trailer's capacity.
Towing  capacity  is  measured  on  level
road. In region with high altitude, please
take note that the engine power and its
towing capacity will reduce.









-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





96

Tips

Towing  trailer  shall  not  exceed
the  maximum  rated  load  of  the
two-hook,  or  it  may  cause  an
accident  and  severe  personal
injury.
As  towing  a  trailer  may  require
longer braking distance, you shall
keep  a  larger  interval  with  other
vehicles.  For  each  10  km/h,  the
interval  between  you  car  and  the
vehicle in front of you shall be no
less than the  total length  of  your
car  and  the  trailer.  Avoid  hard
braking  to  prevent  the  car  from
skidding,  which  may  get  the  car
out of control.



Tire

● Make sure the tire pressure is proper.

Refer to description in section 7-2.

● Taking the total weight of a trailer into

consideration,  keep  its  tires  with
proper  pressure  as  specified  by  its
manufacturer.


Running-in Procedure
●  For a  new  auto  or  after  it  undergoes

replacement  of  driving  system  parts
(engine,

transmission,

differential

mechanism,  wheel  bearing,  driving
shaft, etc.), do not tow any trailer in the
first 2000 km travel.


Maintenance
●  When  towing  a  trailer,  the  increased

load

requires

more

frequent

maintenance of the car.




How  to  Save  Fuel  and  Extend  Auto
Service Life



In  simple  and  easy  way  you  can  save
fuel.  Fuel-saving  is  also  helpful  to
extend  service  life  of  the  car.  Here  are
some

tips

on

saving

fuel

and

maintenance expense:

●  Maintain  proper  pressure  in  tires.

Insufficient  tire  pressure  may  cause
excessive  tire  wear  and  waste  fuel.
Refer to description in section 7-2.

● Do not leave unnecessary articles on

the  car.  Weight  of  unwanted  articles
will

increase

engine

load

and

consume more fuel.

● Avoid engine long time running idle for

warming up. Once the engine running
is  stable,  you  shall  speed  up  the  car
stably. Take note that in cold weather
the  engine  warming  up  may  take
longer time.

● Acceleration shall be slow and stable.

Avoid hard acceleration. Try to shift to
high speed gear as soon as possible.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





97

●  Avoid  engine  running  idle  for  a  long

time.  If  the  car  must  be  stopped  for
long period, you had better shut down
the engine.

● Avoid engine lug-down or overspeed.

Select  appropriate  gear  according  to
road surface conditions.

●

Avoid

unnecessary

alternative

acceleration  and  deceleration,  which
will waste of fuel.

●  Avoid  unnecessary  stopping  or

braking.  In  driving,  if  you  keep  a
steady  vehicle  speed  while  taking
traffic

signaling

lights

into

consideration,  you  can  stop  your  car
for fewer times; and if possible, take a
road without traffic lights. Keep proper
interval with the vehicle in front of you
to  avoid  hard  braking,  which  is  also
helpful to reduce brake wear.

●  Avoid  driving  in  traffic  peak  hours  or

traffic jam region.

●  Do  not rest  your feet  on clutch  pedal

or brake pedal. It will cause excessive
wear,  overheating  and  higher  fuel
consumption.

●  Keep  proper  speed  on  expressway.

The  higher  speed,  the  larger  fuel
consumption. Slower speed can save
fuel.

●  Keep  Front  Wheels  in  Proper

Alignment Do not impact on curbstone,
and  slow  down  the  speed  on  rugged
road.  Bad  alignment  of  front  wheels
may  cause  excessive  wear  of  tires,
and  also  increase  engine  load  and
fuel consumption.

●  Keep  the  chassis  clean  and  free  of

mud and similar materials. It  helps to
reduce  vehicle  weight  and  prevent
corrosion.

●  Adjust  and  Keep  Vehicle  at  Best
Performance  Dirty  air  filter,  spark  plug,
engine  oil  and  lubricant,  improper
throttle clearance, badly adjusted brake,
etc.  may  have  bad  effect  on  engine
performance

and

increase

fuel

consumption.  To  extend  service  life  of
all parts and reduce operating expense,
regular  maintenance  is  required.  When
driving  under  poor  conditions,  such  as
bad  weather,  maintenance  to  the  car
shall be more frequent (Refer to Chapter
6).





Tips

It  is  prohibited  to  shut  down  the
engine  when  running  down  a
slope.  The  power  steering  and
vacuum  booster  will  be  disabled
when the  engine is  off.  Similarly,
emission

pollutant

control

devices  only  function  when  the
engine is running.





-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





98

Chapter 4

Emergency Treatment



If the Car Cannot Start Up ................................................................................. 99
If Engine Stalls in Driving ................................................................................. 102
If the Car Is Overheated .................................................................................. 102
If the Car Has Flat Tires................................................................................... 103
If the Car Gets Stuck........................................................................................ 108
Tow the Car ...................................................................................................... 109




-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





99

If the Car Cannot Start Up

(a) Simple Check


Before  conducting  this  check,  make

sure  the  starting  procedure  in  ―How  to
Start Engine

‖ in Chapter 3 is performed

properly and there is sufficient fuel.

If  Engine  Cannot  Rotate  or  Rotate
Slowly
1.  Check  whether  battery  terminals  are
tightened and cleaned properly.
2. If battery terminals have no problem,
turn  on  rear  interior  light.  If  the  interior
light  can  not  be  turned  on  or  is  dim,  or
when the battery is depleted in starting,
you  can  try  jump  starting.    See

descriptions in ―(c) Jump Starting‖.
If  the  interior  light  is  on  but  the  engine
cannot  start,  it  shall  be  repaired  or
adjusted.  Please  contact  BYD  service
station for help.










Note

Do  not  push  or  pull  the  car  for
starting.  Otherwise  when  the
engine  starts,  there  may  be
damage  to  the  car  or  collision.  It
may

also

make

three-way

catalytic  converter  overheated,
which may lead to fire.



If the starter of the engine runs at the
normal  speed  but  can  not  start  the
engine
1.  Turn  the  ignition  switch  to  "ACC"  or

"OFF"  and  try  again  to  start  the
engine.

2. If the engine can not start up, maybe

there  is  fuel  spill  as  a  result  of
repeated  starting.  Please  see  "(b)
Start Engine with Fuel Spill" for more
details.

3.  If  the  engine  still  can  not  be  started,

please contact BYD service store for
adjustment or repair.





(b) Start Engine with Fuel Spill

If the engine can not start up, maybe
there  is  fuel  spill  as  a  result  of
repeated starting.

In  this  case,  please  step  on  the
accelerator  pedal  in  full  force  and
meanwhile  rotate  the  ignition  switch  to
"START".  Keep  the  ignition  switch  and
accelerator  pedal  in  this  status  for  5
seconds,  and  then  release  them.  Make
another attempt to start the engine  with
your feet off the accelerator pedal.
If the engine still can not start up after 15
seconds,  please  release  the  ignition
switch,  and  try  starting  once  again
several minutes later.
If  the  engine  still  can  not  be  started,
please  contact  BYD  service  store  for
adjustment or repair.


Note

Each starting attempt shall be no
more  than  5  seconds,  or  it  will
cause  overheating  of  engine  or
wires





-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





100

(c) Jump Start

To avoid personal injury and damage to
the  car  and  electronic  components
caused  by  battery  explosion,  sulphuric
acid  burning,  electrical  appliances  fire,
please  strictly  follow  the  instructions
below.
If  you  are  not  sure  about  these
procedures, please contact BYD service
station for help.



Tips

●  The  battery  contains  toxic  and

erosive  sulphuric  acid.  While
making jump start, please wear
safety glasses and protect your
skin,  clothes,  and  the  car  from
being  spilled  with  sulphuric
acid leakage.


●  If  sulphuric  acid  comes  in

contact  with  any  part  of  your
body or your eyes accidentally,
please  take  off  the  clothes
immediately,  wash  the afflicted
part with clean water, and go to
see  the  doctor  quickly.  If
possible,  continue  to clean  the
affected  area  with  sponge  or
cloth  soaked  in  water  on  the
way to the hospital.


●  If  there  is  flame  or  sparkle

nearby,  the  gas  generated  by
battery  may  cause  explosion.
Please  use  standard  wire  for
jump  start  and  avoid  smoking
or lighting a match.




Note

The charging battery shall be 12V.
Before  conducting  a  jump  start,
please  make  sure  the  charging
battery is applicable.


Procedures of Jump Start

1. If the charging  battery is installed on

another car, please make sure there
is no contact between two cars. Shut
down  all  unwanted  lights  and
electrical devices.

2.  If  necessary,  remove  all  plugs  for

opening  of  the  charging  battery  and
depleted  battery,  and  cover  a  piece
of  cloth  on  the  opening.  (This  is
helpful to reduce danger of explosion,
personal injury and burning.)

3.  Start  and  run  the  engine  of  the  car

with  charging  battery  for  a  few
minutes.

Step

lightly

on

the

accelerator pedal to keep the engine
running at 2000rpm.






-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





101




4. Connect wires in order of a, b, c, d:


a.  Connect  the  clamp  of anode  (red)
jump  starting  wire  to  anode  terminal
(―+‖) of the depleted battery.

b.  Connect  another  clamp  of  anode
(red)  starting  wire  to  anode  terminal
(―+‖) of the charging battery.












c.  Connect  the  clamp  of  cathode
(black)  starting  wire  to  cathode
terminal (―-‖) of the charging battery.
d.  Connect  the  another  clamp  of
cathode (black) starting wire to a solid,
fixed,  unpainted  metal  fixation  point
on the car with depleted battery.

Joint point is shown in the figure below:











Connection for Jump Starting
For jump starting connection, please do
not  leave  the  starting  wire  within  action
range of any moving part.


Tips

To  avoid  personal  injury,  while
connecting,  please  do  not  lean
against

the

battery

or,

by

accident,  make  the  starting  wire
or clamp touch any object except
the appointed  battery  terminal  or
ground point.



5.  Start  the  engine  in  normal  way,  and
then step lightly on the accelerator pedal
to  keep  the  engine  running  for  several
minutes at the speed of 2000rpm.

Depleted battery

Charging
battery

Anode
terminal (

―+‖)

Jumper cable  Anode

terminal (

―+‖)

Depleted
battery

Cathode
terminal (―-‖)

Charging
battery

Jumper cable

-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





102

6. Disconnect the starting wire carefully
in  the  reversed  order  of  connection:
disconnect the cathode starting wire first,
and  then  disconnect  the  anode starting
wire.

7.  Take  away  the  cloth  covering  the
battery,  which  may  be  spilled  with
sulphuric acid.

8. To relocate the battery, you shall  put
all plugs of the battery back in place.
If  the  battery  power  is  discharged  for
reasons  unknown  (such  as  a  light
remaining  on),  please  contact  the  BYD
service station for examination.














If Engine Stalls in Driving

If Engine Stalls in Driving…
1.  Please  slow  down  the  car  slowly,

keep  moving  in  a  straight  way  and
run off the road to a safe place.

2. Turn on the emergency flashlight.
3. Try again to start the engine.
If the engine can not start up, please see
"If the Car Cannot Start Up".


Tips

When  the  engine  is  not  running,
boosters  of  brake  and  steering
device do not work, which makes
steering

and

braking

more

difficult than usual.
● If the engine stalls in driving, do
not open the driver's door before
the

car

stops

completely.

Steering  wheel  will  be  locked
once the driver’s door is opened,
which  may  cause  the  car  out  of
control.





If the Car Is Overheated

If  the  engine  coolant  thermometer
indicates overheated,  or  there  is  power
loss, loud knocking, or noisy bang, that
means  the  engine  may  be  overheated.
Please  handle  it  as  per  the  procedures
below…

1 Drive the car off road, stop it and turn

on  the  emergency  flashlight.  Set  the
transmission to N gear, and apply the
parking

brake.

Shut

down

air

conditioning if it is running.


2.  If  there  is  coolant  or steam  spouting

out  of  the  radiator or  expansion  tank,
please  shut  down  the  engine.  Open
engine hood after steam fades away. If
no  coolant  or  steam  is  spouting,  just
keep  the  engine  running  and  make
sure the cooling fan is  working; if not,
please turn off the ignition switch.



Tips

To avoid personal injury, please
keep the engine hood closed until
there is no steam coming out. The
spouting of steam or coolant
means high pressure.


-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





103

3.  Check  whether  there  is  obvious

coolant  leakage  under  the  radiator,
hose,  and  the  car.  Water  drops
produced  by  AC  system  in  use  are
normal.



Tips

When  engine  is  running,  please
keep  your  hands  and  clothes
away  from  the  working  fan  &
driving belt of the engine.



4.  If  there  is  coolant  leakage,  please

shut  down  the  engine  at  once  and
contact BYD service station for help.

5. In case of no obvious leakage, please

check the coolant reservoir. If it is dry,
please  add  coolant  to  the  reservoir
until  the  level  is  between  two  scale
marks while the engine is running.



Tips

Under high temperature, it is not
allowed to remove the radiator
cap since the spouting
high-temperature steam and
liquid under pressure may cause
serious personal injury.




6.  When  the  coolant  temperature  falls

down  to  normal,  check  the  coolant
level  in  the  tank  again  and  add
additional  coolant  if  necessary.  Large
drop of coolant level means leakage in
the  system;  please  contact  BYD
service

station

for

immediate

examination.



If the Car Has Flat Tires



1.  Please  slow  down  the  car  slowly,

keep  moving  in  a  straight  way  and
run  off  the  road  to  a  safe  place.
Do not park your car on the turnout
track  in  the  middle  of  a  highway.
Park the car on firm and flat ground.

2.  Shut  down  the  engine  and  turn  on

the emergency flashlight.

3.  Apply the parking brake and set the

transmission to N gear.

4.  All people should get off the car for

a place away from traffic.

5.  Read  the  following  instructions

carefully:









Tips

To  reduce  the  possibility  of
serious  personal  injury,  please
obey the instructions below when
you lift the car by jack.
●  Follow  the  manufacturer’s

instructions on using the jack.

● No part of your body is allowed

to  stay  under  the  car  lifted  by
jack,  or  there  may  be  bodily
injury.


●  When  the  car  is  lifted  by  jack,

do not start the engine or leave
it in running.




-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





104

●  Park  the  car  on  flat  and  solid

ground,  pull  up  parking  brake
firmly

and

shift

the

transmission  to  N  gear.  If
necessary,  lay  chock  blocks
under

the

tire

which

is

diagonally  opposite  to  the  tire
to be replaced.


● Make sure the jack is placed on

the right lifting point. Lifting up
the  car  by  a  jack  not  placed
properly may damage the car or
cause  the  car  dropping  down
from the jack, which may result
in personal injuries.


●  When  the  car  is  supported

completely  by  jack,  no  one  is
allowed to stay under the car.

●  Lifting up  the  car  only  for  tire

replacement purpose.

●  Do  not  lift  up  the  car  when

someone is in it.

● Do not put any thing at the top

or  bottom  of  the  jack  while
lifting.

● Just lift the car to a height that

allows

tire

removal

and

replacement.






Note

Do  not  continue  driving  the  car
with  a  flat  tire.  Even  a  short  trip
may damage the tire permanently.




Tools Required and Spare Tire





Take out tools required and the spare

tire.

1.  Toolkit
2.  Jack
3.  Spare tire
In emergency conditions, you may have
to repair the car by yourself. Please well
know  the  use  method  and  storage
location of the jack and various tools.






Rotate  the  terminal  of  the  jack
instructionly

Remove: rotate the terminal in direction

1 until the jack become flexible.

Storage:  rotate  the  terminal  in  direction

2  until  the  jack  is  fixed  tightly  to
prevent  it  from  being  thrown
forward  when  there  is  crash  or
emergency braking.



-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





105




Loosen  and  remove  the  bolts,  then
take out the spare tire.


To store the tire, please put the outside
of the tire downward in  place, and then
fasten  the  tire  in  the  opposite  order  to
prevent  it  from  being  thrown  forward
when  there  is  crash  or  emergency
braking.




Block Wheels





2.  While lifting,  please lay  the  chock
block under the wheel in the diagonal
direction of the flat tire to prevent the
car sliding.
Put  the  chock  block  in  front  of  a  front
wheel or behind a rear wheel.






Unscrew  Bolts  on  Wheel  with  a  Flat
Tire





3. Unscrew all bolts on the wheel with
a flat tire.
Before  lifting  up  the  car,  please  loosen
bolts  on  the  wheel  by  rotating  them
anticlockwise.
For better torque, you can fit a spanner
onto the bolt with its handle on the right
as shown in the figure above. Grip at the
end  of  the  spanner  handle  and  pull
upwards.  Please  avoid  the  spanner
slipping out of the bolt.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





106

Do not remove the bolts, just loosen
them by rotating one cycle and a half.


Tips

Do  not  apply  engine  oil  or
lubricant on the bolts, or they will
get  loose,  which  may  cause  the
wheel  detached  and  lead  to
serious accident.



Jack Positioning





4.  Place  the  jack  under  the  proper
lifting point.

Make sure that the jack is placed on flat
and solid ground.


Lift Up Vehicle





5. Make sure nobody is in the car, and
lift up the car to a height that allows
installation of spare tire.

Please  notice  that  it  needs  larger
clearance  to  install  the  spare  tire  than
remove the flat tire.
To lift up the car, please insert the  jack
handle  into  the  jack  (loose  joint)  and
rotate  it  clockwise.  When  the  jack
touches the car and starts lifting, please
check  again  if  the  jack  is  at  the  right
position.


Tips

When  the  car  is  supported
completely  by  jack,  no  one  is
allowed to stay under the car.




Replace Wheels





6.  Remove  wheel  bolts  and  replace
the tire.

Take off the flat tire and put it aside.
Roll  the  spare  tire  to  the  installation
position,  align  the  bolt  to  tire  hole,  and
then raise the tire until the top bolt fit into
the  screw  hole.  Rotate  the  tire  push  it
until  all  bolts  can  fit  into  corresponding
screw holes.












-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





107






Before  installation,  please  brush  off  all
corrosive  materials  on  the  installation
surface  with  a  wire  brush.  During
installation,  the  metal  area  on  the
installation  surfaces  must  be  in  well
contact  with  each  other,  or  the  wheel
bolts  may  get  loose,  which  may  cause
the tire falling off in driving.





Reinstall Wheel Bolts





7. Reinstall all wheel bolts instructionly.

To  reinstall  bolts,  please  manually
tighten  them  with  wedged  end  inward
first. Push the wheel backward and try to
further tighten the bolts manually.


Tips

Do  not  apply  engine  oil  or
lubricant on the bolts, or they will
get  loose,  which  may  cause  the
wheel  detached  and  lead  to
serious  accident.
。 If  there  is
engine  oil  or  lubricant  on  the
bolts

or

nuts,

clean

them

immediately.

Lower Down Vehicle





8. Lower down the car to ground and
tighten the wheel bolts.


To  lay  down  the  car,  please  rotate  the
jack handle counterclockwise.
Please  use a  spanner for  wheel  bolt  to
tighten  the  bolts.  Do  not  use  any  other
tools or lever, like hammer, tube, or your
feet.
Make sure the spanner is fitted onto the
bolts firmly.
As  per  the  order  shown  in  the  figure
above,  tighten  the  bolts  slightly  one  by
one,  repeat  the  procedure  until  all  the
bolts are fastened firmly.




-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





108

Tips

●  Please  make  sure  no  part  of

your  body  and  no  one  nearby
will  get  injured  while  laying
down the car onto the ground.

●  When  the  tire  is  replaced,

please  use  the  spanner  with  a
torque of 103N·

m (10.5 kgf·

m) to

fasten the  bolts.  Otherwise  the
bolts will get loose, which may
cause  the  tire  falling  off  and
result in serious accident.


























After Tire Replacement

9.

The

tire

pressure

after

replacement.
Adjust  the  tire  pressure  to  the  value
specified  in  Chapter  8.  If  the  current
pressure  is  lower  than  specified  value,
please drive the car slowly to the nearby
service station for air charging.
Do not forget to install the tire valve cap,
or dust and moisture will enter the valve
core to cause possible air leakage. If the
tire  valve  cap  is  missing,  please  use  a
new one immediately.

10.  Put  tools,  jack  and  flat  tire  in
proper storage.

After  tire  replacement,  please  use  a
torque  spanner  to  tighten  the  wheel
bolts to the torque specified in Chapter 8.
The  flat  tire  should  be  repaired  by  a
qualified technician.


Tips

Before  driving,  please  make  sure
all  tools,  jack,  and  flat  tire  are
fixed in  their  storage  position so
as  to  reduce  the  possibility  of
personal injury in case of a crash
or emergency braking.




If the Car Gets Stuck

If the car gets stuck in snow, mud, or
sand,  please  try  to  get  it  out  by
pushing it forward or backward.


Tips

If  there  are  persons  or  objects
near the car, please do not try to
move  the  car  by  pushing  it
forward  and  backward.  If  not,
once  the  car  gets  out  and
suddenly

moves

forward

or

backward, there may be personal
injury or damage to objects.













-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





109

Tow the Car













Use  proper  towing  devices  to  tow  the
car to avoid damage.

Improper  towing  may  damage  the  car.
Most  personnel  handling  towing  know
the right method, but something may go
wrong accidentally. To avoid damage to
the  car,  please  follow  the  precautions
below.



Precautions for Towing:
Towing should  use safety chain system
and  abide  to  applicable  national  and
local  laws.  The  wheels  touching  the
ground and their axle should be in good
condition. If they are damaged, you shall
use platform truck for towing.

Emergency Towing





For  emergency  towing,  you  can
contact BYD service station to handle
on your behalf.
If you can not find a towing company
under emergency situation, please tie
the  towing  cable  or  chain  to  the
emergency  towing  hook  at  the
bottom  of  the  car  for  temporary
towing.  In  this  case,  you  shall  be
extremely careful.


Note

  Please  use  the  specified

towing hook, or the car may be
damaged.

  Do  not  tow  the  car  from  the

rear side with all four wheels on
the  ground,  or  it  will  seriously
damage the transmission.



The driver should sit inside steering the
car and controlling the brake.
Towing  in  this  way  may  only  move  the
car slowly for a short distance on a hard
road.  Meanwhile  it  requires  that  the
wheels,  shafts,  transmission,  drivetrain,
steering  wheel,  and  brake  be  in  good
condition.

Tow from the front

Tow from the rear

Use platform truck

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     5      6      7      8     ..
